Sanyo FXR-725GD Servise Manual page 22

Full panel detachable auto reverse cassette player with cd changer controller
Hide thumbs

Advertisement

Ref. No.
Part No.
50
TK6031-001082
51
TK6107-001028
52
TKMT70-00438W
53
TKMT90-02013J
54
TKMT91-21013R
55
TK6003-000322
56
TK6031-000464
57
TK6044-000272
58
TK6031-000486
59
TKMT90-11010P
60
TKMT90-15010E
61
TKMT90-15010D
62
TKMT70-00438P
63
TK6031-000486
64
TK6107-001026
65
TK6031-000430
66
TKMT70-00438Y
67
TK6107-001048
68
TKMT75-00047V
69
TK6031-001082
70
TKMT72-00379E
71
TK6003-000305
72
TK6107-001054
73
TKMT70-00487Q
74
TK6107-001054
75
TKMT70-00487R
76
TK6009-000334
77
TK6003-000295
78
TK6107-000366
79
TK6107-001049
80
TKMT90-02013H
81
TKMT72-00331K
82
TKMT72-00056A
83
TKMT72-00079A
84
TK6009-000334
85
TKMT59-00052A
86
TK6107-000345
87
TK6107-000201
88
TK6002-001011
89
TKMT70-00438A
90
TKMT61-00007A
91
TKMT60-00025A
92
TKMT70-00487U
93
TKMT41-00160B
94
TKMT41-00160A
95
TKMT71-00099A
CASSETTE DECK MECHANISM (5AD002)
— 20 —
Description
WASHER (2.1x5x0.5T)
SPRING LEVER PLAY
LEVER PLAY
ASS'Y CHASSIS MAIN
ASS'Y PCB HEAD
SCREW (2x3.7)
WASHER (1.9x3.2x0.25)
E-RING (ø1.5)
WASHER (2.1x4x0.4T)
ASS'Y ARM C/R
ASS'Y PINCH R
ASS'Y PINCH F
LEVER PRO
WASHER (2.1x4x0.4T)
SPRING LEVER PRO
WASHER (1.2x3.2x0.35T)
LEVER LOCK
SPRING LEVER LOCK
ASS'Y BASE FR C/K
WASHER (2.1x5x0.5T)
STOPPER LEVER
SCREW (M2x4)
SPRING FF/REW
LEVER FF
SPRING FF/REW
LEVER REWIND
SCREW AZIMUTH
SCREW (M2x5.5)
SPRING PINCH
SPRING BASE HEAD
ASS'Y BASE HEAD C/K
PLATE HEAD-B
HOLDER H/B
PLATE HEAD-A
SCREW AZIMUTH
HEAD (TC860CPRF)
SPRING AZIMUTH-R
SPRING AZIMUTH-F
SCREW (M2x3)
STOPPER AZIMUTH
SPRING EJECT
SCREW (Ml.7x2)
EJECT STOPPER
HEAD CONNETOR ASS'Y
MOTOR CONNECTOR ASS'Y
NyIon Tube (L-40mm)
