MK2000 MicroKiosk Product Reference Guide

Defining Script Properties

Before a script is created, the script properties must be defined. This defines the type of
terminal, flash type, number of disks being created and the memory configuration of each
disk partition.
To define the script properties:
1. With TCM open, tap on the Script Window to make it the active window.
2. From the Script menu, select the Properties option.
OR
Tap on
3. From the Terminal drop-down menu, select MK2000.
4. From the Disks drop-down menu, select the number of disk partitions to be created.
Note: The options available under the disks drop-down menu changes depending
on the flash type. Some flash types only have one option for the number of
disk partitions, others have two options.
5. If two partitions have been selected under the Disk drop-down menu, the memory
configuration of the two partitions may be changed. Tap on the up or down arrow
for either of the partitions, until the memory configuration of each is set to the
desired value. As the one partition's size is changed, the other partition is
automatically changed accordingly.
6. For each disk partition, determine the Read/Write access option.
7. The Script File Path displays the path of the selected script file.
8. Select a Cushion percentage from the Cushion drop-down menu to specify the
percent of flash reserved for cushion. Choosing a higher number reduces disk
storage space, but also increases write performance on fragmented disks or disks
becoming full. To speed the writing process, select as high a number as storage
needs permit (up to 25%).
9. Tap the OK button to complete the settings.
D-4
from the tool bar. The Script Properties window displays.
