MAIN CIRCUIT BOARD FOR FXR-725GD/SS, A.SS, XE
Ref. No.
Part No.
IC301
TK111257100
IC401
TK112311303
IC501
TK111766600
IC701
TK119516300
J104, J107
TK165100006
J113, J116
TK165100006
J134
TK165100006
L101
TK170024500
L102
TK172024034
L103
TK170024900
L104
TK1710578E0
L105
TK170025100
L131, L132
TK172024434
L133
TK1710577E0
L134
TK1710575E0
L151
TK1710579E0
L152
TK1710576E0
L280
TK172021750
L601
TK1730060B0
L701
TK172024834
N280
TK19139A150
P301
TK1981365P5
P302
TK1981365P6
P502
TK26563210
P701
TK1981312AC
Q100
TK12110372B
Q101
TK128012603
Q131, Q605
TK120015503
Q132
TK126021221
Q133
TK120020603
Q134
TK12324121B
Q135
TK123362403
Q601, Q701
TK120014601
Q602, Q608
TK124185811
Q604
TK122132621
Q606
TK120014401
Q607
TK120015503
Q702
TK120014601
R101, R106
TK165333306
R102, R103
TK165310406
R104
TK165333106
R105, R203
TK165333006
R107, R110
TK165310406
R108
TK165315106
R109, R209
TK165368206
R111
TK165311406
R130, R132
TK165310206
R131, R133
TK165310406
R134, R289
TK165322306
Description
IC, UPC4570C
IC, LC75371M-CT
IC, HA13153A
IC, LC72323N-9931
RESISTOR, CHIP, 0OHM 1/8W
RESISTOR, CHIP, 0OHM 1/8W
RESISTOR, CHIP, 0OHM 1/8W
COIL, 1R8-6R5SR
COIL, EL0305RA-1R0K-FT
COIL, 1R9-6R5SR-0.7
COIL, FM-MIX
COIL, 1R45-5R5SR
COIL, EL0305RA-4R7J-FT
COIL, AM-RF
COIL, AM-OSC
COIL, FM-DET
COIL, AM-IFT
COIL, 7132A-153J
L-14-1123
COIL, EL0305RA-220J-FT
WIRE
POST-GIL-S-5P-S2T2
POST-GIL-S-6P-S2T2
CONNECTOR
POST-TMD-L12X-B1
TRANSISTOR, 2SA1037AKT146-Q, R
TRANSISTOR, 3SK126T-O, Y
TRANSISTOR, DTC124EKAT
TRANSISTOR, 2SK212T-E
TRANSISTOR, DTA114EKAT
TRANSISTOR, 2SC2412KT-Q, R
TRANSISTOR, 2SC3624T-17, 18
TRANSISTOR, KTC3199T-Y, GR
TRANSISTOR, 2SD1858T-Q, R
TRANSISTOR, 2SB1326T-R
TRANSISTOR, KTA1272T-O, Y
TRANSISTOR, DTC124EKAT
TRANSISTOR, KTC3199T-Y, GR
RESISTOR, CHIP, 33KOHM 1/16W
RESISTOR, CHIP, 100KOHM 1/16W
RESISTOR, CHIP, 330OHM 1/16W
RESISTOR, CHIP, 33OHM 1/16W
RESISTOR, CHIP, 100KOHM 1/16W
RESISTOR, CHIP, 150OHM 1/16W
RESISTOR, CHIP, 6.8KOHM 1/16W
RESISTOR, CHIP, 110.0KOHM 1/16W
RESISTOR, CHIP, 1KOHM 1/16W
RESISTOR, CHIP, 100KOHM 1/16W
RESISTOR, CHIP, 22KOHM 1/16W
— 23 —
