Mounting the AP3965 to a Pole

To fit the mounting plate to a pole:
1. Determine the diameter of the pole.
Pole Diameter
<= 2.5" [63.5mm]
6" - 7" (178mm)
2. Attach the AP to the "H" bracket on the side that does not have the PEM stand‐offs. Tighten
the four screws to a torque of 12.0 in‐lbs.
3. Using four M4 screw assemblies, attach the pole bracket onto the "H" bracket. Tighten the
screws to 12.0 in‐lbs.
4. Position the pole mount bracket (see Figure
10

Mounting the AP3965 to a Wall

Note: Use anchors when mounting on cement walls. (Not shown above.) Mounting screws (shown
above) are not included.
Cable Clamp Size
Use small cable clamp.
Use large cable clamp
Note: For other pole diameters, provide your own stainless steel cable clamp. The band must be ½"
[12.7mm] wide.
2‐4) onto the AP mounting bracket.
AP3965 Installation Procedures
