Dinion IP
| Installation Manual

Specifications

Type number
Standard
Active pixels
Rated supply voltage
Min illumination
Imager
Resolution
SNR
Video output
Synchronization
Shutter
Day/Night
Sens Up
Auto black
AGC
XF-DYN
DNR
Contour
BLC
White balance
Color saturation
Lens Mount
ALC lens
Power consumption
Dimensions
Weight
Tripod Mount
Operating
temperature
Controls
Bosch Security Systems | 2006-05 | V2.0
NWC-0495-10P
PAL
752x582
24 VAC or 12 VDC or Power-over-Ethernet (IEEE 802.3af)
12-28 VAC (50/60 Hz)
11-36 VDC
< 0.4 lux
< 0. 1 5 lux (in monochrome mode)
Interline CCD
540 TVL (BNC)
> 50 dB
1 Vpp, 75 Ohm
Internal or Line Lock selectable
AES (1/60 (1/50) to 1/100000), Flickerless, Fixed selectable
Color, Mono, Auto
Adjustable from OFF to 10x
On, Off selectable (maximum level selectable up to 28dB)
AGC on or off (0 dB) selectable
Automatic dynamic range enhancement level selectable
Automatic noise filtering ON/OFF selectable
Sharpness enhancement level selectable
BLC On or Off selectable, with programmable area
Automatic 2500 - 9000K (with AWB hold mode and manual
mode)
Adjustable from monochrome (0%) to 133% color
CS compatible, C-mount compatible with supplied adapter ring
Video or DC iris auto detect
< 8 W
59 x 67 x 122 mm (2.28 x 2.6 x 4.8 inch) without lens (HxWxL)
450g (0.99 lbs) without lens
Bottom (isolated) and Top ¼" 20 UNC
0° to 40° C (32° to 104° F)
OSD with softkey operation
11
NWC-0495-20P
NTSC
768x492
EN | 91
