External Antennas
Table A-3 External Antennas for AP3965e
(Short Description)
30715 (WS-AO-DE13025N)*
30716 (WS-AO-5Q05025N)
30717 (WS-AO-5Q11025N)
30718 (WS-AO-DE10055N)
30720 (WS-AO-DE07180N)
30724 (WS-AO-DQ04360N)
WS-AO-5D23009N*
(WS-AO-5D23009N)
* Approved for FCC (US) and IC (Canada) only.
Part No. Frequency
Band
2.4G/5G
5G
5G
2.4G/5G
2.4G/5G
2.4G/5G
5G
Antenna 2.4G
Type Gain
Sector 13
Sector N/A
Sector N/A
Sector 10-10.5
Panel 7
Omni 4-5.5
Directional N/A
for point-to-
point
applications
ExtremeWireless™ AP3965 Installation Guide 31
Specifications
5G
Gain
Shape
11-12 25-degree, sector,
eight-feed
4.5-5 25-degree, sector,
four-feed
11-11.5 25-degree, sector,
four-feed
6-7.5 55-degree, sector,
eight-feed
6-7 100-degree, panel,
eight-feed
4-6 Omni
23 9 degree, panel, dual
polarization, point-to-
point
