Sanyo FXR-725GD Servise Manual page 33

Full panel detachable auto reverse cassette player with cd changer controller
Hide thumbs

Advertisement

Ref. No.
Parts No.
Q612, Q621
TK120014601
Q631
TK120014601
Q641, Q791
TK120020703
Q651
TK12324121B
Q662
TK120015503
Q792
TK120020203
Q793
TK12110372B
R201, R254
TK165310306
R202, R663
TK165310206
R203, R631
TK165310006
R204
TK1691734D9
R205
TK165382306
R206
TK165368206
R207, R714
TK165310406
R208, R411
TK165339206
R209, R771
TK165333206
R210, R331
TK165322306
R251, R252
TK165347306
R253, R255
TK165322206
R256
TK165315206
R257, R258
TK165347206
R260, R261
TK165310306
R301, R302
TK165347306
R303, R304
TK165310106
R305, R306
TK165333406
R307, R308
TK165315306
R332, R662
TK165222206
R401, R402
TK165322306
R403, R404
TK165300006
R405, R406
TK165382206
R409, R410
TK165333306
R412
TK165339206
R413, R414
TK165322306
R501, R502
TK165310306
R503, R504
TK165310306
R509, R632
TK165310306
R510, R601
TK165322306
R512, R513
TK165310506
R514, R515
TK165310506
R541, R542
TK165210206
R543, R544
TK165247106
R602
TK161C56108
R611
TK165247106
R612
TK165333106
R621, R748
TK165347206
R641
TK165247206
R642, R672
TK165347306
R651
TK165212306
R652
TK165282206
MAIN CIRCUIT BOARD FOR FXC-755RDS/XE
— 31 —
Description
TRANSISTOR, KTC3199T-Y, GR
TRANSISTOR, KTC3199T-Y, GR
TRANSISTOR, DTA124EKAT
TRANSISTOR, 2SC2412KT-Q, R
TRANSISTOR, DTC124EKAT
TRANSISTOR, DTC114EKAT
TRANSISTOR, 2SA1037AKT146-Q, R
RESISTOR, CHIP, 10KOHM 1/16W
RESISTOR, CHIP, 1KOHM 1/16W
RESISTOR, CHIP, 10OHM 1/16W
RESISTOR, SEMI-FIXED, NVZ6TLT-204B-RT
RESISTOR, CHIP, 82KOHM 1/16W
RESISTOR, CHIP, 6.8KOHM 1/16W
RESISTOR, CHIP, 100KOHM 1/16W
RESISTOR, CHIP, 3.9KOHM 1/16W
RESISTOR, CHIP, 3.3KOHM 1/16W
RESISTOR, CHIP, 22KOHM 1/16W
RESISTOR, CHIP, 47KOHM 1/16W
RESISTOR, CHIP, 2.2KOHM 1/16W
RESISTOR, CHIP, 1.5KOHM 1/16W
RESISTOR, CHIP, 4.7KOHM 1/16W
RESISTOR, CHIP, 10KOHM 1/16W
RESISTOR, CHIP, 47KOHM 1/16W
RESISTOR, CHIP, 100OHM 1/16W
RESISTOR, CHIP, 330KOHM 1/16W
RESISTOR, CHIP, 15KOHM 1/16W
RESISTOR, CHIP, 2.2KOHM 1/10W
RESISTOR, CHIP, 22KOHM 1/16W
RESISTOR, CHIP, 0OHM 1/16W
RESISTOR, CHIP, 8.2KOHM 1/16W
RESISTOR, CHIP, 33KOHM 1/16W
RESISTOR, CHIP, 3.9KOHM 1/16W
RESISTOR, CHIP, 22KOHM 1/16W
RESISTOR, CHIP, 10KOHM 1/16W
RESISTOR, CHIP, 10KOHM 1/16W
RESISTOR, CHIP, 10KOHM 1/16W
RESISTOR, CHIP, 22KOHM 1/16W
RESISTOR, CHIP, 1MOHM 1/16W
RESISTOR, CHIP, 1MOHM 1/16W
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 470OHM 1/10W
RESISTOR, CARBON, 560OHM 1/2W
RESISTOR, CHIP, 470OHM 1/10W
RESISTOR, CHIP, 330OHM 1/16W
RESISTOR, CHIP, 4.7KOHM 1/16W
RESISTOR, CHIP, 4.7KOHM 1/10W
RESISTOR, CHIP, 47KOHM 1/16W
RESISTOR, CHIP, 12KOHM 1/10W
RESISTOR, CHIP, 8.2KOHM 1/10W
