Dinion IP - NWC-0495
Installation Manual
EN
IP Day/Night Camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dinion IP NWC-0495 and is the answer not in the manual?

Questions and answers

Related Manuals for Bosch Dinion IP NWC-0495

Summary of Contents for Bosch Dinion IP NWC-0495

  • Page 1 Dinion IP - NWC-0495 Installation Manual IP Day/Night Camera...
  • Page 2 | Installation Manual Copyright This user guide is the intellectual property of Bosch Security Systems and is protected by copyright. All rights reserved. No part of this document may be reproduced or transmitted for any purpose, by whatever means, electronic or mechanical, without the express written permission of Bosch Security Systems.

  • Page 3: Table Of Contents

    Video service monitor ...................17 Alarm connector ....................17 Lens mounting ......................17 Mounting the camera ....................18 QUICK SET-UP ...................20 Back focus adjustment ..................20 Accessing and navigating quick set-up menu ..........21 How to use the navigation keys ..............21 Bosch Security Systems | 2006-05 | V2.0...
  • Page 4 Date and time ....................37 Time server .......................38 Display stamping ....................38 Encoder Settings ....................39 Selecting an encoder profile ................40 Changing profiles ...................41 JPEG posting ....................44 Camera settings ....................45 Current profile ......................45 Profiles ......................46 ALC ........................46 Bosch Security Systems | 2006-05 | V2.0...
  • Page 5 Activating a partition for recording .............61 Continuous recording ..................62 Recording status ....................62 Alarm recording ....................63 Properties ......................64 Alarm Settings .......................67 Alarm in ......................67 Alarm connections ..................67 Video content analysis ..................69 Analysis ......................69 Analysis type ....................70 Motion detector ....................70 Bosch Security Systems | 2006-05 | V2.0...
  • Page 6 Establishing the connection .................85 Connect on alarm ...................85 Connecting with a Web browser ...............86 Closing the connection .................86 OPERATION WITH DECODER SOFTWARE ........87 MAINTENANCE ..................88 Testing the network connection .................88 Repairs ........................88 Transfer and disposal ..................88 Bosch Security Systems | 2006-05 | V2.0...
  • Page 7 Dinion IP | Installation Manual EN | vii TROUBLESHOOTING ................89 SPECIFICATIONS ................91 Dimensions ......................92 ACCESSORIES ...................93 Recommended lenses ...................93 Power transformers ..................93 GLOSSARY ..................94 Bosch Security Systems | 2006-05 | V2.0...

  • Page 8: Safety Precautions

    10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the equipment. 11. Only use attachments/accessories specified by the manufacturer. Bosch Security Systems | 2006-05 | V2.0...

  • Page 9: Fcc Information

    • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. Bosch Security Systems | 2006-05 | V2.0...
  • Page 10 Bosch could void the user's authority to operate the equipment. For additional information or to speak to a representative, please contact the Bosch Security Systems location nearest to you or visit our web site at www.boschsecuritysystems.com Only for EU countries...
  • Page 11 Dinion IP EN | x | Installation Manual Bosch Security Systems | 2006-05 | V2.0...

  • Page 12: Introduction

    • Remote control of all built-in functions via TCP/IP • Password protection to prevent unauthorized connection or configuration changes • Relay input for external sensor (such as door contacts) • Event-driven, automatic connection (for example at switch-on and for alarms) Bosch Security Systems | 2006-05 | V2.0...

  • Page 13: Type Number Overview

    MPEG viewer – Adobe Acrobat Reader • Quick install instructions Note If equipment appears to have been damaged during shipment, repack it in the original packaging and notify the shipping agent or supplier. Bosch Security Systems | 2006-05 | V2.0...

  • Page 14: System Requirements

    • Computer with Windows 2000/XP operating system, network access and reception software, for example VIDOS or DIBOS 8.0 • MPEG-4 compatible hardware decoder from Bosch Security Systems (such as VIP XD) as a receiver and a connected video monitor The minimum PC requirements are: •...

  • Page 15: Wide Dynamic Range

    MPEG4 streams per camera that can serve different purposes, for example one for local recording and one optimized for transmission over the LAN, and an additional JPEG stream for use with a PDA for example. Bosch Security Systems | 2006-05 | V2.0...

  • Page 16: Recording

    Clicking this icon stores the video sequences and they can be replayed with the MPEG viewer from Bosch Security Systems included with the package. Bosch Security Systems | 2006-05 | V2.0...

