Dinion IP
NWC-495-10P | NWC-495-20P
en
Operating Instructions

Advertisement

Table of Contents
loading

Summary of Contents for Bosch NWC-0495-20P

  • Page 1 Dinion IP NWC-495-10P | NWC-495-20P Operating Instructions...
  • Page 3: Table Of Contents

    Intelligent Video Motion Detection Connections Power Network (and power) Video service monitor Alarm connector Mounting Lens mounting Mounting the camera Quick set-up Back focus adjustment Accessing and navigating quick set-up menu Bosch Security Systems Operating Instructions | en 3 V 2.5 | 2007.6...
  • Page 4 Configuration via the browser Settings General Settings 7.2.1 Camera identification 7.2.2 Password protection 7.2.3 Language selection 7.2.4 Date and time 7.2.5 Time server Display Settings 7.3.1 Display stamping docnumber | V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 5: Dinion Ip | En

    Creating a partition 7.8.2 Partition status 7.8.3 Editing a partition 7.8.4 Deleting partitions Recording profile 7.10 Recording scheduler 7.10.1 Activating recording 7.10.2 Recording status 7.11 Alarm Settings 7.11.1 Alarm in Bosch Security Systems Operating Instructions | en 5 V 2.5 | 2007.6...
  • Page 6 7.16 Function test Connections between video servers 8.0.1 Installation 8.0.2 Establishing the connection 8.0.3 Connect on alarm 8.0.4 Connecting with a Web browser 8.0.5 Closing the connection docnumber | V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 7 Operation with decoder software Maintenance 10.1 Testing the network connection 10.2 Repairs 10.2.1 Transfer and disposal Troubleshooting Specifications 12.1 Dimensions (mm/inch) 12.2 Accessories 12.2.1 Recommended lenses 12.2.2 Power transformers Glossary Bosch Security Systems Operating Instructions | en 7 V 2.5 | 2007.6...
  • Page 8: Important Safety Instructions

    Power cord and plug protection - Protect the plug and power cord from foot traffic, being pinched by items placed upon or against them at electrical outlets, and its docnumber | V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 9 – – – – Bosch Security Systems For battery powered units, refer to the operating instructions. For external power supplied units, use only the rec- ommended or approved power supplies. For limited power source units, this power source must comply with EN60950.
  • Page 10 14. Attachments, changes, or modifications - Only use attach- ments/accessories specified by the manufacturer. Any change or modification of the equipment, not expressly approved by Bosch, could void the warrantee or, in the case of an authorization agreement, authority to operate the equipment.
  • Page 11 The exclamation point within the triangle sign alerts the user to important instructions accompanying the unit. CAUTION! Alerts the user to the risk of damage to the unit. NOTE! General sign for notes. Calls attention to important information. Bosch Security Systems Operating Instructions | en 11 V 2.5 | 2007.6...
  • Page 12 Video loss Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be held liable for any damage that results from missing video information. To minimize the risk of lost digital information, Bosch Security Systems recom- mends multiple, redundant recording systems, and a procedure to back up all analog and digital information.
  • Page 13 UL MAKES NO REPRESENTATIONS, WARRANTIES, OR CERTIFI- CATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNC- TIONS OF THIS PRODUCT. Bosch Security Systems reorient or relocate the receiving antenna; increase the separation between the equipment and receiver;...
  • Page 14 Please dispose of these units at an environmentally compatible recycling facility, per European Directive 2002/96/EC. Bosch has a strong commitment towards the environment. This unit has been designed to respect the environment as much as possible.
  • Page 15: Introduction

    – Fast, convenient configuration using the integrated Web server and a browser – Firmware update through flash memory – Convenient upload and download of configuration data Bosch Security Systems Operating Instructions Introduction | en 15 V 2.5 | 2007.6...
  • Page 16: Type Number Overview

    24 VAC or 12 VDC (use class 2 power supply) or PoE (IEEE 802.3af) 1/3" Day/Night IP camera Manual System requirements Configuration Manager MPEG ActiveX control DirextX control Microsoft Internet Explorer Sun JVM Player and archive player Adobe Acrobat Reader Operating Instructions Dinion IP NWC-0495-20P 60 Hz Bosch Security Systems...
  • Page 17: System Requirements

