Duplex

Layout of media transport path

The main components associated with the media path and transport with the duplex installed.

Model T650 duplex paper path

PC cartridge

Sensor (option

pass through)

Sensor (input)

Standard bin full actuator

and sensor (standard bin full)

Sensor (duplex input)

Sensor (duplex exit)

Sensor (fuser output)

Sensor (narrow media)

Sensor (duplex

double feed)

Diagnostic aids
