COM Port

Connector Pin-Outs

Table 2-2 through Table 2-4 describe the MK2000 connector pin outs, see Figure 1-3 on
page 1-5 for port locations.
Table 2-1. COM Port
COM
COM1
COM4
COM6
Pin 10
Figure 2-12. 10-Pin Connector Port
Port
RS-485
RS-232 (no power)
RS-232 (with 5 VDC)
10-Pin
Installation
Pin 1
2-19
