MAIN CIRCUIT BOARD FOR FXR-725GD/SS, A.SS, XE
Ref. No.
Part No.
R730, R731
TK165210206
R732, R733
TK165210206
R734, R735
TK165210206
R742
TK165210206
TH661
TK100015205
TK180575490
TK21176010
TK21235150
TK21235160
TK26F0002
TK2952266A
MAIN CIRCUIT BOARD FOR FXR-730GD/A.SS, FXC-750GD/A.SS
: FXR-730GD/A.SS
: FXC-750GD/A.SS
Ref. No.
Part No.
AJ201
TK196510300
C201, C257
TK157A1030J
C204
TK157A4730J
C205
TK15715R00J
C206, C207
TK157A1830J
C208
TK157C2240J
C209
TK15713300J
C211, C419
TK1553106K6
C212, C256
TK157A1020J
C251, C253
TK15711010J
C252, C307
TK157C1040J
C254, C303
TK1553476K6
C255
TK157A1040J
C258, C708
TK15712200J
C259
TK15711200J
C260, C401
TK1556105K6
C261, C305
TK157A1030J
C301, C302
TK15716810J
C304
TK1553476K6
C306, C705
TK157A1030J
C402, C403
TK1556105K6
C404,
C405
TK1556105K6
C406, C407
TK1556105K6
C408, C417
TK1556105K6
C409, C410
TK157A1020J
C411, C412
TK157A5630J
C413, C414
TK157A3320J
C415, C416
TK157A2230J
C418, C501
TK1556105K6
C420, C506
TK1553106K6
C421, C604
TK157C1040J
Description
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/10W
PTC-B59975-C120-A54
PCB MAIN
BRACKET (IC)
S.PLATE (TUN-A)
S.PLATE (TUN-B)
FUSE 10A AUTO
DPBS-2.6X6SSA
Description
ANT JACK ASSY
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 0.047UF 16V
CAPACITOR, CHIP, 5PF 50V
CAPACITOR, CHIP, 0.018UF 25V
CAPACITOR, CHIP, 0.22UF 25V
CAPACITOR, CHIP, 33PF 50V
CAPACITOR, ELECTROLYTIC, 10UF 16V
CAPACITOR, CHIP, 1000PF 50V
CAPACITOR, CHIP, 100PF 50V
CAPACITOR, CHIP, 0.1U
CAPACITOR, ELECTROLYTIC, 47UF 16V
CAPACITOR, CHIP, 0.1UF 16V
CAPACITOR, CHIP, 22PF 50V
CAPACITOR, CHIP, 12PF 50V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 680PF 50V
CAPACITOR, ELECTROLYTIC, 47UF 16V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, CHIP, 1000PF 50V
CI-1608B563K25-CT
CAPACITOR, CHIP, 3300PF 50V
CAPACITOR, CHIP, 0.022UF 25V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, ELECTROLYTIC, 10UF 16V
CAPACITOR, CHIP, 0.1U
— 25 —
