Summary of Contents for Fuji Electric FRENIC5000G11S Series

Page 1: Table Of Contents
Fuji Electric Co.,Ltd. INVERTER SIO Driver System Configuration....................... 3 External Device Selection ....................8 Communication Settings ....................9 Setup Items ........................29 Cable Diagrams ......................33 Supported Device Addresses..................99 Device Code and Address Code.................. 106 Error Messages......................110...
Page 2 INVERTER SIO Driver Introduction This manual describes how to connect the Display and the External Device (target inverter). In this manual, the connection procedure is described in the sections identified below: System Configuration "1 System Configuration" (page 3) This section lists the types of External Devices and SIO that you can connect.
Page 3: System Configuration
INVERTER SIO Driver System Configuration The following section shows system configurations for connecting Fuji Electric Co.,Ltd. External Devices and the Display. Setting Cable Series Inverter Link I/F SIO Type Example Diagram Setting Cable Terminal block on RS-422/485 FRENIC5000G11S G11S- Example 1...
Page 4 INVERTER SIO Driver • If a communication error is generated while operating via RS-422/485, there is a possibility that the stop command will not be recognized via RS-422/485. This is dangerous, so be sure to perform an emergency stop using the External Device outer signal terminal’s force stop function.
Page 5 INVERTER SIO Driver IPC COM Port When connecting IPC with an External Device, the COM port used depends on the series and SIO type. Please refer to the IPC manual for details. Usable port Usable Port Series RS-232C RS-422/485(4 wire) RS-422/485(2 wire) COM1 , COM2,...
Page 6 INVERTER SIO Driver When setting up communication between an External Device and the RS-232C/422/485 interface module, use the IPC (RS-232C) or PS5000 (RS-422/485) cable diagrams. However, when using PFXZPBMPR42P2 in a RS-422/485 (4-wire) configuration with no flow control, connect 7.RTS+ and 8.CTS+, and connect 6.RTS- and 9.CTS-.
Page 7 INVERTER SIO Driver RS-422/485 (4 wire) DIP Switch Setting Description Reserved (always OFF) SIO type: RS-422/485 Output mode of SD (TXD) data: Always output Terminal resistance (220Ω) insertion to SD (TXD): None Terminal resistance (220Ω) insertion to RD (RXD): None Short-circuit of SDA (TXA) and RDA (RXA): Not available Short-circuit of SDB (TXB) and RDB (RXB): Not available RS (RTS) Auto control mode: Disabled...
Page 8: External Device Selection
Use an integer from 1 to 4 to enter the number of Devices/PLCs to connect to the Number of Devices/PLCs display. Select the manufacturer of the External Device to connect. Select "Fuji Electric Manufacturer Co.,Ltd.". Select the External Device model (series) and the connection method. Select "INVERTER SIO".
Page 9: Communication Settings
INVERTER SIO Driver Communication Settings This section provides examples of communication settings recommended by Pro-face for the Display and the External Device. Setting Example 1 GP-Pro EX Settings Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. •...
Page 10 INVERTER SIO Driver Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
Page 11 INVERTER SIO Driver Setting Example 2 GP-Pro EX Settings Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. • Set Wait To Send to 10(ms) or more. Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
Page 12 INVERTER SIO Driver External Device Settings To configure communication settings, use the FUNC/DATA, Up, Down, or PRG/RESET key on the touch panel located on the front of the External Device. Refer to your External Device manual for details. Turn ON the power of the External Device. Press the PRG/RESET key to move to the program mode.
Page 13 INVERTER SIO Driver Setting Example 3 GP-Pro EX Settings Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. • Set Wait To Send to 10(ms) or more. Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
Page 14 INVERTER SIO Driver External Device Settings To configure communication settings, use the FUNC/DATA, Up, Down, or PRG/RESET key on the touch panel located on the front of the External Device. Refer to your External Device manual for details. Turn ON the power of the External Device. Press the PRG/RESET key to move to the program mode.
Page 15 INVERTER SIO Driver Setting Example 4 GP-Pro EX Settings Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. • Set Wait To Send to 5(ms) or more. Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
Page 16 INVERTER SIO Driver External Device Settings To configure communication settings, use the FUNC/DATA, Up, Down, or PRG/RESET key on the touch panel located on the front of the External Device. Refer to your External Device manual for details. Turn ON the power of the External Device. Press the PRG/RESET key to move to the program mode.
Page 17 INVERTER SIO Driver Setting Example 5 GP-Pro EX Settings Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. • Set Wait To Send to 5(ms) or more. Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
Page 18 INVERTER SIO Driver External Device Settings To configure communication settings, use the FUNC/DATA, Up, Down, or PRG/RESET key on the touch panel located on the front of the External Device. Refer to your External Device manual for details. Turn ON the power of the External Device. Press the PRG/RESET key to move to the program mode.
