Sanyo FXR-725GD Servise Manual page 41
Full panel detachable auto reverse cassette player with cd changer controller
Hide thumbs
Advertisement
RF33S CIRCUIT BOARD FOR FXR-730GD/A.SS, FXC-750GD/A.SS
Ref. No
Part No.
R129
TK169162210
R131
TK165315306
R132
TK165382106
R134
TK165318206
R135
TK165333306
R136
TK165356206
R138
TK165347206
R139
TK165368306
R140
TK165310506
R141
TK165347306
R146
TK165322106
R155
TK165318106
R156
TK169162010
R171
TK165300006
TK182522710
TK21235240
Description
RESISTOR, SEMI-FIXED, KVSF637A-473B
RESISTOR, CHIP, 15KOHM 1/16W
RESISTOR, CHIP, 820OHM 1/16W
RESISTOR, CHIP, 1.8KOHM 1/16W
RESISTOR, CHIP, 33KOHM 1/16W
RESISTOR, CHIP, 5.6KOHM 1/16W
RESISTOR, CHIP, 4.7KOHM 1/16W
RESISTOR, CHIP, 68KOHM 1/16W
RESISTOR, CHIP, 1MOHM 1/16W
RESISTOR, CHIP, 47KOHM 1/16W
RESISTOR, CHIP, 220OHM 1/16W
RESISTOR, CHIP, 180OHM 1/16W
RESISTOR, SEMI-FIXED, KVSF637A-223B
RESISTOR, CHIP, 0OHM 1/16W
PCB RF33
SHIELD PLATE
— 39 —
