Parts List - Cassette Deck Mechanism - Sanyo FXR-725GD Servise Manual

Full panel detachable auto reverse cassette player with cd changer controller
Hide thumbs

Advertisement

Ref. No.
Part No.
1
TK6107-000323
2
TKMT75-00047X
3
TK6003-000305
4
TK6107-000369
5
TK6107-000339
6
TK6031-000446
7
TKMT70-00439B
8
TKMT72-00027A
9
TKMT70-00076A
10
TKMT70-00438T
11
TKMT90-11011A
12
TK6031-001032
13
TKMT72-00331N
14
TKMT74-00091C
15
TKMT72-00331P
16
TK6107-001021
17
TKHT72-00046A
18
TK6031-000575
19
TKMT72-00331M
20
TK6031-000431
21
TKMT66-00025A
22
TK6031-000431
23
TKMT66-00017A
24
TK6031-000433
25
TKMT72-00379D
26
TKMT72-00126A
27
TK6107-000191
28
TK6031-000431
29
TKMT72-00379C
30
TKMT72-00331G
31
TKMT75-00047K
32
TK6003-000305
33
TKMT61-00002A
34
TKMT70-00438Z
35
TK6107-001061
36
TK6107-000249
37
TKMT72-00380G
38
TK6009-000333
39
TKMT72-00104A
40
TK6031-000431
41
TK6001-001048
42
TKMT75-00047U
43
TKMT90-11010N
44
TKMT70-00438R
45
TK6107-001023
46
TK6107-001022
47
TKMT66-00016A
48
TKMT91-01011K
49
TK6602-000106
CASSETTE DECK MECHANISM (5AD002)
— 19 —
Description
SPRING-F
ASS'Y CASE L/P
SCREW (M2x4)
SPRINF L/P
SPRING E/P
WASHER(1.6x3.5x0.25T)
CASE E/P
ARM-C
CASE CASSETTE
HOLDER-C
ASS'Y ARM PLAY
WASHER (1x3.2x0.25T)
GEAR CLUTCH 1
FELT CLUTCH
GEAR CLUTCH 2
SPRING CLUTCH
CLUTCH BODY
WASHER (1.2x3.5x0.5T)
GEAR CAM
WASHER (1.2x3x0.25T)
GEAR SENSOR
WASHER (1.2x3x0.25T)
GEAR 19.6B
WASHER (1.2x3.2x0.35T)
GEAR REEL
SENSOR PULLEY
SPRING B/T
WASHER (1.2x3x0.25T)
GEAR PLAY-B
ARM SENSOR
ASS'Y CHASSIS REEL
SCREW (M2x4)
SPRING SWITCH
LEVER SWITCH
SPRING TRIGGER
SPRING ARM LOCK
ARM LOCK
SCREW ARM LOCK
PULLEY CENTER
WASHER (1.2x3x0.25T)
SCREW (M2x2.5)
ASS'Y-EJECT A C/K
ASS'Y MOTOR
LEVER EJECT-B
SPRING EJECT-B
SPRING EJECT-A
GEAR 18.6B
ASS'Y FLYWHEEL
BELT (120.2)