Page 19 INVERTER SIO Driver Setting Example 6 GP-Pro EX Settings Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. • Set Wait To Send to 5(ms) or more. Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
Page 20 INVERTER SIO Driver External Device Settings To configure communication settings, use the FUNC/DATA, Up, Down, or PRG/RESET key on the touch panel located on the front of the External Device. Refer to your External Device manual for details. Turn ON the power of the External Device. Press the PRG/RESET key to move to the program mode.
Page 21 INVERTER SIO Driver Setting Example 7 GP-Pro EX Settings Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. • Set Wait To Send to 5(ms) or more. Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
Page 22 INVERTER SIO Driver External Device Settings To configure communication settings, use the FUNC/DATA, Up, Down, or PRG/RESET key on the touch panel located on the front of the External Device. Refer to your External Device manual for details. Turn ON the power of the External Device. Press the PRG/RESET key to move to the program mode.
Page 23 INVERTER SIO Driver Setting Example 8 GP-Pro EX Settings Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. • Set Wait To Send to 5(ms) or more. Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
Page 24 INVERTER SIO Driver External Device Settings To configure communication settings, use the FUNC/DATA, Up, Down, or PRG/RESET key on the touch panel located on the front of the External Device. Refer to your External Device manual for details. Turn ON the power of the External Device. Press the PRG/RESET key to move to the program mode.
Page 25 INVERTER SIO Driver Setting Example 9 GP-Pro EX Settings Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. • Set Wait To Send to 5(ms) or more. Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
Page 26 INVERTER SIO Driver External Device Settings To configure communication settings, use the FUNC/DATA, Up, Down, or PRG/RESET key on the touch panel located on the front of the External Device. Refer to your External Device manual for details. Turn ON the power of the External Device. Press the PRG/RESET key to move to the program mode.
Page 27 INVERTER SIO Driver 3.10 Setting Example 10 GP-Pro EX Settings Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. • Set Wait To Send to 5(ms) or more. Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings] To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add Device] to add another External Device.
Page 28 INVERTER SIO Driver External Device Settings To configure communication settings, use the FUNC/DATA, Up, Down, or PRG/RESET key on the touch panel located on the front of the External Device. Refer to your External Device manual for details. Turn ON the power of the External Device. Press the PRG/RESET key to move to the program mode.
Page 29: Setup Items
INVERTER SIO Driver Setup Items Set up the Display's communication settings in GP Pro-EX or in the Display's off-line mode. The setting of each parameter must match that of the External Device. "3 Communication Settings" (page 9) Setup Items in GP-Pro EX Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].
Page 30 INVERTER SIO Driver Setup Items Setup Description Enter the time (seconds) for which the Display waits for the response from the External Device, from "1 to 127". Timeout • If the Timeout value is set to less than 10(s), it will be changed to 10(s) when initializing the External Device from the Display.
Page 31 INVERTER SIO Driver Setup Items in Off-line Mode • Refer to the Maintenance/Troubleshooting manual for information on how to enter off-line mode or about the operation. Cf. Maintenance/Troubleshooting Manual "Off-line Mode" • The number of the setup items to be displayed for 1 page in the off-line mode depends on the Display in use.
Page 32 INVERTER SIO Driver Setup Items Setup Description Enter the time (seconds) for which the Display waits for the response from the External Device, from "1 to 127". Timeout • If the Timeout value is set to less than 10(s), it will be changed to 10(s) when initializing the External Device from the Display.
Page 33: Cable Diagrams
INVERTER SIO Driver Cable Diagrams The following cable diagrams may be different from cable diagrams recommended by Fuji Electric Co.,Ltd. Please be assured there is no operational problem in applying the cable diagrams shown in this manual. • Please ground the FG pin of the External Device body. Use a grounding resistance of 100Ω 2mm or thicker wire, or your country's applicable standard.
Page 34 INVERTER SIO Driver Display Cable Remarks (Connection Port) GP-4107 (COM1) Cable length: GP-4*03T (COM2) User-created cable 500m or less GP-4203T (COM1) RS-422 Terminal Block Conversion Adapter by Pro-face GP4000 (COM2) PFXZCBADTM1 GP-4201T (COM1) Cable length: SP5000 (COM1/2) 500m or less User-created cable SP-5B00 (COM2) User-created cable...
Page 35 INVERTER SIO Driver • 1:1 Connection Display side Signal name Shield External Device side Display CA3-ADPCOM-01 Terminal block Signal name Termination DX(+) resistance CA3-ADPTRM-01 120 Ω (1/2W) DX(-) User-created cable • 1:n Connection Display side Signal name Shield Shield Display External Device side External Device side CA3-ADPCOM-01...
