DISPLAY CIRCUIT BOARD FOR FXR-725GD/SS, A.SS, XE
Ref. No.
Part No.
C801
TK15716810E
C802
TK157B1040E
D801
TK134028703
D802
TK134030113
D811, D812
TK141026009
D813, D814
TK141026009
D815, D816
TK141026009
D817, D818
TK141026009
D819, D820
TK141026009
D821, D822
TK141026009
D823
TK141026109
D824
TK141028913
H801
TK144027800
IC801
TK112296300
J801, J802
TK165100006
J803, J804
TK165100006
J805, J806
TK165200006
P801
TK1981313AC
PL801
TK146013700
R801, R802
TK165210206
R803, R804
TK165210206
R805
TK165247306
R806
TK165243306
R807
TK165110206
R811, R812
TK165233206
R813, R814
TK165210206
R815, R816
TK165210206
R817, R818
TK165218206
R819
TK165218206
R820, R821
TK165210306
R822, R823
TK165210306
R824, R825
TK165215306
R828, R829
TK165222206
R830, R831
TK165222206
R832, R833
TK165200006
R841, R848
TK165210206
R842, R849
TK165222206
R843, R850
TK165227206
R844, R851
TK165233206
R845, R852
TK165247206
R846, R853
TK165256206
R847
TK165282206
SW801, SW802
TK23A1127
SW803, SW804
TK23A1127
SW805, SW806
TK23A1127
SW807, SW808
TK23A1127
SW809, SW810
TK23A1127
SW811, SW814
TK23A1127
SW812, SW813
TK23A11710
Description
CAPACITOR, CHIP, 680PF 50V
CAPACITOR, CHIP, 0.1UF 25V
DIODE, ZENER, HZM6.2ZFA
DIODE, ZENER, BZX84-C5V1
LED, MBG3864X-J300K-R
LED, MBG3864X-J300K-R
LED, MBG3864X-J300K-R
LED, MBG3864X-J300K-R
LED, MBG3864X-J300K-R
LED, MBG3864X-J300K-R
LED, SLR-332VRT32-RT
LED, HBG1105W-DE-TR-CT
LCD, 278
IC, LC75834W
RESISTOR, CHIP, 0OHM 1/8W
RESISTOR, CHIP, 0OHM 1/8W
RESISTOR, CHIP, 0OHM 1/10W
POST-TMD-L12P-A2
PILOTLAMP, ASSY 137 G-30
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 47KOHM 1/10W
RESISTOR, CHIP, 43KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/8W
RESISTOR, CHIP, 3.3KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 1.8KOHM 1/10W
RESISTOR, CHIP, 1.8KOHM 1/10W
RESISTOR, CHIP, 10KOHM 1/10W
RESISTOR, CHIP, 10KOHM 1/10W
RESISTOR, CHIP, 15KOHM 1/10W
RESISTOR, CHIP, 2.2KOHM 1/10W
RESISTOR, CHIP, 2.2KOHM 1/10W
RESISTOR, CHIP, 0OHM 1/10W
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 2.2KOHM 1/10W
RESISTOR, CHIP, 2.7KOHM 1/10W
RESISTOR, CHIP, 3.3KOHM 1/10W
RESISTOR, CHIP, 4.7KOHM 1/10W
RESISTOR, CHIP, 5.6KOHM 1/10W
RESISTOR, CHIP, 8.2KOHM 1/10W
SWITCH (SKQCAC-260G)
SWITCH (SKQCAC-260G)
SWITCH (SKQCAC-260G)
SWITCH (SKQCAC-260G)
SWITCH (SKQCAC-260G)
SWITCH (SKQCAC-260G)
SWITCH SKQNAC-RT
— 33 —
