RF33S CIRCUIT BOARD FOR FXR-730GD/A.SS, FXC-750GD/A.SS
Ref. No
Part No.
C100, C103
TK15712700J
C101, C171
TK15711200J
C102, C104
TK157A1030J
C105
TK15775R00J
C106
TK15711500J
C107, C122
TK157A2230J
C108, C127
TK155310626
C110, C116
TK157A1030J
C111
TK15712R00J
C112, C113
TK15774R00J
C114
TK15711800J
C115
TK15771200J
C118
TK157A1520J
C119
TK172151546
C120
TK157A6810E
C121, C154
TK157A1030J
C123
TK1552107K6
C124, C129
TK15711010J
C126, C140
TK157A1020J
C128, C182
TK157A1040J
C131
TK15716R00J
C132
TK157A1220J
C133, C150
TK157A2230J
C134
TK155633526
C135
TK155622576
C136, C143
TK157C1050E
C137
TK157A4730J
C138
TK157A3920J
C141
TK157C1040J
C144, C152
TK157C2240E
C145, C151
TK157A1020J
C146
TK157A6820J
C148, C153
TK157C1050E
C149
TK155610526
C155, C156
TK157A1030J
C157
TK157A1230J
C158
TK157C4740E
C159, C162
TK157A1030J
C161, C175
TK157A1020J
C163
TK15773300E
C164, C170
TK157A1030J
C165, C168
TK157C1050E
C166
TK15774R00J
C167
TK157A2230J
C172
TK15711200J
C173, C177
TK157A1030J
C183, C187
TK157A2220J
C186, C189
TK157A1020J
C190
TK15711000J
Description
CAPACITOR, CHIP, 27PF 50V
CAPACITOR, CHIP, 12PF 50V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 5P
CAPACITOR, CHIP, 15PF 50V
CAPACITOR, CHIP, 0.022UF 25V
CAPACITOR, ELECTROLYTIC, 10UF 16V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 2PF 50V
CAPACITOR, CHIP, 4PF 50V
CAPACITOR, CHIP, 18PF 50V
CAPACITOR, CHIP, 12P
CAPACITOR, CHIP, 1500PF 50V
COIL, LK1608-4R7K-CT
CAPACITOR, CHIP, 680PF 50V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, ELECTROLYTIC, 100UF 10V
CAPACITOR, CHIP, 100PF 50V
CAPACITOR, CHIP, 1000PF 50V
CAPACITOR, CHIP, 0.1UF 16V
CAPACITOR, CHIP, 6PF 50V
CAPACITOR, CHIP, 1200PF 50V
CAPACITOR, CHIP, 0.022UF 25V
CAPACITOR, ELECTROLYTIC, 3.3UF 50V
CE-SSM2.2M50-LT
CAPACITOR, CHIP, 1UF 16V
CAPACITOR, CHIP, 0.047UF 16V
CAPACITOR, CHIP, 3900PF 50V
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 0.22UF 25V
CAPACITOR, CHIP, 1000PF 50V
CAPACITOR, CHIP, 6800PF 50V
CAPACITOR, CHIP, 1UF 16V
CAPACITOR, ELECTROLYTIC, 1UF 50V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 0.012U
CAPACITOR, CHIP, 0.47UF, 16V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 1000PF 50V
CAPACITOR, CHIP, 33PF 50V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 1UF 16V
CAPACITOR, CHIP, 4PF 50V
CAPACITOR, CHIP, 0.022UF 25V
CAPACITOR, CHIP, 12PF 50V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 2200PF 50V
CAPACITOR, CHIP, 1000PF 50V
CAPACITOR, CHIP, 10PF 50V
— 37 —