    VIDOS, BMVS or DIBOS 8.0 – MPEG-4 compatible hardware decoder from Bosch Security Systems (such as VIP XD) as a receiver and a connected video monitor The minimum PC requirements are: – Operating platform: A PC running Windows 2000 or Win- dows XP with IE 6.0...
  • Page 18: Wide Dynamic Range

    The camera uses the MPEG-4 compression standard. Thanks to efficient encoding, the data rate remains low even with high image quality and can also be adapted to local conditions within wide limits. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 19: Tri Streaming

    Bosch Security Systems Operating Instructions Introduction | en 19 V 2.5 | 2007.6...
  • Page 20: Snapshots

    Clicking this icon stores the video sequences and they can be replayed with the Player from Bosch Security Systems included with the package. 1.4.14 Intelligent Video Motion Detection...
  • Page 21: Connections

    10mm A LA R M ET H Fig. 2.1 Power connection Bosch Security Systems - use a class 2 power supply - 24 VAC or 12 VDC - push in the tabs to open the quick-connectors (these connections are not polarity sensitive).
  • Page 22: Network (And Power)

    - connect a service monitor to the composite video BNC connector to aid installation. - a monitor connected close to the camera via this connection can also be used in parallel with remote PC viewing. Operating Instructions Dinion IP Bosch Security Systems...
  • Page 23: Alarm Connector

    Relay out contact 2 Alarm Pin 4 Pin 1 Fig. 2.4 Network and power connection Bosch Security Systems - Max. wire diameter AWG 22-28 for both stranded and solid. - Default relay position n.o. (normally open), no alarm. - Alarm output relay switching capability: Max voltage 30VAC or +40VDC.
  • Page 24: Mounting

    The lens circuit is automatically disabled to avoid internal damage. Remove the lens connector and check the pin connections. V 2.5 | 2007.6 Bosch DC iris lens Damp - Damp + Drive + Drive - Operating Instructions Dinion IP Bosch Bosch Security Systems...
  • Page 25: Mounting The Camera

    Do not obstruct the free flow of air around the camera. NOTE! The camera becomes quite warm when operating; this is normal. However, you should take this into account when touching the camera. Bosch Security Systems Operating Instructions Mounting | en 25 V 2.5 | 2007.6...
  • Page 26: Quick Set-Up

    To adjust back focus: Open the slide door at the side of the camera Unlock the back focus locking button. Turn the back focus adjustment as required. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 27: Accessing And Navigating Quick Set-Up Menu

    Press the menu/select key to access the menus or to move to the next or previous menu. – Press the menu/select key for approximately 1.5 seconds to open the Installer menu. Bosch Security Systems Up key Lock Down key Operating Instructions...
  • Page 28: Install Menu

    (Video iris lenses only). The level detector indica- tor must be set to the center by adjusting the level potentiometer on the lens, to obtain the best pic- ture performance. Return to the INSTALL menu Operating Instructions Dinion IP Bosch Security Systems...
  • Page 29: Adjustment Procedure Manual-Iris Lens

    The factory default IP address is 192.168.0.1 Function Selection IP Address Bosch Security Systems Description Enter an IP address for the camera. Use LEFT/RIGHT to change position in the address, use UP/DOWN to select the digit. Use SELECT to exit the address edit screen.
  • Page 30: Defaults

    Only restore the factory defaults when it is absolutely necessary. V 2.5 | 2007.6 Enter the Subnet mask (default 255.255.255.0) Enter a Gateway address. Return to the Install menu Operating Instructions Dinion IP Bosch Security Systems...
  • Page 31: Network Connection

    192.168.0.1 Start the Web browser. Enter the IP address of the camera as the URL. Bosch Security Systems Insert the CD into the CD-ROM drive of the computer. If the CD does not start automatically, open the root directory of the CD in Windows Explorer and double click MPEGAx.exe.
  • Page 32 Depending on the device and network configuration, up to 20 web browsers, or 50 VIDOS or BVMS connections are supported. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 33: Secured Network

    Only after these have been configured can you communicate with the camera via the network. Bosch Security Systems Operating Instructions Network connection | en 33 V 2.5 | 2007.6...
  • Page 34: Operation Via The Browser