Page 36 INVERTER SIO Driver • 1:1 Connection Display side D-Sub 9 pin (socket) Termination resistance Signal name Shield External Device side 120 Ω (1/2W) Terminal block Signal name Termination DX(+) Display resistance 120 Ω (1/2W) DX(-) Shell • 1:n Connection Display side D-Sub 9 pin (socket) Termination resistance...
Page 37 INVERTER SIO Driver • 1:1 Connection Display side Signal name Shield External Device side Display CA4-ADPONL-01 Terminal block Signal name Termination DX(+) resistance CA3-ADPTRM-01 Ω (1/2W) DX(-) User-created cable • 1:n Connection Display side Signal name Shield External Device side External Device side Display Shield...
Page 38 INVERTER SIO Driver • 1:1 Connection Display side D-Sub 9 pin (plug) Signal name Shield TRMRX External Device side CA4-ADPONL-01 Terminal block Display Signal name Termination DX(+) resistance Ω (1/2W) DX(-) TRMTX Shell User-created cable • 1:n Connection Display side D-Sub 9 pin (plug) Signal name Shield...
Page 39 INVERTER SIO Driver • 1:1 Connection Display side External Device side Shield Terminal block Signal name Display CA3-ADPCOM-01 Signal name Termination DX(+) resistance Ω (1/2W) DX(-) CA3-ADPTRM-01 User-created cable • 1:n Connection Display side External Device side External Device side Shield Shield Terminal block...
Page 40 INVERTER SIO Driver • 1:1 Connection External Device side Display side Terminal Block D-Sub 9 pin (socket) Shield Terminal resistance Signal name Signal name Ω (1/2W) Terminal DX(+) DATA+ resistance Ω (1/2W) DX(-) DATA- Display Shell • 1:n Connection External Device side Shield External Device side Display side...
Page 41 INVERTER SIO Driver • 1:1 Connection Display side Terminal block Termination Signal name Shield External Device side resistance*1 Terminal block Signal name Termination DX(+) Display resistance 120 Ω (1/2W) DX(-) • 1:n Connection Display side Terminal block Termination Signal name External Device side External Device side Shield...
Page 42 INVERTER SIO Driver • 1:1 Connection Display side External Device side D-Sub 9pin (plug) Terminal Block Shield Terminal resistance Signal name Signal name Ω (1/2W) Terminal DX(+) LINE(+) resistance Ω (1/2W) DX(-) LINE(-) Display GND(SG) RS(RTS) Shell • 1:n Connection External Device side Shield Display side...
Page 43 INVERTER SIO Driver • 1:1 Connection Display side Signal name Shield External Device side Display Terminal block Signal name Termination DX(+) resistance PFXZCBADTM1 120 Ω (1/2W) DX(-) User-created cable • 1:n Connection Display side Signal name Shield Display External Device side Shield External Device side Terminal block...
Page 44 INVERTER SIO Driver • 1:1 Connection External Device side Terminal Block Signal name Display Terminal DX(+) resistance Ω (1/2W) DX(-) • 1:n Connection Terminal External Device side Shield External Device side resistance Terminal Block Terminal Block 220Ω(1/4W) Signal name Signal name Display Terminal DX(+)
Page 45 INVERTER SIO Driver • 1:1 Connection External Device side Display side Terminal Block D-Sub 9 pin (socket) Shield Terminal resistance Signal name Signal name Ω (1/2W) Terminal DATA+ DX(+) resistance Ω (1/2W) DX(-) DATA- Display Shell • 1:n Connection External Device side Shield External Device side Display side...
Page 46 INVERTER SIO Driver Cable Diagram 2 Display Cable Remarks (Connection Port) COM port conversion adapter by Pro-face CA3-ADPCOM-01 GP3000 (COM1) AGP-3302B (COM2) Terminal block conversion adapter by Pro-face GP-4*01TM (COM1) Cable length: CA3-ADPTRM-01 GP-Rear Module (COM1) 500m or less (COM2) User-created cable LT3000 (COM1) User-created cable...
Page 47 • The following cables are recommended as the connecting cable for use with RJ-45 connectors. Part name Model Remarks Extension cable by Fuji Electric CB-5S, CB-3S, 3 cables available in length of 5m, Systems Co., Ltd. CB-1S 3m, and 1m.
Page 48 INVERTER SIO Driver • Do not use pin numbers 1, 2, 7 and 8 of the FRENIC-MEGA, FRENIC-Mini, FRENIC- Eco, FRENIC-Multi series for communications. Refer to your External Device manual for details. • When using the FVR-E11S series, do not connect the VCC to the connector cables. Refer to your External Device manual for details.
