MK2000 MicroKiosk Product Reference Guide

Installation Overview

To install the MK2000 perform the following seven steps:
1. Select the mounting method:
• Wall Mount
• Pole Mount
• Desk Mount.
Refer to MK2000 Mounting on page 2-3 for mounting instructions.
2. Select the method of supplying power:
• Symbol approved AC power supply
• Power-over-Ethernet.
Refer to Power on page 2-9 for power connection options.
3. Select the data communications method:
• Wired Ethernet (10/100 Base-T cable)
• Wireless Ethernet (2Mb or 11Mb RF)
• Wired RS-485 (serial cable)
• Wired Printer/Scanner (RS-232, serial cable).
Refer to Communication Interfaces on page 2-10.
4. Select optional peripherals:
• Printer
• External hand held scanner
• Printer/Scanner (RS-232) Communication Devices.
Refer to Peripherals on page 2-16.
5. For Configuration settings, refer to the Configuration Utility on page 3-9
• To configure the communications interfaces refer to: Configuration Utility on
page 3-9, or set the communications configuration using Windows
desktop (Settings/Control Panel).
• Enter Windows
6. Add a sign to the MK2000 (if desired). Refer to Signage on page 2-16.
2-2
®
CE Desktop, see MK2000 Protected Mode on page 6-2.
®
CE,
