Ref.No.
PartsNo.
PL801
TK146013700
R801, R802
TK165210206
R803, R804
TK165210206
R805
TK165247306
R806
TK165243306
R807
TK165110206
R811, R812
TK165233206
R813, R814
TK165210206
R815, R816
TK165210206
R817, R818
TK165218206
R819, R843
TK165218206
R820, R821
TK165210306
R822, R823
TK165210306
R824, R825
TK165215306
R828, R829
TK165222206
R830, R831
TK165222206
R832, R833
TK165200006
R841, R848
TK165282106
R842, R849
TK165212206
R844, R851
TK165227206
R845, R852
TK165247206
R846, R853
TK165210306
R847
TK165233306
R850
TK165218206
SW801, SW802
TK23A1127
SW803, SW804
TK23A1127
SW805, SW806
TK23A1127
SW807, SW808
TK23A1127
SW809, SW810
TK23A1127
SW811, SW814
TK23A1127
SW812, SW813
TK23A11710
SW815
TK23A1127
TK180574511
TK21176741
TK22129651
TK28073560
TK28073630
DISPLAY CIRCUIT BOARD FOR FXC-755RDS/XE
— 36 —
Description
PILOTLAMP, ASSY 137 G-30
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 47KOHM 1/10W
RESISTOR, CHIP, 43KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/8W
RESISTOR, CHIP, 3.3KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 1KOHM 1/10W
RESISTOR, CHIP, 1.8KOHM 1/10W
RESISTOR, CHIP, 1.8KOHM 1/10W
RESISTOR, CHIP, 10KOHM 1/10W
RESISTOR, CHIP, 10KOHM 1/10W
RESISTOR, CHIP, 15KOHM 1/10W
RESISTOR, CHIP, 2.2KOHM 1/10W
RESISTOR, CHIP, 2.2KOHM 1/10W
RESISTOR, CHIP, 0OHM 1/10W
RESISTOR, CHIP, 820OHM 1/10W
RESISTOR, CHIP, 1.2KOHM 1/10W
RESISTOR, CHIP, 2.7KOHM 1/10W
RESISTOR, CHIP, 4.7KOHM 1/10W
RESISTOR, CHIP, 10KOHM 1/10W
RESISTOR, CHIP, 33KOHM 1/10W
RESISTOR, CHIP, 1.8KOHM 1/10W
SWITCH (SKQCAC-260G)
SWITCH (SKQCAC-260G)
SWITCH (SKQCAC-260G)
SWITCH (SKQCAC-260G)
SWITCH (SKQCAC-260G)
SWITCH (SKQCAC-260G)
SWITCH SKQNAC-RT
SWITCH (SKQCAC-260G)
PCB DISP
BKT (LCD)
HOLDER ASSY (LCD)
COLOR SHEET (LCD)
COLOR SHEET(LED) 10X10
