M2266S/H
Technical Handbook
Table 6.4 SCSI Connector Signal Assignments
(Differential Type: M2266H)
Pin Number
Signal
Signal
Pin Number
01
Open ('1)
GND
02
03
+DBO
-DBO
04
05
+DB1
-DEl
06
07
+DB2
-DB2
08
09
+DB3
-13133
10
11
+DB4
-DB4
12
13
+DB5
-DB5
14
15
+DB6
-DB6
16
17
+DB7
-DB7
18
19
+DBP
-DBP
20
21
DIFFSENS (*2)
GND
22
23
GND
GND
24
25
TERMPWR
TERMPWR (*3)
26
27
GND
GND
28
29
+ATN
-ATN
30
31
GND
GND
32
33
+BSY
-BSY
34
35
+ACK
-ACK
36
37
+RST
-RST
38
39
+MSG
-MSG
40
41
+SEL
-SEL
42
43
+C/D
-C/D
44
45
+REQ
-REQ
46
47
+1/0
-i/O
48
49
GND
GND
50
*1
If pin 01 on the cable is used for shield ground, the shield of the connector on
the IDD is not terminated to ground.
*2
Input signal for protection of differential driver circuit.
*3
Terminating resistor power supply (jumper setup for input only, both input
and output, or open).
6-8
FS810125-01 . . . A