  • Page 17: Connections

    • use a shielded UTP Category 5 cable with RJ45 connectors. AL AR M • Power can be supplied to the camera via the Ethernet cable compliant with the Power-over- ET H Ethernet (IEEE 802.3af) standard. UTP Cat 5 RJ45 Bosch Security Systems | 2006-05 | V2.0...

  • Page 18: Video Service Monitor

    C-mount lenses can be mounted using the lens adapter ring. DC-iris lenses are recommended for the best picture performance. The camera automatically detects the type of lens used and optimizes performance accordingly. A spare male lens connector is provided. Bosch Security Systems | 2006-05 | V2.0...

  • Page 19: Mounting The Camera

    Mounting the camera The camera can be mounted from the top or bottom. The bottom mounting is isolated from ground. With outdoor scenes, a DC-iris lens is recommended. Bosch Security Systems | 2006-05 | V2.0...
  • Page 20 Do not obstruct the free flow of air around the camera. Note The camera becomes quite warm when operating; this is normal. However, you should take this into account when touching the camera. Bosch Security Systems | 2006-05 | V2.0...

  • Page 21: Quick Set-Up

    To adjust back focus: 1. Open the slide door at the side of the camera 2. Unlock the back focus locking button. 3. Turn the back focus adjustment as required. Bosch Security Systems | 2006-05 | V2.0...

  • Page 22: Accessing And Navigating Quick Set-Up Menu

    • Press the menu/select key to access the menus or to move to the next or previous menu. • Press the menu/select key for approximately 1.5 seconds to open the Installer menu. • Use the up or down keys to scroll up or down through a menu. Bosch Security Systems | 2006-05 | V2.0...

  • Page 23: Install Menu

    2. Access the Lens Wizard menu. 3. Set Back Focus Now is highlighted in the menu. 4. Turn the back focus adjustment as required. 5. Lock the back focus locking button. 6. Exit the menu. Bosch Security Systems | 2006-05 | V2.0...

  • Page 24: Install Ip Address Submenu

    RIGHT to change position in the address, use UP/ DOWN to select the digit. Use SELECT to exit the address edit screen. Subnet Mask Enter the Subnet mask (default 255.255.255.0) Gateway Enter a Gateway address. Exit Return to the Install menu Bosch Security Systems | 2006-05 | V2.0...

  • Page 25: Defaults

    Restoring the factory defaults may result in the loss of the IP connection. If this occurs, change the IP address of your browser to the factory default value. Only restore the factory defaults when it is absolutely necessary. Bosch Security Systems | 2006-05 | V2.0...

  • Page 26: Network Connection

    The camera must be assigned a valid IP address to operate on your network. The default address pre-set at the factory is 192.168.0.1 – Start the Web browser. – Enter the IP address of the camera as the URL. Bosch Security Systems | 2006-05 | V2.0...
  • Page 27 Note If the connection is not established, the maximum number of possible connections may already have been reached. The maximum number of connections depends on the device and network configuration. Bosch Security Systems | 2006-05 | V2.0...

  • Page 28: Operation Via The Browser

    You can view the image on a full screen. – Click on one of the MPEG-4 Stream 1, MPEG-4 Stream 2 or M-JPEG tabs below the video image to switch between the different displays for the camera image. Bosch Security Systems | 2006-05 | V2.0...

  • Page 29: Digital I/O

    Recording video sequences Sections of the video sequence that is currently being shown on the Livepage can be saved on the computer's hard drive. The sequences are recorded at the Bosch Security Systems | 2006-05 | V2.0...

  • Page 30: Running Recording Program

    – Click the symbol for recording video sequences again. Saving is terminated. Installing MPEG viewer You can play back saved video sequences using the MPEG viewer from Bosch Security Systems, which can be found on the software CD supplied. Note A corresponding MPEG ActiveX (located on the CD provided with the product) must be installed on the computer in order to play back saved video sequences using the MPEG viewer.

  • Page 31: Selecting Recordings

    • Click a partition name from the list to display the recordings for this partition. • Click a list entry. The playback for the selected sequence starts immediately in the video window. Bosch Security Systems | 2006-05 | V2.0...

