DISPLAY CIRCUIT BOARD FOR FXR-725GD/SS, A.SS, XE
Ref. No.
Part No.
SW815
TK23A1127
TK180574511
TK21176741
TK22129651
TK28073560
TK28073630
DISPLAY CIRCUIT BOARD FOR FXR-730GD/A.SS, FXC-750GD/A.SS
Ref. No.
Part No.
C801
TK15786810E
C802
TK157B1040E
D801
TK134028703
D802
TK134024313
D811, D812
TK141026009
D813, D814
TK141026009
D815, D816
TK141026009
D817, D818
TK141026009
D819, D820
TK141026009
D821, D822
TK141026009
D823
TK141026109
D824
TK141029203
H801
TK144027800
IC801
TK112296300
J801, J802
TK165100006
J803, J804
TK165100006
J805, J806
TK165200006
P801
TK1981313AC
PL801
TK146013700
R801, R802
TK165210206
R803, R804
TK165210206
R805
TK165247306
R806
TK165243306
R807
TK165110206
R811, R812
TK165222206
R813, R814
TK165210206
R815, R816
TK165210206
R817, R818
TK165218206
R819, R843
TK165218206
R820, R821
TK165239206
R822, R823
TK165239206
R824, R825
TK165215306
Description
SWITCH (SKQCAC-260G)
PCB DISP
BKT (LCD)
HOLDER ASSY (LCD)
COLOR SHEET (LCD)
COLOR SHEET(LED) 10X10
Description
CAPACITOR, CHIP, 680PF 50V
CAPACITOR, CHIP, 0.1UF 25V
DIODE, ZENER, HZM6.2ZFA
DIODE, ZENER, 02CZ5.1T-Y
LED, MBG3864X-J300K-R
LED, MBG3864X-J300K-R
LED, MBG3864X-J300K-R
LED, MBG3864X-J300K-R
LED, MBG3864X-J300K-R
LED, MBG3864X-J300K-R
LED, SLR-332VRT32-RT
LED, HEB1105W-RR-CT
LCD, 278
IC, LC75834W
RESISTOR, CHIP, 0OHM 1/8W
RESISTOR, CHIP, 0OHM 1/8W
RESISTOR, CHIP, 0OHM 1/10W
POST-TMD-L12P-A2
PILOTLAMP, ASSY 137 G-30
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 47KOHM 1/10W
RESISTOR, CHIP, 43KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/8W
RESISTOR, CHIP, 2.2KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 1.8KOHM 1/10W
RESISTOR, CHIP, 1.8KOHM 1/10W
RESISTOR, CHIP, 3.9KOHM 1/10W
RESISTOR, CHIP, 3.9KOHM 1/10W
RESISTOR, CHIP, 15KOHM 1/10W
