MK2000 MicroKiosk Product Reference Guide

Stylus Settings

The Stylus settings include setting the Double Tap Speed and the Calibration setting. These
values are pre-configured at the factory. To recalibration the Stylus settings:
Simultaneously press and release buttons A,C and D, see Figure 1-1 on page 1-3. This
command proceeds directly to the stylus calibration.
or
1. Enter Protected mode, see MK2000 Protected Mode on page 6-2
2. From the Windows
3. Select Settings
4. Select Control Panel from the Settings window
5. Select Stylus from the Control Panel window
6. From the Stylus window set the Double Tap Speed and the touch screen
Calibration. Double Tap Speed settings are not persistent and will default back to
factory settings on bootup, see Registry Persistence on page 6-2.

Specifying an ESSID For a Wireless Network Connection

The ESSID for the Spectrum24 radio card is set using the Symbol Mobile Companion
application. It is saved with the other values of the current configuration. As always, if the
value is changed, save the new configuration.
To set the value, use the Configuration Utility (Communications - S24 802.11b - ESSID) or
perform the following steps (from Windows
1. To run Mobile Companion select Start - Programs - Tools - S24 Event Monitor.
The task tray icon to appears on the task tray.
2. Tap on the task tray icon and select Find WLANs from the menu. The Mobile
Companion program launches.
3. A list of valid networks (ESSIDs) is presented, select one and tap the Connect
button.
4. Review the Mode, Encryption, IPConfig and Power tab settings. Tap the OK button
in the upper right hand corner to close the Mobile Companion.
5. The Mobile Companion icon should exhibit a vertical green bar graph indicating
radio signal quality. Absence of this bar graph indicates lack of communication
between the MK2000 radio and an access point.
3-8
®
CE desktop, select Start
®
CE Protected Mode):
