TC-W7960
Name
(Downstream)
(Upstream)
(Internet)
(LAN)
(USB)
(Wireless)
(WPS)
Buttons:
Name
WiFi The switch for the WiFi function. Press it to enable/disable the WiFi function.
The switch for the WPS function. Press it for 2 seconds to enable the WPS
WPS
function.
300Mbps Wireless N DOCSIS 3.0 Cable Modem Router User Guide
Status
Green The modem router is synchronized with more than one channel.
White The modem router is synchronized with one channel.
Flashing The modem router is scanning for downstream channels.
Off The initialization is not started, or has failed.
Green The modem router is synchronized with more than one channel.
White The modem router is synchronized with one channel.
Flashing The modem router is synchronizing with upstream channels.
Off The initialization is not started, or has failed.
On Internet service is available.
Off Internet service is not available.
Flashing The modem router is initializing.
On At least one LAN port is connected.
Off No LAN port is connected.
Off No USB device is plugged in to the USB port.
On The USB device is detected and ready to use.
Flashing The USB device is being detected.
On The wireless network is enabled.
Off The wireless network is disabled.
The LED stays on for 5 minutes when a WPS connection is
On/Off
established before turns off.
Flashing WPS connection is in progress. This may take up to 2 minutes.
Indication
Indication
4