  • Page 32: Controlling Playback

    You can control playback by means of the buttons below the video image. The buttons have the following functions: Start playback Pause playback Jump to start of active video sequence or to previous sequence in the list Bosch Security Systems | 2006-05 | V2.0...
  • Page 33 • Right-click a bookmark to delete it. Note Bookmarks are only valid while you are in the Recordings page; they are not saved with the sequences. As soon as you leave the page all bookmarks are deleted. Bosch Security Systems | 2006-05 | V2.0...

  • Page 34: Configuration Via The Browser

    The configuration menu tree allows all parameters of the camera to be configured. The configuration menu is recommended for expert users or system administrators. All unit parameters can be accessed in this mode. Changes that Bosch Security Systems | 2006-05 | V2.0...
  • Page 35 – Click one of the links in the sub-menu. The corresponding page is opened. The settings are changed by entering new values or by selecting a pre-defined value in a list field. Bosch Security Systems | 2006-05 | V2.0...

  • Page 36: General Settings

    Enter a name that makes it as easy as possible to identify the location unambiguously. Camera ID Each camera should be assigned a unique identifier that can be entered here as an additional means of identification. Bosch Security Systems | 2006-05 | V2.0...

  • Page 37: Password Protection

    Service or if the unit is not protected by a password. Enter the password for the selected user name here. Confirm password Re-enter the new password to rule out typing mistakes. Bosch Security Systems | 2006-05 | V2.0...

  • Page 38: Language Selection

    This is added automatically. – Enter the current time or click Synchr. PC to apply the system time from your computer to the camera. Bosch Security Systems | 2006-05 | V2.0...

  • Page 39: Time Server

    This field sets the position of the camera name overlay. It can be displayed at the Top, at the Bottom or at a position of your choice using the Custom option. Or it can be set to Off if no overlay of this information is to be shown. Bosch Security Systems | 2006-05 | V2.0...

  • Page 40: Encoder Settings

    A red rectangle indicates that the sequence (live or saved) has been manipulated. Encoder Settings For encoding the video signal, you can select two profiles and change the presets for the profiles. Bosch Security Systems | 2006-05 | V2.0...

  • Page 41: Selecting An Encoder Profile

    For ISDN connections via one B channel, resolution 352 × 288/240 pixels • Profile 7: Modem For analog modem connections at 20 kBit/s, resolution 352 × 288/240 pixels • Profile 8: GSM For GSM connections at 9,600 baud, resolution 176 × 144/120 pixels Bosch Security Systems | 2006-05 | V2.0...

  • Page 42: Changing Profiles

    Note The profiles are rather complex. They include a number of parameters that interact with one another. Therefore it is generally best to use the default Bosch Security Systems | 2006-05 | V2.0...
  • Page 43 A value of 31 results in a very high refresh rate and lower image quality. Bosch Security Systems | 2006-05 | V2.0...
  • Page 44 352 × 576/480 pixels • 2CIF 704 × 288/240 pixels • 4CIF/D1 704 × 576/480 pixels • 2/3 D1 464 × 576/480 pixels Profile reset Click Default to return the profile to the factory default values. Bosch Security Systems | 2006-05 | V2.0...

  • Page 45: Jpeg Posting

    February 16, 2006 at 12.45 p.m. and 30 seconds. JPEG posting interval Enter the interval in seconds at which the images will be sent to an FTP server. Enter zero if you do not want any images to be sent. Bosch Security Systems | 2006-05 | V2.0...

  • Page 46: Camera Settings

    The numbering follows the labeling of the video inputs on the actual unit. Camera settings Current profile Note If the camera is in monochrome mode, all color related menu items are disabled and cannot be accessed. Bosch Security Systems | 2006-05 | V2.0...

  • Page 47: Profiles

    Enter a name for the selected profile. Profile defaults Select to restore the factory defaults. A confirmation screen appears. Allow 5 seconds for the camera to optimize the picture after a profile reset. Bosch Security Systems | 2006-05 | V2.0...

  • Page 48: Dinion Ip | Installation Manual En

    – FIXED - allows a user defined shutter speed (1/60 [1/50], 1/100, 1/120, 1/ 250, 1/500, 1/1000, 1/2000, 1/5000, 1/10K). Sensitivity Up Selects the factor by which the sensitivity of the camera is increased (OFF, 2x, 3x, …, 10x). Bosch Security Systems | 2006-05 | V2.0...

  • Page 49: Day/Night

    The switching level is programmable. Set the video level at which the camera switches to monochrome operation (-15 to 0 to +15). In monochrome mode the IR filter is removed, giving full IR sensitivity. Bosch Security Systems | 2006-05 | V2.0...