Page 49 INVERTER SIO Driver • 1:1 Connection Display side Signal name Display External Device side CA3-ADPCOM-01 RJ-45 connector Signal name DX(+) CA3-ADPTRM-01 DX(-) User-created cable • 1:n Connection Display side Signal name Display Branch Adapter side CA3-ADPCOM-01 RJ-45 connector Signal name Branch Adapter DX(+)
Page 50 INVERTER SIO Driver • 1:1 Connection Display side D-Sub 9 pin (socket) Termination resistance Signal name External Device side Ω (1/2W) RJ-45 connector Signal name Display DX(+) DX(-) Shell • 1:n Connection Display side D-Sub 9 pin (socket) Termination resistance Signal name Branch Adapter side Ω...
Page 51 INVERTER SIO Driver • 1:1 Connection Display side Signal name Display Branch Adapter side CA4-ADPONL-01 RJ-45 connector Signal name DX(+) CA3-ADPTRM-01 DX(-) User-created cable • 1:n Connection Display side Signal name Display Branch Adapter side CA4-ADPONL-01 RJ-45 connector Signal name Branch Adapter DX(+)
Page 52 INVERTER SIO Driver • 1:1 Connection Display side D-Sub 9 pin (plug) Signal name TRMRX External Device side CA4-ADPONL-01 RJ-45 connector Display Signal name DX(+) DX(-) TRMTX Shell User-created cable • 1:n Connection Display side D-Sub 9 pin (plug) Signal name TRMRX Branch Adapter side CA4-ADPONL-01...
Page 53 INVERTER SIO Driver • 1:1 Connection Display side External Device side RJ-45 connector Signal name Display CA3-ADPCOM-01 Signal name DX(+) DX(-) CA3-ADPTRM-01 User-created cable • 1:n Connection Display side Branch Adapter side Signal name RJ-45 connector Display CA3-ADPCOM-01 Signal name Branch Adapter DX(+)
Page 54 INVERTER SIO Driver • 1:1 Connection External Device side Display side D-Sub 9 pin (socket) RJ-45 connector Termination resistance Signal name Signal name Ω (1/2W) DATA+ DX(+) DATA- DX(-) Display Shell • 1:n Connection Branch Adapter side Display side D-Sub 9 pin (socket) RJ-45 connector Termination resistance...
Page 55 INVERTER SIO Driver • 1:1 Connection Display side Terminal block Termination Signal name External Device side resistance*1 RJ-45 connector Signal name Display DX(+) DX(-) • 1:n Connection Display side Terminal block Termination Signal name Branch Adapter side resistance*1 RJ-45 connector Signal name Branch Adapter...
Page 56 INVERTER SIO Driver • 1:1 Connection External Device side Display side RJ-45 connector D-Sub 9pin (plug) Termination resistance Signal name Signal name Ω (1/2W) DX(+) LINE(+) DX(-) LINE(-) Display GND(SG) RS(RTS) Shell • 1:n Connection Display side Branch Adapter side D-Sub 9pin (plug) RJ-45 connector Termination...
Page 57 INVERTER SIO Driver • 1:1 Connection Display side Signal name Display External Device side RJ-45 connector Signal name DX(+) PFXZCBADTM1 DX(-) User-created cable • 1:n Connection Display side Signal name Display Branch Adapter side RJ-45 connector Signal name Branch Adapter DX(+) External Device side Branch Adapter side...
Page 58 INVERTER SIO Driver • 1:1 Connection External Device side RJ-45 connector Signal name Display DX(+) DX(-) • 1:n Connection Branch Adapter side RJ-45 connector Signal name Branch Display Adapter DX(+) Branch Adapter side External Device side DX(-) RJ-45 connector RJ-45 connector Signal name Signal name Branch Adapter side...
Page 59 INVERTER SIO Driver • 1:1 Connection External Device side Display side D-Sub 9 pin (socket) RJ-45 connector Termination resistance Signal name Signal name Ω (1/2W) DATA+ DX(+) DATA- DX(-) Display Shell • 1:n Connection Branch Adapter side Display side D-Sub 9 pin (socket) RJ-45 connector Termination resistance...
Page 60 INVERTER SIO Driver Cable Diagram 3 Display Cable Remarks (Connection Port) COM port conversion adapter by Pro-face CA3-ADPCOM-01 GP3000 (COM1) AGP-3302B (COM2) Terminal block conversion adapter by Pro-face GP-4*01TM (COM1) Cable length: CA3-ADPTRM-01 GP-Rear Module (COM1) 500m or less (COM2) User-created cable LT3000 (COM1) User-created cable...
