Data
2009 (3009) Output of step 9
2010 (3010) Output of step 10
4001 (5001) Terminal [X1] input signal
4002 (5002) Terminal [X2] input signal
4003 (5003) Terminal [X3] input signal
4004 (5004) Terminal [X4] input signal
4005 (5005) Terminal [X5] input signal
4006 (5006) Terminal [X6] input signal
4007 (5007) Terminal [X7] input signal
4010 (5010) Terminal [FWD] input signal
4011 (5011) Terminal [REV] input signal
6000 (7000) Final run command
(ON when "frequency command 0" and a run command is given)
6001 (7001) Final FWD run command
(ON when "frequency command 0" and a run forward command is given)
6002 (7002) Final REV run command
(ON when "frequency command 0" and a run reverse command is given)
6003 (7003) During acceleration
(ON during acceleration)
6004 (7004) During deceleration
(ON during deceleration)
6005 (7005) Under anti-regenerative control
(ON under anti-regenerative control)
6006 (7006) Within dancer reference position DR_REF
(ON when the dancer roll position is within the reference range)
6007 (7007) Alarm factor presence
(ON when there is no alarm factor)
Logic circuit (U03, etc.)
Any of the following functions is selectable as a logic circuit (with general-purpose timer).
Data Function
0 No function assigned
1 Through output +
General-purpose timer
2 ANDing + General-purpose
timer
3 ORing + General-purpose
timer
4 XORing + General-purpose
timer
5 Set priority flip-flop +
General-purpose timer
6 Reset priority flip-flop +
General-purpose timer
7 Rising edge detector +
General-purpose timer
5.3 Function Code Index by Purpose
Selectable Signals
SO09
SO10
X1
X2
X3
X4
X5
X6
X7
FWD
REV
FL_RUN
FL_FWD
FL_REV
DACC
DDEC
REGA
ALM_ACT
Description
Output is always OFF.
Only a general-purpose timer. No logic circuit exists.
AND circuit with 2 inputs and 1 output, plus
general-purpose timer.
OR circuit with 2 inputs and 1 output, plus general-purpose
timer.
XOR circuit with 2 inputs and 1 output, plus
general-purpose timer.
Set priority flip-flop with 2 inputs and 1 output, plus
general-purpose timer.
Reset priority flip-flop with 2 inputs and 1 output, plus
general-purpose timer.
Rising edge detector with 1 input and 1 output, plus
general-purpose timer.
This detects the rising edge of an input signal and outputs
the ON signal for 2 ms.
