Dinion IP
| Installation Manual
Video level
Adjust the video output level (-15 to 0 to +15).
Peak Average
Adjust the balance between peak and average video control (-15 to 0 to +15).
At -15 the camera controls the average video level, at +15 the camera controls the
peak video level.
ALC Speed
Adjust the speed of the video level control loop (Slow, Medium or Fast).

Shutter/AGC

Shutter
– AES (auto-shutter) - the camera automatically sets the optimum shutter speed
for manual iris lenses. The camera tries to maintain the selected shutter speed
(1/60 [1/50], 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/5000, 1/10K) as
long as the light level of the scene permits.
– FL - flickerless mode avoids interference from light sources (recommended
for use with video iris or DC iris lenses only).
– FIXED - allows a user defined shutter speed (1/60 [1/50], 1/100, 1/120, 1/
250, 1/500, 1/1000, 1/2000, 1/5000, 1/10K).
Sensitivity Up
Selects the factor by which the sensitivity of the camera is increased (OFF, 2x, 3x,
..., 10x).
Bosch Security Systems | 2006-05 | V2.0
EN | 47
