Symbol MK2000 MicroKiosk Product Reference Manual page 163

3. Select the Monitor upgrade mode, see Figure E-8. Use the A button (Down) see
Figure E-1 on page E-3 to scroll down to the Monitor option and select the option
using the C button (Select/Action).
Platform
Application
Data
Windows
Monitor
Splash Screen
Partition Table
Auto Select
4. Select the File Media Source, see Figure E-9. The Select Transport menu is
displayed, use the A button (Down), see Figure E-1 on page E-3 to highlight
Card
and select using the C button (Select/Action).
PC Card
CF Card
Scanner/Printer
Serial, RS 485
SerialWireless - S24 DS
Previous
Top
®
CE
Figure E-8. IPL Mode Menu
Select Transport
Figure E-9. Select Transport Menu
IPL
Upgrade Procedures
Timer off
CF
Timer off
E-9
