4.4.2.5 PG interface (5 V line driver) card (OPC-G1-PG2)
The PG interface (5 V line driver) card has the following circuits:
- Shifted phase pulse train (A, B, and Z phases) input circuit for speed feedback (5 V line driver output
type PG)
- Wire break detection circuit (Detection of wire breaks on the Z phase can be cancelled.)
- Power output circuit for feeding power to the connected PG (pulse generator)
Mounting this interface card on the FRENIC-MEGA enables the following:
(1) Speed control (vector control with speed sensor, V/f control with speed sensor, dynamic torque vector
control with speed sensor) using PG feedback signals, and servo-lock function
(2) Pulse train input as frequency commands
Ports available for the interface card
This interface card can be connected to the C-port only, out of three option connection ports (A-, B-, and
C-ports) provided on the FRENIC-MEGA.
PG interface specifications
Pulse resolution
Maximum response frequency
Pulse output system
Applicable PG
Maximum wiring length *
PG power supply *
1 Table 4.18 shows the relationship between the wiring length and the minimum diameter of wires connectable.
*
2 If the PG power current exceeds 200 mA, use an external power supply.
*
PG power
requirements
5 V 10%, 200 mA
Item
1
2
Table 4.18 Relationship Between the Wiring Length and
the Minimum Diameter of Wires Connectable
Up to 66 ft Up to 98 ft
(Up to 20 m) (Up to 30 m)
AWG24 AWG22
2
(0.25 mm ) (0.34 mm
Specifications
20 to 3000 P/R
100 kHz
Line driver (Equivalent to 26C31 or 26LS31)
Source current: +20 mA (max.)
Sink current: –20 mA (max.)
328 ft (100 m) (when using AWG16)
+5 VDC 10%, 200 mA or below
Wiring length
Up to 164 ft Up to 246 ft
(Up to 50 m) (Up to 75 m)
AWG20 AWG18
2 2
) (0.50 mm ) (0.75 mm
4-58