    6.1.1 Processor load When accessing the camera with a browser, the processor load is displayed in the upper right of the window next to the Bosch logo. Move the mouse cursor over the icons to display numerical val- ues. This information can help with problem solving or when fine tuning the device.
  • Page 35: Image Selection

    Individual images from the video sequence that is currently being shown on the Livepage can be saved in JPEG format on the computer's hard drive. Bosch Security Systems Operation via the browser | en 35 Operating Instructions V 2.5 | 2007.6...
  • Page 36: Recording Video Sequences

    Click the symbol for recording video sequences again. Sav- ing is terminated. Installing Player You can play back saved video sequences using the Player from Bosch Security Systems, which can be found on the software CD supplied. NOTE! A corresponding MPEG ActiveX (located on the CD provided with the product) must be installed on the computer in order to play back saved video sequences using the Player.
  • Page 37: Running Recording Program

    (see “Recording” on page 61). – Click Recordings in the navigation bar in the upper section of the window. The playback page appears. Bosch Security Systems Operation via the browser | en 37 Operating Instructions to indi-...
  • Page 38: Selecting Recordings

    6.2.2 Controlling playback You will see a time bar below the video image for quick orienta- tion. If a particular sequence has been selected for playback by V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 39 You can use the slide control to control playback speed and fast forward/rewind: positioning in the middle indicates playback at Bosch Security Systems Operation via the browser | en 39 Operating Instructions V 2.5 | 2007.6...
  • Page 40 Bookmarks are only valid while you are in the Recordings page; they are not saved with the sequences. As soon as you leave the page all bookmarks are deleted. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 41: Configuration Via The Browser

    Changes that influence the fun- damental functioning of the unit (for example firmware updates) can only be made using the configuration menu. Bosch Security Systems Configuration via the browser | en 41 Operating Instructions...
  • Page 42 Save the changes made in each window by clicking Set. Clicking the Set button saves only the settings in the current window. Changes in any other fields are ignored. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 43: General Settings

    Camera ID Each camera should be assigned a unique identifier that can be entered here as an additional means of identification. Bosch Security Systems Configuration via the browser | en 43 Operating Instructions V 2.5 | 2007.6...
  • Page 44: Password Protection

    Service or if the unit is not pro- tected by a password. Enter the password for the selected user name here. Confirm password Re-enter the new password to rule out typing mistakes. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 45: Language Selection

    This is added automatically. Enter the current time or click Synchr. PC to apply the sys- tem time from your computer to the camera. Bosch Security Systems Configuration via the browser | en 45 Operating Instructions V 2.5 | 2007.6...
  • Page 46: Time Server

    If there are empty lines at the bottom of the table, for example after deletions, you can add new data by marking the row and selecting values from the list boxes. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 47: Display Settings

    HyperTerminal, using the Custom option. Or it can be set to Off if no overlay of this information is to be shown. Bosch Security Systems Configuration via the browser | en 47 Operating Instructions...
  • Page 48: Encoder Settings

    You can adapt the MPEG-4 data transmission to the operating environment (for example network structure, bandwidth, data V 2.5 | 2007.6 If you have selected the Custom option, additional fields are displayed to specify the exact position (Position (XY):). Operating Instructions Dinion IP Bosch Security Systems...
  • Page 49 You will see a preview for each data stream in the right section of the window. The preview of the data stream currently selected is marked by a frame. Various additional items of infor- Bosch Security Systems Configuration via the browser | en 49 Operating Instructions...
  • Page 50: Changing Profiles

    Therefore it is generally best to use the default profiles. The profiles should only be changed if you are completely familiar with all the configuration options. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 51 1/2 D1 352 × 576/480 pixels – 2CIF 704 × 288/240 pixels – 4CIF/D1 704 × 576/480 pixels – 2/3 D1 464 × 576/480 pixels Bosch Security Systems Configuration via the browser | en 51 Operating Instructions V 2.5 | 2007.6...
  • Page 52 4 and 31 on a slide bar. The value 4 represents the best quality with, if necessary, a lower frame refresh rate depending on the settings for the maximum data V 2.5 | 2007.6 Operating Instructions Bosch Security Systems...
  • Page 53: Jpeg Posting