Page 61 INVERTER SIO Driver All GP3000 models except the GP-3200 Series and AGP-3302B Only a COM port which can communicate by RS-422/485 (2-wire) can be used. (Except PE-4000B, PS5000) IPC COM Port (page 5) Except GP-4203T All GP4000 models except GP-4100 Series, GP-4*01TM, GP-Rear Module, GP-4201T and GP-4*03T Except SP-5B00 When using a Terminal Block Conversion Adapter (CA3-ADPTRM-01) instead of the RS-422 Terminal Block Conversion Adapter, refer to Cable Diagram 3A.
Page 62 INVERTER SIO Driver • 1:1 Connection Display side Signal name Shield External Device side Display CA3-ADPCOM-01 Terminal block Signal name DX(+) CA3-ADPTRM-01 DX(-) User-created cable • 1:n Connection Display side Signal name Shield Display External Device side External Device side CA3-ADPCOM-01 Terminal block Terminal block...
Page 63 INVERTER SIO Driver • 1:1 Connection Display side D-Sub 9 pin (socket) Termination resistance Signal name External Device side Shield Ω 112 (1/2W) Terminal block Signal name DX(+) Display DX(-) Shell • 1:n Connection Display side D-Sub 9 pin (socket) Termination resistance Signal name...
Page 64 INVERTER SIO Driver • 1:1 Connection Display side Signal name Shield External Device side Display CA4-ADPONL-01 Terminal block Signal name DX(+) CA3-ADPTRM-01 DX(-) User-created cable • 1:n Connection Display side Signal name Shield External Device side External Device side Display CA4-ADPONL-01 Terminal block Terminal block...
Page 65 INVERTER SIO Driver • 1:1 Connection Display side D-Sub 9 pin (plug) Signal name Shield TRMRX External Device side CA4-ADPONL-01 Terminal block Display Signal name DX(+) DX(-) TRMTX Shell User-created cable • 1:n Connection Display side D-Sub 9 pin (plug) Signal name Shield TRMRX...
Page 66 INVERTER SIO Driver • 1:1 Connection Display side External Device side Shield Terminal block Display Signal name CA3-ADPCOM-01 Signal name DX(+) DX(-) CA3-ADPTRM-01 User-created cable • 1:n Connection Display side External Device side External Device side Shield Terminal block Terminal block Signal name Display CA3-ADPCOM-01...
Page 67 INVERTER SIO Driver • 1:1 Connection External Device side Display side Terminal block D-Sub 9 pin (socket) Shield Termination resistance Signal name Signal name Ω 112 (1/2W) DX(+) DATA+ DATA- DX(-) Display Shell • 1:n Connection External Device side External Device side Display side Terminal block Terminal block...
Page 68 INVERTER SIO Driver • 1:1 Connection Display side Terminal block Termination Signal name External Device side Shield resistance*1 Terminal block Signal name DX(+) Display DX(-) • 1:n Connection Display side Terminal block Termination Signal name External Device side External Device side Shield resistance*1 Terminal block...
Page 69 INVERTER SIO Driver • 1:1 Connection External Device side Display side Terminal block D-Sub 9pin (plug) Shield Termination resistance Signal name Signal name Ω 112 (1/2W) DX(+) LINE(+) DX(-) LINE(-) Display GND(SG) RS(RTS) Shell • 1:n Connection External Device side External Device side Display side D-Sub 9pin (plug)
Page 70 INVERTER SIO Driver • 1:1 Connection Display side Signal name Shield External Device side Display Terminal block Signal name DX(+) PFXZCBADTM1 DX(-) User-created cable • 1:n Connection Display side Signal name Shield Display External Device side External Device side Terminal block Terminal block Shield Signal name...
Page 71 INVERTER SIO Driver • 1:1 Connection External Device side Terminal block Signal name Display DX(+) DX(-) • 1:n Connection External Device side External Device side Termination resistance Terminal block Terminal block 220Ω(1/4W) Shield Signal name Signal name Display Termination DX(+) DX(+) resistance 220Ω(1/4W)
Page 72 INVERTER SIO Driver • 1:1 Connection External Device side Display side Terminal block D-Sub 9 pin (socket) Shield Termination resistance Signal name Signal name Ω 112 (1/2W) DX(+) DATA+ DX(-) DATA- Display Shell • 1:n Connection External Device side External Device side Display side Terminal block Terminal block...
Page 73 INVERTER SIO Driver Cable Diagram 4 Display Cable Remarks (Connection Port) COM port conversion adapter by Pro-face GP3000 (COM1) CA3-ADPCOM-01 AGP-3302B (COM2) GP-4*01TM (COM1) Terminal block conversion adapter by Pro-face Cable length: GP-Rear Module CA3-ADPTRM-01 500m or less (COM1) (COM2) User-created cable LT3000 (COM1) User created cable...
