PARTS LIST
Ref. No.
Part No.
1
TK5BB002
2
TK21047071
3
TK21145270
4
TK21291290
5
TK2952265A
6
TK2952266A
7
TK21035350
8
TK21176550
9
TK28061411
10
AKC393G9C
AKC423G9C
11
TK22331240
TK22331690
12
TK22240150
13
TK29A5208C
14
TK35U27B0
TK35V03B0
15
TK35U97A0
TK35V02A0
ET201
TK37302B0
TK37303B0
16
TK2952266C
17
TK2953268A
18
TK22331552
TK22331561
19
TK22060450
TK22060460
20
TK21176790
21
TK2958266A
22
TK21176820
Ref. No.
Part No.
TK21176533
TK2102013
TK28940560
TK28940590
TK29X12210
TK21176780
TK26917170
TK26917280
TK28584860
TK28530950
TK22720821
CABINET & CHASSIS
Description
CD DECK MECHANISM (5BB002)
COVER (TOP)
HEATSINK (2P)
PLATE SPRING (REL)
DPBS-2.6X5SSA
DPBS-2.6X6SSA
CHASSIS ASSY
BKT ASSY (DET)
INSULATOR
FPPART FXD770GD/SSSOP (FXD-770GD/A.SS)
FPPART FXD775RDS/XESOP (FXD-775RDS/XE)
FPASSY(A) (FXD-770GD/A.SS)
FPASSY(A) (FXD-775RDS/XE)
FACE PLATE(B) (FXD-770GD/A.SS, FXD-775RDS/XE)
TPB2-2X8SSC (FXD-770GD/A.SS, FXD-775RDS/XE)
DISPLAY CIRCUIT BOARD (FXD-770GD/A.SS)
DISPLAY CIRCUIT BOARD (FXD-775RDS/XE)
MAIN CIRCUIT BOARD (FXD-770GD/A.SS)
MAIN CIRCUIT BOARD (FXD-775RDS/XE)
BL ASSY RF33 (FXD-770GD/A.SS)
BL ASSY RF33 (FXD-775RDS/XE)
DPBS-2.6X6SSC
DPBB-2.6X8SSA
FPASSY(C) (FXD-770GD/A.SS)
FPASSY(C) (FXD-775RDS/XE)
ESC ADAPTOR (FXD-770GD/A.SS)
ESC ADAPTOR (FXD-775RDS/XE)
BRACKET (RCA)
DPSS-2.6X6SSA
BRACKET (STOPPER)
ACCESSORY
Description
BRACKET (MOUNT) (FXD-770GD/A.SS, FXD-775RDS/XE)
SUPPORT BRACKET (FXD-770GD/A.SS, FXD-775RDS/XE)
M.KIT (FXD-770GD/A.SS)
M.KIT (FXD-775RDS/XE)
SCREW KIT (FXD-770GD/A.SS, FXD-775RDS/XE)
BRACKET (REL) (FXD-770GD/A.SS, FXD-775RDS/XE)
CABLE ASSY (FXD-770GD/A.SS)
CABLE ASSY (FXD-775RDS/XE)
GIFT BOX (FXD-770GD/A.SS)
IN BOX (FXD-775RDS/XE)
C.CASE ASSY (FXD-770GD/A.SS, FXD-775RDS/XE)
