Appendix A: Specifications; Specifications For The Ap3965 - Extreme Networks ExtremeWireless AP3965i Installation Manual

This appendix lists the specifications for the ExtremeWireless™ Outdoor Access Point AP3965.
Table A-1 Specifications for the AP3965
Item
AP Part Numbers
31016
31017
31018
31019
Enclosure material
Power source
Power consumption
Antenna
Uplink Interface
RoHS compliant
Radio Configuration
Water/Dust Proof Ratings
Operating temperature
Altitude (feet)
Relative Humidity (% RH)
Wind
Specification
WS-AP3965I-FCC
WS-AP3965I-ROW
WS-AP3965E-FCC
WS-AP3965E-ROW
Metal enclosure IP67 rated
802.3at or 802.3at+ compliant PoE
< 22W (Max.) when operating as AP only
< 55W (Max.) when operating as AP and providing power to a
second device
8 RP-N jack antenna connectors: 4 5GHz and 4 2.4GHz
8 antenna terminator caps
GbE Ethernet x1 with PoE
Yes
Dual Band Dual Concurrent 802.11ac and 802.11n
Radio 1 IEEE 802.11ac, 5GHz, 4x4:4 MU-MIMO, 20/40/80MHz
channel (up to 1733 Mbps per radio)
Radio 2 IEEE 802.11n, 2.4GHz, 4x4:4, MCS8, MCS9, 20/40MHz
channel (up to 800 Mbps per radio)
NEMA Type 6
o o o
-22 F to 158 F (-30 C to +70
(upper temperature includes solar load and elevation)
Operating: 13,000
Non-Operating: 50,000
Operating: 0%-95% (non-condensing)
Non-Operating: 0%-95% (condensing allowed on the outside
packaging)
Up to 150Mph
ExtremeWireless™ AP3965 Installation Guide 27
A
Specifications
o
C)