Page 74 INVERTER SIO Driver All GP3000 models except the GP-3200 Series and AGP-3302B Only a COM port which can communicate by RS-422/485 (2-wire) can be used. (Except PE-4000B, PS5000) IPC COM Port (page 5) Except GP-4203T All GP4000 models except GP-4100 Series, GP-4*01TM, GP-Rear Module, GP-4201T and GP-4*03T Except SP-5B00 When using a Terminal Block Conversion Adapter (CA3-ADPTRM-01) instead of the RS-422 Terminal Block Conversion Adapter, refer to Cable Diagram 4A.
Page 75 INVERTER SIO Driver • 1:1 Connection Display side Signal name Shield External Device side Display CA3-ADPCOM-01 Terminal block Signal name Termination DX(+) resistance CA3-ADPTRM-01 Ω (1/2W) DX(-) User-created cable • 1:n Connection Display side Signal name Shield External Device side External Device side Display CA3-ADPCOM-01...
Page 76 INVERTER SIO Driver • 1:1 Connection Display side D-Sub 9 pin (socket) Termination resistance Signal name External Device side Shield Ω (1/2W) Terminal block Signal name Termination DX(+) Display resistance Ω (1/2W) DX(-) Shell • 1:n Connection Display side D-Sub 9 pin (socket) Termination resistance Signal name...
Page 77 INVERTER SIO Driver • 1:1 Connection Display side Signal name Shield External Device side Display CA4-ADPONL-01 Terminal block Signal name Termination DX(+) resistance CA3-ADPTRM-01 Ω (1/2W) DX(-) User-created cable • 1:n Connection Display side Signal name Shield External Device side External Device side Display CA4-ADPONL-01...
Page 78 INVERTER SIO Driver • 1:1 Connection Display side D-Sub 9 pin (plug) Signal name Shield TRMRX External Device side CA4-ADPONL-01 Terminal block Display Signal name Termination DX(+) resistance Ω (1/2W) DX(-) TRMTX Shell User-created cable • 1:n Connection Display side D-Sub 9 pin (plug) Signal name Shield...
Page 79 INVERTER SIO Driver • 1:1 Connection Display side External Device side Shield Terminal block Signal name Display CA3-ADPCOM-01 Signal name Termination DX(+) resistance Ω (1/2W) DX(-) CA3-ADPTRM-01 User-created cable • 1:n Connection Display side External Device side External Device side Shield Terminal block Terminal block...
Page 80 INVERTER SIO Driver • 1:1 Connection External Device side Display side Terminal block D-Sub 9 pin (socket) Shield Termination resistance Signal name Signal name Ω (1/2W) Termination DX(+) DATA+ resistance Ω (1/2W) DX(-) DATA- Display Shell • 1:n Connection External Device side External Device side Display side Terminal block...
Page 81 INVERTER SIO Driver • 1:1 Connection Display side Terminal block Termination Signal name External Device side Shield resistance*1 Terminal block Signal name Termination DX(+) Display resistance Ω (1/2W) DX(-) • 1:n Connection Display side Terminal block Termination Signal name External Device side External Device side Shield resistance*1...
Page 82 INVERTER SIO Driver • 1:1 Connection External Device side Display side Terminal block D-Sub 9pin (plug) Shield Termination resistance Signal name Signal name Ω Termination (1/2W) DX(+) resistance LINE(+) Ω (1/2W) DX(-) LINE(-) Display GND(SG) RS(RTS) Shell • 1:n Connection External Device side External Device side Display side...
Page 83 INVERTER SIO Driver • 1:1 Connection Display side Signal name Shield External Device side Display Terminal block Signal name Termination DX(+) resistance PFXZCBADTM1 Ω (1/2W) DX(-) User-created cable • 1:n Connection Display side Signal name Shield External Device side External Device side Display Terminal block Terminal block...
Page 84 INVERTER SIO Driver • 1:1 Connection External Device side Terminal block Signal name Display Termination DX(+) resistance Ω (1/2W) DX(-) • 1:n Connection External Device side External Device side Termination Terminal block Terminal block resistance Shield 220Ω(1/4W) Signal name Signal name Display Termination DX(+)
Page 85 INVERTER SIO Driver • 1:1 Connection External Device side Display side Terminal block D-Sub 9 pin (socket) Shield Termination resistance Signal name Signal name Ω (1/2W) Termination DX(+) DATA+ resistance Ω (1/2W) DATA- DX(-) Display Shell • 1:n Connection External Device side External Device side Display side Terminal block...
