AP3965 Installation Procedures
AP3965 Installation Procedures
Use these instructions as guidelines for mounting and connecting the AP3965 easily and safely.
The installation of the AP3965 should be performed by a professional installer to ensure proper
operation and compliance with local safety guidelines.
Attach the AP3965 to a surface that can support it and withstand its environment. It can be
mounted to a wall, girder, ceiling, or pole, and the surface material can be concrete, brick, wood,
metal, or plastic.
Install the AP3965 by following these procedures:
•
Ground Connection
•
Mounting the AP3965 to a Wall
•
Attach the Mounting Bracket to the AP
•
Mounting the AP3965 to a Pole
•
Attaching Antennas
•
LAN 1/LAN 2 Connections
•
Weatherproofing the Antenna
•
Forming a Drip Loop for AP3965e Cables
Ground Connection
The ground connection for the AP3965 is located on the rear of the device. Attach a ground to
earth cable to the grounding terminal.
1.
Use the M4 ground screw assembly, with the star washer, to attach the ground wire's ring
terminal to the AP. The wire should be as close to the AP bottom as possible (see Figure
2.
Tighten the screw to a torque of 12.0 in‐lbs.
Warning: This product should be installed and serviced by a qualified licensed technician,
electrician, or electrical maintenance person familiar with its operation and the hazards involved.
ExtremeWireless™ AP3965 Installation Guide 7
Installation
2‐1).