    When setting this parameter, please ensure that the date and time of the unit are always correctly set. Example: the file snap021606_124530.jpg Bosch Security Systems Configuration via the browser | en 53 Operating Instructions V 2.5 | 2007.6...
  • Page 54 Check the box to activate one or more camera inputs for the JPEG image. An enabled camera input is indicated by a check mark. NOTE! The numbering follows the labeling of the video inputs on the actual unit. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 55: Camera Settings

    At -15 the camera controls the average video level, at +15 the camera controls the peak video level. ALC Speed Adjust the speed of the video level control loop (Slow, Medium or Fast). Bosch Security Systems Configuration via the browser | en 55 Operating Instructions V 2.5 | 2007.6...
  • Page 56: Shutter/Agc

    Gain In AGC mode the camera automatically sets the gain to the low- est possible value needed to maintain a good picture. Select V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 57: Day/Night

    Color: the camera gives color pictures as long as the light level permits. The camera recognizes IR illuminated scenes to prevent unwanted switching to color mode. There are two modes for IR contrast: Bosch Security Systems Configuration via the browser | en 57 Operating Instructions V 2.5 | 2007.6...
  • Page 58: Enhance

    In AUTO mode the camera automatically reduces the noise in the picture. This may cause some motion blur on moving objects. Enhanced Dynamic Range In XF-DYN mode the camera automatically optimizes the con- trast in the picture. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 59: Color

    ATW mode and AWB hold mode: adjusts the B gain to optimize around the white point. Saturation Adjusts the color saturation. -15 gives a monochrome image Bosch Security Systems Configuration via the browser | en 59 Operating Instructions V 2.5 | 2007.6...
  • Page 60: Back Light Compensation (Blc)

    Use your mouse to select an area in the picture. BLC Level adjusts the balance between the selected BLC area and its surrounding. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 61: Installer Options

    The VRM is an external program that configures recording tasks for video servers. For further information, con- tact your local customer service at Bosch Security Systems. Bosch Security Systems A confirmation screen appears. Allow 5 seconds for the camera to optimize the picture after a mode reset.
  • Page 62: Type

    Click Log to view a status report with logged actions. A new window opens. In this window, click Delete to delete all entries. Entries are deleted immediately; you cannot undo this process. Click Close to close the window. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 63: Iscsi Settings

    Enter the IP address of the required iSCSI server here. Click Connect. The connection to the IP address is estab- lished. The iSCSI LUN map field contains the correspond- ing logical drives. Bosch Security Systems Configuration via the browser | en 63 Operating Instructions V 2.5 | 2007.6...
  • Page 64: Iscsi Lun Map

    Target password If the drive is password protected, enter the password. NOTE! You may not enter a new password. This is only possible by configuring the iSCSI storage device. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 65: Initiator Name

    In this window, click Delete to delete all entries. Entries are deleted immediately; you cannot undo this process. Click Close to close the window. Bosch Security Systems Configuration via the browser | en 65 Operating Instructions V 2.5 | 2007.6...
  • Page 66: Partitioning

    Click Create partition to start the wizard for creating parti- tions. The first window appears. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 67 All modifications to settings are only effective if you complete the configuration in the last window by clicking Finish. Switch to the last window if necessary. Bosch Security Systems Configuration via the browser | en 67 Operating Instructions V 2.5 | 2007.6...
  • Page 68: Partition Status

    V 2.5 | 2007.6 A window opens showing information on the high- lighted partition. This window provides information about the current configuration of the partition. No changes can be made here. Operating Instructions Dinion IP Bosch Security Systems...
  • Page 69 Number of alarm tracks NOTE! Alarm tracks must be set up for alarm recording. Bosch Security Systems A new window with the entries for the selected parti- tion is opened. You can modify the configuration in the Partition properties window.
  • Page 70 You can delete all recordings in a partition at any time. CAUTION! Check the recordings before deleting and back-up important sequences on the computer's hard drive. – Click Format! to delete all recordings in the current parti- tion. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 71: Deleting Partitions