Page 86 INVERTER SIO Driver Cable Diagram 5 Display Cable Remarks (Connection Port) The COM port conversion adapter by Pro-face CA3-ADPCOM-01 GP3000 (COM1) AGP-3302B (COM2) Terminal block conversion adapter by Pro-face GP-4*01TM (COM1) Cable length: CA3-ADPTRM-01 GP-Rear Module (COM1) 500m or less (COM2) User-created cable LT3000 (COM1)
Page 87 • The following cables are recommended as the connecting cable for use with RJ-45 connectors. Parts name Model Remarks Extension cable by Fuji Electric CB-5S, CB-3S, 3 cables available in length of 5m, Systems Co., Ltd. CB-1S 3m, and 1m.
Page 88 INVERTER SIO Driver • 1:1 Connection Display side External Device side Signal name RS-485 communication card Display (OPC-E1-RS card) CA3-ADPCOM-01 RJ-45 connector Signal name DX(+) CA3-ADPTRM-01 DX(-) User-created cable • 1:n Connection Display side Signal name External Device side RS-485 communication card Display CA3-ADPCOM-01 (OPC-E1-RS card)
Page 89 INVERTER SIO Driver • 1:1 Connection Display side D-Sub 9 pin (socket) Termination External Device side resistance Signal name RS-485 communication card Ω (1/2W) (OPC-E1-RS card) RJ-45 connector Signal name DX(+) Display DX(-) Shell • 1:n Connection Display side D-Sub 9 pin (socket) Termination External Device side resistance...
Page 90 INVERTER SIO Driver • 1:1 Connection Display side External Device side Signal name RS-485 communication card Display (OPC-E1-RS card) CA4-ADPONL-01 RJ-45 connector Signal name DX(+) CA3-ADPTRM-01 DX(-) User-created cable • 1:n Connection Display side Signal name External Device side RS-485 communication card Display CA4-ADPONL-01 (OPC-E1-RS card)
Page 91 INVERTER SIO Driver • 1:1 Connection Display side D-Sub 9 pin (plug) Signal name External Device side RS-485 communication card TRMRX CA4-ADPONL-01 (OPC-E1-RS card) RJ-45 connector Display Signal name DX(+) DX(-) TRMTX Shell User-created cable • 1:n Connection Display side D-Sub 9 pin (plug) Signal name External Device side...
Page 92 INVERTER SIO Driver • 1:1 Connection External Device side RS-485 communication card Display side (OPC-E1-RS card) RJ-45 connector Display Signal name CA3-ADPCOM-01 Signal name DX(+) DX(-) CA3-ADPTRM-01 User-created cable • 1:n Connection External Device side Display side RS-485 communication card (OPC-E1-RS card) Signal name Display...
Page 93 INVERTER SIO Driver • 1:1 Connection External Device side RS-485 communication card Display side (OPC-E1-RS card) D-Sub 9 pin (socket) RJ-45 connector Termination resistance Signal name Signal name Ω (1/2W) DX(+) DATA+ DX(-) DATA- Display Shell • 1:n Connection External Device side RS-485 communication card Display side (OPC-E1-RS card)
Page 94 INVERTER SIO Driver • 1:1 Connection Display side Terminal block External Device side Termination Signal name RS-485 communication card resistance*1 (OPC-E1-RS card) RJ-45 connector Signal name DX(+) Display DX(-) • 1:n Connection Display side Terminal block External Device side Termination Signal name RS-485 communication card resistance*1...
Page 95 INVERTER SIO Driver • 1:1 Connection External Device side RS-485 communication card Display side (OPC-E1-RS card) D-Sub 9pin (plug) RJ-45 connector Termination resistance Signal name Signal name Ω (1/2W) DX(+) LINE(+) DX(-) LINE(-) Display GND(SG) RS(RTS) Shell • 1:n Connection External Device side RS-485 communication card Display side...
Page 96 INVERTER SIO Driver • 1:1 Connection Display side External Device side Signal name RS-485 communication card Display (OPC-E1-RS card) RJ-45 connector Signal name DX(+) PFXZCBADTM1 DX(-) User-created cable • 1:n Connection Display side Signal name External Device side RS-485 communication card Display (OPC-E1-RS card) RJ-45 connector...
Page 97 INVERTER SIO Driver • 1:1 Connection External Device side RS-485 communication card (OPC-E1-RS card) RJ-45 connector Signal name Display DX(+) DX(-) • 1:n Connection External Device side RS-485 communication card (OPC-E1-RS card) RJ-45 connector Signal name Display DX(+) External Device side DX(-) External Device side RJ-45 connector...