  • Page 50: Enhance

    Adjusts the black level between 0 and approximately 110mV. Zero position of slider corresponds to the factory default black level. Contour Adjusts the sharpness of the picture. 0 corresponds to the default position. Bosch Security Systems | 2006-05 | V2.0...

  • Page 51: Color

    Red Gain ATW mode and AWB hold mode: adjusts the Red gain to optimize the white point. Green Gain ATW mode and AWB hold mode: adjusts the Green gain to optimize the white point. Bosch Security Systems | 2006-05 | V2.0...

  • Page 52: Back Light Compensation (Blc)

    When ON, the video level is optimized for the selected area of the image. Parts outside this area may be underexposed or overexposed (this is normal). To set-up an area for BLC, click Area Selection. Selecting an area Bosch Security Systems | 2006-05 | V2.0...

  • Page 53: Installer Options

    You can record the images from the camera in the RAM memory of the unit or in an appropriately configured iSCSI storage device. Local RAM memory is suitable for short-term recordings and pre-alarm recordings in Ring mode operation. Bosch Security Systems | 2006-05 | V2.0...

  • Page 54: Type

    • Click Advanced to view a status report with logged actions. A new window will open. • In this window, click Delete to delete all entries. The entries will be deleted immediately; you cannot undo this process. • Click the Close button to close the window. Bosch Security Systems | 2006-05 | V2.0...

  • Page 55: Iscsi Settings

    • Enter the IP address of the required iSCSI server here. • Click the Scan button. The connection to the IP address will be established. The iSCSI LUN map field contains the corresponding logical drives. Bosch Security Systems | 2006-05 | V2.0...

  • Page 56: Iscsi Lun Map

    Enter the LUN of the required drive. Target password If the drive is password protected, enter the password. Note You may not enter a new password. This is only possible by configuring the iSCSI storage device. Bosch Security Systems | 2006-05 | V2.0...

  • Page 57: Initiator Name

    • Click Advanced to view a status report with logged actions. A new window will open. • In this window, click Delete to delete all entries. The entries will be deleted immediately; you cannot undo this process. • Click the Close button to close the window. Bosch Security Systems | 2006-05 | V2.0...

  • Page 58: Partitioning

    Creating a new partition is performed using separate windows in which information is presented to you and you are led step by step through the necessary settings. Bosch Security Systems | 2006-05 | V2.0...

  • Page 59: Saving Changes

    After you have made all necessary settings, you must transfer the settings to the unit and save them. To do this, you need to quit the help in the last window using the Finish button. Bosch Security Systems | 2006-05 | V2.0...

  • Page 60: Editing A Partition

    Changes to the size of a partition (Total partition size) lead to the entire hard drive being reorganized and the loss of all recordings stored on the drive. Consequently, you should back up all Bosch Security Systems | 2006-05 | V2.0...

  • Page 61: Deleting Partitions

    0. • Click the Set button to transfer the changes to the unit and to save them. Bosch Security Systems | 2006-05 | V2.0...

  • Page 62: Recording Scheduler

    • Click the Start button to activate the currently selected partition for recording. • Click the Stop button to deactivate the currently selected partition for recording. Recordings that are currently running will be interrupted and the configuration can be modified. Bosch Security Systems | 2006-05 | V2.0...

  • Page 63: Continuous Recording

    • Click the Clear all button to delete all highlighted time intervals. Recording status The graphic indicates the recording activity in this partition. You will see an animated graphic while recording is taking place. Bosch Security Systems | 2006-05 | V2.0...

  • Page 64: Alarm Recording

    (pre- and post-alarm time). This segment in the partition functions in a similar manner to a ring buffer and is overwritten until an alarm is actually triggered. Recording occurs on the segment Bosch Security Systems | 2006-05 | V2.0...

  • Page 65: Properties

    Consequently, you should back up all important sequences on the computer's hard drive. Partition name You can enter a new name for the partition. Bosch Security Systems | 2006-05 | V2.0...
  • Page 66 Already Used alarm tracks are displayed in the graphic next to the parameter. Alarm recording Select which time intervals are to be covered for Pre-alarm and Post-alarm. Bosch Security Systems | 2006-05 | V2.0...
  • Page 67 You can delete all recordings in a partition at any time. Caution Check the recordings before deleting and back up important sequences on the computer's hard drive. • Click the Format! button to delete all recordings in the currently selected partition. Bosch Security Systems | 2006-05 | V2.0...

