Installation
Quantity
8
1
Optional: You may also need antennas, terminators, or cables. Refer to
www.extremenetworks.com/support for product numbers.
3.
Perform a visual inspection of the AP3965 for any signs of physical damage. Contact Extreme
Networks if there are any signs of damage.
Separately Ordered Components
The following accessories are available for the ExtremeWireless™ Access Point AP3965. For
ordering information, contact your Extreme Networks sales representative.
•
Antennas. Refer to "External Antennas" on page 30 and the ExtremeWireless™ External
Antenna Site Preparation and Installation Guide for more information about these antennas. This
document is available at: https://extremenetworks.com/downloads.
•
Power over Ethernet (PoE) Injector. The following 802.3at PoE injectors are recommended for
use with the AP3965:
–
–
•
Terminator cap. This part is listed as a spare item as the AP3965e is shipped with six
terminator caps. If you are not attaching six antennas to the AP3965e, you must use a
terminator cap on the antenna connector not being used.
–
•
Cables to connect the lightning protectors on the enclosure to the antennas. All cables listed
below have Standard Polarity Type‐N jack and plug connectors.
–
–
–
–
–
–
–
•
Bracket (30514) WS‐MBO‐ART01 — Outdoor articulating mounting bracket for AP3965.
6
Item
Screw assemblies, size M4, that include the screws, flat washers,
and split washers.
Ground Screw assembly, size M4, that include the screw, star
washer, and split washer.
Note:
Before mounting the AP3965, read the
PD‐9001GO‐ENT (outdoor 802.3at PoE single port midspan)
PD‐9501GO‐ENT (single port 802.3at plus outdoor midspan)
Note: When the AP3965 is powered by the Power Injector, the DATA port of the Injector should be
connected to a non PoE switch or, if the switch is PoE capable, PoE must be DISABLED on the
DATA port.
WS‐CAB‐NTERM — Terminator, Standard Polarity, Type‐N Plug, 50 OHM, 1W
WS‐CAB‐L200C20N—20 foot LMR200 cable
WS‐CAB‐L400C06N—6 foot LMR400 cable
WS‐CAB‐L400C20N—20 foot LMR400 cable
WS‐CAB‐L400C50N—50 foot LMR400 cable
WS‐CAB‐L400C75N—75 foot LMR400 cable
WS‐CAB‐L600C25N—25 foot LMR600 cable
WS‐CAB‐L600C50N—50 foot LMR600 cable
Separately Ordered Components
" on page 46
"RF Safety Distance
.
