MK2000 Parts

The MK2000 parts are shown in front, rear and bottom views Figure 1-1 on page 1-3, Figure
1-2 on page 1-4 and Figure 1-3 on page 1-5. The parts include:
• Touch screen
•

Speakers and microphone

•

Scanner window

•

Function buttons

• External ports.

Touch Screen LCD

Full color 6.4 inch diagonal VGA active matrix LCD (640 X 480 pixels) ideal for presenting
text, graphics and motion video clips. The touch screen feature provides greater user
interaction and enhances the capabilities of custom designed applications.
Speakers and Microphone
The MK2000's speakers are ideal for multimedia applications.
The MK2000 also has a built in microphone which can be used for recording audio.
Scanner Window
The scanner window protects the scan engine.
Function Buttons
The MK2000 has four programmable function buttons (shown in Figure 1-1 on page 1-3).
The buttons are functionally identified A, B, C and D (from right to left) for reference
purposes in this document only, the alphabetic button labeling is not physically present on
the MK2000. These buttons are programmable to allow the user to perform various tasks
such as navigating through an application and making decisions when prompted. For a
detailed description of setting the buttons values, see Inactivity Manager on page 3-7.

Access Covers

The rear of the unit has three access covers that allow access to the expansion card slot
features of the MK2000. Expansion card slot access is intended only for development or
maintenance purposes and requires removal of the access cover.
