Ref. No.
Parts No.
AJ201
TK196510300
C201, C257
TK157A1030J
C204
TK157A4730J
C205
TK15715R00J
C206, C207
TK157A1830J
C208, C212
TK157A1020J
C209, C786
TK15713300J
C211, C419
TK1553106K6
C251, C253
TK15711010J
C252, C307
TK157C1040J
C254, C303
TK1553476K6
C255
TK157A1040J
C256, C308
TK157A1020J
C258, C708
TK15712200J
C259
TK15711200J
C260, C401
TK1556105K6
C261, C305
TK157A1030J
C301, C302
TK15716810J
C304
TK1553476K6
C306, C705
TK157A1030J
C402, C403
TK1556105K6
C404, C405
TK1556105K6
C406, C407
TK1556105K6
C408, C417
TK1556105K6
C409, C410
TK157A1020J
C411, C412
TK157A5630J
C413, C414
TK157A3320J
C415, C416
TK157A2230J
C418, C501
TK1556105K6
C420, C506
TK1553106K6
C421, C604
TK157C1040J
C502, C503
TK1556105K6
C504, C674
TK1556105K6
C505, C791
TK1556474K6
C507
TK1553228G0
C508, C509
TK157A1020J
C551, C682
TK157F1040E
C611
TK1552107K5
C621, C631
TK157C1040J
C641, C704
TK157A1020J
C661, C683
TK157C1040J
C662, C681
TK15711010J
C675
TK1556105K6
C676, C677
TK1556105K5
C701
TK1552227G5
C703
TK1552227K6
C706, C787
TK157C1040J
C707
TK15712700J
C710
TK157A1020J
MAIN CIRCUIT BOARD FOR FXC-755RDS/XE
— 29 —
Description
ANT JACK ASSY
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 0.047UF 16V
CAPACITOR, CHIP, 5PF 50V
CAPACITOR, CHIP, 0.018UF 25V
CAPACITOR, CHIP, 1000PF 50V
CAPACITOR, CHIP, 33PF 50V
CAPACITOR, ELECTROLYTIC, 10UF 16V
CAPACITOR, CHIP, 100PF 50V
CAPACITOR, CHIP, 0.1U
CAPACITOR, ELECTROLYTIC, 47UF 16V
CAPACITOR, CHIP, 0.1UF 16V
CAPACITOR, CHIP, 1000PF 50V
CAPACITOR, CHIP, 22PF 50V
CAPACITOR, CHIP, 12PF 50V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 680PF 50V
CAPACITOR, ELECTROLYTIC, 47UF 16V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, CHIP, 1000PF 50V
CI-1608B563K25-CT
CAPACITOR, CHIP, 3300PF 50V
CAPACITOR, CHIP, 0.022UF 25V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, ELECTROLYTIC, 10UF 16V
CAPACITOR, CHIP, 0.1U
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, ELECTROLYTIC, 0.47UF 50V
CAPACITOR, ELECTROLYTIC, 2200UF 16V
CAPACITOR, CHIP, 1000PF 50V
CAPACITOR, CHIP, 0.1UF 50V
CAPACITOR, ELECTROLYTIC, 100UF 10V
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 1000PF 50V
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 100PF 50V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, ELECTROLYTIC, 220UF 10V
CAPACITOR, ELECTROLYTIC, 220UF 10V
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 27PF 50V
CAPACITOR, CHIP, 1000PF 50V
