This chapter provides installation instructions for the ExtremeWireless™ Outdoor Access Point
AP3965.
For information about...

Unpacking the AP3965

Separately Ordered Components
AP3965 Installation Procedures
Weatherproofing the AP3965e Connections
Configuring AP3965 Channel Settings
Unpacking the AP3965
Unpack the AP3965 as follows:
1. Open the box and remove the packing material protecting the AP3965.
2. Verify that the contents of the carton contains the items listed in Table
Table 2-1 Contents of the AP3965 Carton
Quantity
1
1
Under the cardboard separation:
1
1
1
The following hardware is included:
4
4
4
4
Item
AP3965 Quick Reference
AP3965i/e model that you ordered.
H-shaped bracket that is used for mounting the AP.
Metal bracket for attaching the AP to a pole, pipe, or mast.
#10AWG ground wire with a ring terminal crimped on it (6 foot length)
Additional Hex nuts for the concrete anchors.
Concrete wall anchor assemblies that include the anchors, a flat
washer, and a hex nut.
Split Washers for the concrete anchors.
Cable clamps, all are ½" wide. Two clamps accommodate a 2.5"
maximum diameter pole and two clamps accommodate a
6"-7" diameter pole.
Installation
Refer to page...
2‐1.
ExtremeWireless™ AP3965 Installation Guide 5