  • Page 68: Alarm Settings

    (compatible MPEG-4 compatible hardware receiver or computer with reception software). You can enter up to ten IP addresses which will be selected in order by the unit in case of an alarm until a connection is established. Bosch Security Systems | 2006-05 | V2.0...
  • Page 69 Select On if an active connection should be re-established automatically to one of the previously specified IP addresses after each restart, connection breakdown or network failure. Note Stream 2 is always transmitted for automatic connections. This should be taken into account when assigning the profile. Bosch Security Systems | 2006-05 | V2.0...

  • Page 70: Video Content Analysis

    Depending on the Analysis type selected and the relevant configuration, additional information overlays the video image in the small window. If you have selected MOTION+ analysis, for example, the sensor fields will light up in which movement is registered. Bosch Security Systems | 2006-05 | V2.0...

  • Page 71: Analysis Type

    Note Additional analysis algorithms with comprehensive functions such as IVMD are available from Bosch Security Systems. Motion detector For the detector to function, the following conditions must be met: • Analysis must be activated.

  • Page 72: Tamper Detection

    The options for tamper detection can only be set for fixed cameras. Dome cameras or other motorized cameras cannot be protected in this manner as the movement of the camera itself causes changes in the video image that are too great. Bosch Security Systems | 2006-05 | V2.0...
  • Page 73 Scene too dark Activate this function if tampering associated with covering the objective (for instance, by spraying paint on it) should trigger an alarm. The average brightness of the scene provides a basis for recognition. Bosch Security Systems | 2006-05 | V2.0...
  • Page 74 • Left-click the fields to be activated. Activated fields are marked red. • If necessary, click Select all to select the entire video frame for monitoring. • Right-click any fields you wish to deactivate. • Click OK to save the configuration. Bosch Security Systems | 2006-05 | V2.0...

  • Page 75: Alarm E-Mail

    You can select the data format of the alarm message. • Standard (with JPEG): e-mail with JPEG image file attachment. • SMS: e-mail in SMS format to an e-mail-to-SMS gateway (for example to send an alarm by cellphone) without an image attachment. Bosch Security Systems | 2006-05 | V2.0...

  • Page 76: Attach Jpeg From Camera

    You can choose various events that activate the output automatically. Thus, for example, it is possible to switch on a spotlight in response to a motion alarm and switch it off again when the alarm is over. Bosch Security Systems | 2006-05 | V2.0...

  • Page 77: Service Settings

    – To do this, enter the old IP address followed by /reset (for instance 192.168.0.80/reset) in the address bar of your web browser. When the camera is restarted it can only be accessed at the new IP address. Bosch Security Systems | 2006-05 | V2.0...
  • Page 78 10 or 100 MBit/s for either full or half-duplex mode (FD or HD). Note Malfunctions can occur (for example image faults) if the network capacity is not sufficient for transmission of the maximum data rate generated by the camera. Bosch Security Systems | 2006-05 | V2.0...

  • Page 79: Multicasting

    225.0.0.0 to 239.255.255.255. The multicast address can be the same for multiple streams. However, it is then necessary to use a different port in each case so that multiple data streams are not sent simultaneously using the same port and multicast address. Bosch Security Systems | 2006-05 | V2.0...

  • Page 80: Version Information

    The hardware and firmware version numbers are for information only and cannot be altered. Keep a record of these numbers in case technical assistance is required. Hardware version The hardware version number of the camera is displayed. Bosch Security Systems | 2006-05 | V2.0...

  • Page 81: Livepage Configuration

    Enter the path to a suitable background graphic in this field. The image can be stored on a local computer, a local network or at an Internet address. – Click Search if necessary to find a suitable image on the local network. Bosch Security Systems | 2006-05 | V2.0...
  • Page 82 This file can be viewed, edited and printed with any text editor or the standard Office software. File for event log Enter the path for saving the event log here. – If necessary, click Search to find a suitable folder. Bosch Security Systems | 2006-05 | V2.0...

  • Page 83: Licenses

    The firmware is installed there automatically. Thus a camera can be serviced and updated remotely without requiring a technician to make changes to the unit on Bosch Security Systems | 2006-05 | V2.0...
  • Page 84 | Installation Manual EN | 83 site. The latest firmware can be obtained from your customer service center or from the Bosch Security Systems download area. Caution Before starting the firmware update, make sure that you have selected the correct upload file! Uploading the wrong files can result in the unit no longer being addressable, requiring it to be replaced.