Page 98 INVERTER SIO Driver • 1:1 Connection External Device side RS-485 communication card Display side (OPC-E1-RS card) D-Sub 9 pin (socket) RJ-45 connector Termination resistance Signal name Signal name Ω (1/2W) DATA+ DX(+) DATA- DX(-) Display Shell • 1:n Connection External Device side RS-485 communication card Display side (OPC-E1-RS card)
Page 99: Supported Device Addresses
INVERTER SIO Driver Supported Device Addresses The following section shows the range of supported device addresses. Please note that the actual supported range of the devices vary depending on the External Device to be used. Please check the actual range in the manual of your External Device.
Page 100 INVERTER SIO Driver FVR-E11S Series : This address can be specified as system data area. Device Bit Address Word address 32 bits Remarks Basic function F00.00-F42.15 F00-F42 Terminal function E01.00-E42.15 E01-E42 Control function C01.00-C33.15 C01-C33 Motor 1 P01.00-P10.15 P01-P10 High level function H01.00-H46.15 H01-H46 Motor 2...
Page 101 INVERTER SIO Driver FVR-C11S Series : This address can be specified as system data area. Device Bit Address Word address 32 bits Remarks Basic function F00.00-F36.15 F00-F36 Terminal function E01.00-E03.15 E01-E03 Control function C01.00-C07.15 C01-C07 Motor 1 P00.00-P00.15 High level function H01.00-H25.15 H01-H25 Option...
Page 102 INVERTER SIO Driver FRENIC-MEGA Series : This address can be specified as system data area. Device Bit Address Word address 32 bits Remarks Fundamental function F00.00-F80.15 F00-F80 Extension terminal function E01.00-E99.15 E01-E99 Control function of frequency C01.00-C53.15 C01-C53 Motor 1 parameter P01.00-P99.15 P01-P99 High performance function...
Page 103 INVERTER SIO Driver FRENIC-Mini Series : This address can be specified as system data area. Device Bit Address Word address 32 bits Remarks Fundamental function F00.00-F51.15 F00-F51 Extension terminal function E01.00-E99.15 E01-E99 Control function of frequency C01.00-C52.15 C01-C52 Motor 1 parameter P02.00-P99.15 P02-P99 High performance function...
Page 104 INVERTER SIO Driver FRENIC-Eco Series : This address can be specified as system data area. Device Bit Address Word address 32 bits Remarks Fundamental function F00.00-F44.15 F00-F44 Extension terminal function E01.00-E99.15 E01-E99 Control function of frequency C01.00-C53.15 C01-C53 Motor 1 parameter P01.00-P99.15 P01-P99 High performance function...
Page 105 INVERTER SIO Driver FRENIC-Multi Series : This address can be specified as system data area. Device Bit Address Word address 32 bits Remarks Fundamental function F00.00-F51.15 F00-F51 Extension terminal function E01.00-E99.15 E01-E99 Control function of frequency C01.00-C53.15 C01-C53 Motor 1 parameter P01.00-P99.15 P01-P99 High performance function...
Page 106: Device Code And Address Code
INVERTER SIO Driver Device Code and Address Code Use device code and address code if you select "Device Type & Address" for the address type of the data display. FRENIC5000G11S/FRENIC5000P11S Series Device Code Device Device Name Address Code (HEX) Basic function 0080 Word address Terminal function...
Page 107 INVERTER SIO Driver FVR-C11S Series Device Code Device Device Name Address Code (HEX) Basic function 0080 Word address Terminal function 0081 Word address Control function 0082 Word address Motor 1 0083 Word address High level function 0084 Word address Option 0086 Word address Command data...
Page 108 INVERTER SIO Driver FRENIC-Mini Series Device Code Device Device Name Address Code (HEX) Fundamental function 0080 Word address Extension terminal function 0081 Word address Control function of frequency 0082 Word address Motor 1 parameter 0083 Word address High performance function 0084 Word address Command data...
Page 109 INVERTER SIO Driver FRENIC-Multi Series Device Code Device Device Name Address Code (HEX) Fundamental function 0080 Word address Extension terminal function 0081 Word address Control function of frequency 0082 Word address Motor 1 parameter 0083 Word address High performance function 0084 Word address Motor 2 parameter...
Page 110: Error Messages
INVERTER SIO Driver Error Messages Error messages are displayed on the Display screen as follows: "No. : Device Name: Error Message (Error Occurrence Area)". Each description is shown below. Item Description Error number. Name of the External Device where an error has occurred. Device/PLC name is the title of Device Name the External Device set with GP-Pro EX.
Page 111 INVERTER SIO Driver Error Code Description Data error • The write data is beyond the writable range. Error during writing • An attempt was made to write another function data during function writing. This error does not occur in FRENIC-Mini Series. GP-Pro EX Device/PLC Connection Manual...
Page 112 INVERTER SIO Driver GP-Pro EX Device/PLC Connection Manual...