  • Page 85: Function Test

    • Can the camera be called remotely? • Does the camera transmit all the data required? • Does the camera respond as desired to alarm events? • Is it possible to control peripheral devices if necessary? Bosch Security Systems | 2006-05 | V2.0...

  • Page 86: Connections Between Video Servers

    With the appropriate configuration, a connection between a transmitter and a receiver is established automatically when an alarm is triggered. After a short time, the live video image from the transmitter is shown on the connected monitor. Bosch Security Systems | 2006-05 | V2.0...

  • Page 87: Connecting With A Web Browser

    – Use the Web browser to connect to the receiver. Its home page is displayed. In the title bar of the Monitor window on the page Connections, click on the X icon to end the display of the video images on the connected monitor. Bosch Security Systems | 2006-05 | V2.0...

  • Page 88: Operation With Decoder Software

    There are many options available for operation and configuration operation when using a camera with VIDOS. Refer to the software documentation for more details. The camera is also designed to operate with the DIBOS 8.0 digital recorder platform. Bosch Security Systems | 2006-05 | V2.0...

  • Page 89: Maintenance

    Defective or superfluous devices and parts should be disposed of professionally or taken to your local collection point for hazardous materials. Bosch Security Systems | 2006-05 | V2.0...

  • Page 90: Troubleshooting

    Troubleshooting If you cannot resolve a fault, please contact your supplier or system integrator or go direct to Bosch Security Systems Customer Service. The version numbers of the internal processors can be viewed on a special page. Please note this information before contacting Customer Service.
  • Page 91 Service and replace if necessary. firmware upload. file. Incorrect update file. Enter the IP address followed by / main.htm in your web browser and repeat the upload. Bosch Security Systems | 2006-05 | V2.0...

  • Page 92: Specifications

    59 x 67 x 122 mm (2.28 x 2.6 x 4.8 inch) without lens (HxWxL) Weight 450g (0.99 lbs) without lens Tripod Mount Bottom (isolated) and Top ¼" 20 UNC Operating 0° to 40° C (32° to 104° F) temperature Controls OSD with softkey operation Bosch Security Systems | 2006-05 | V2.0...

  • Page 93: Dimensions

    1 ... 50/60 fields/s adjustable (PAL/NTSC) Field/image-based coding Network protocols TCP, UDP, IP, HTTP, IGMP V2, ICMP, ARP Dimensions (4.646") (3.346") (1.339") 1/4"-20 UNC 1/4"-20 UNC (1.889") (4.843") (2.638") Dimensions in mm (inches). Bosch Security Systems | 2006-05 | V2.0...

  • Page 94: Accessories

    1/3-inch, 3.0 - 8 mm, DC-iris, CS-mount F/1.0-360, 4-pin Power transformers • TC 120PS Power Supply Unit – 110-120 VAC/15 VDC, 50/60 Hz, 300mA • TC 220PS Power Supply Unit – 230 VAC/15 VDC, 50 Hz, 10 VA Bosch Security Systems | 2006-05 | V2.0...

  • Page 95: Glossary

    "209. 1 30.2. 1 93". ISDN Integrated Services Digital Network JPEG An encoding process for still images (Joint Photographic Experts Group) kBit/s Kilobits per second, the actual data rate Bosch Security Systems | 2006-05 | V2.0...
  • Page 96 Time-To-Live; life cycle of a data packet in station transfers User Datagram Protocol Uniform Resource Locator Unshielded Twisted Pair See wide area network Wide area network A long distance link used to extend or connect remotely located local area networks Bosch Security Systems | 2006-05 | V2.0...
  • Page 97 Dinion IP EN | 96 | Installation Manual Bosch Security Systems | 2006-05 | V2.0...
  • Page 98 Dinion IP | Installation Manual Bosch Security Systems | 2006-05...
  • Page 99 Bosch Sicherheitssysteme GmbH Bosch Security Systems B.V. Ludwig-Bölkow-Allee P.O. Box 80002 85521 Ottobrunn 5600 JB Eindhoven Germany The Netherlands www.bosch-sicherheitssysteme.de www.boschsecuritysystems.com 9922 141 0xxxxx 06-15 © 2006 Bosch Security Systems B.V. Subject to change. Printed in Portugal.