    Modify the names of the recording profiles on the tabs in the Recording planner page. Bosch Security Systems Configuration via the browser | en 71 Operating Instructions...
  • Page 72 Select the encoder profile to use for continual recording. NOTE! The recording profile can deviate from the standard setting Active profile and is only used during an active recording. Encoder Select which data stream to record here. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 73 The Standard profile option sets this to the same as the standard profile. Motion detection/video alarm Select the alarm type that is to trigger a recording. Bosch Security Systems Configuration via the browser | en 73 Operating Instructions V 2.5 | 2007.6...
  • Page 74: Recording Scheduler

    Use the right mouse button to deselect any of the intervals. Click Select all to select all of the intervals to be assigned to the selected profile. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 75: Activating Recording

    Recording scheduler are deactivated and the configura- tion cannot be modified. You can terminate recording at any time to modify the configuration. Click Start to activate the recording schedule. Bosch Security Systems Configuration via the browser | en 75 Operating Instructions V 2.5 | 2007.6...
  • Page 76: Recording Status

    IP connection. Name You can enter a name for each alarm input, which is then dis- played below the icon for the alarm input on the Livepage dur- ing configuration. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 77: Alarm Connections

    Only ten passwords can be defined here. You can define a gen- eral password if more than ten connections are required, for Bosch Security Systems Configuration via the browser | en 77 Operating Instructions V 2.5 | 2007.6...
  • Page 78 IP addresses after each restart, connection breakdown or network failure. NOTE! Stream 2 is always transmitted for automatic connections. This should be taken into account when assigning the profile. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 79: Vca

    If you select Motion+ analysis, for example, the sensor fields in which movement is registered light up. Bosch Security Systems Configuration via the browser | en 79 Operating Instructions V 2.5 | 2007.6...
  • Page 80: Analysis Type

    The current alarm status is displayed for information purposes. NOTE! Additional analysis algorithms with comprehensive functions such as IVMD are available from Bosch Security Systems. 7.12.3 Motion detector Motion detection is available for the Motion+ analysis type. For the detector to function, the following conditions must be met: –...
  • Page 81: Sensitivity

    If necessary, click Clear all first to clear the current selec- tion (fields marked red). Left-click the fields to be activated. Activated fields are marked red. Bosch Security Systems Configuration via the browser | en 81 Operating Instructions V 2.5 | 2007.6...
  • Page 82: Tamper Detection

    Scene too bright Activate this function if tampering associated with exposure to extreme light (for instance, shining a flashlight directly on the V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 83 Select only those areas for reference monitoring in which no movement takes place and that are always evenly lit, as false alarms could otherwise be triggered. Bosch Security Systems Configuration via the browser | en 83 Operating Instructions V 2.5 | 2007.6...
  • Page 84: Alarm E-Mail

    7.13.2 Mail server IP address Enter the IP address of a mail server that operates on the SMTP standard (Simple Mail Transfer Protocol). Outgoing e-mails are V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 85: Layout

    Test the e-mail function by clicking Send now. An alarm e-mail is immediately created and sent. 7.14 Relay Settings Here, you can make the settings for the alarm sources and alarm connections. Bosch Security Systems Configuration via the browser | en 85 Operating Instructions V 2.5 | 2007.6...
  • Page 86: Alarm Out

    Trigger relay Click the button to switch the relay manually (for example for testing purposes or to operate a door opener). V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 87: Service Settings

    – Click Set after entering a new IP address. – Bosch Security Systems To do this, enter the old IP address followed by / reset (for instance 192.168.0.80/reset) in the address bar of your web browser. When the camera is...
  • Page 88 Also ensure that Java application support is activated (in the Java Plug-in Con- trol Panel of the Windows Control Panel). V 2.5 | 2007.6 restarted it can only be accessed at the new IP address. Operating Instructions Dinion IP Bosch Security Systems...
  • Page 89 1. SNMP host address / 2. SNMP host address The camera supports the SNMP V2 (Simple Network Manage- ment Protocol) for managing and monitoring network compo- Bosch Security Systems Configuration via the browser | en 89 Operating Instructions V 2.5 | 2007.6...
  • Page 90: Multicasting

    VIDOS or BVMS, will not find the camera. 7.15.2 Multicasting In addition to a 1:1 connection between an encoder and a sin- gle receiver (unicast), the camera can enable multiple receivers V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 91 NOTE! Duplication of data places a heavy demand on the CPU and can lead to impairment of the image quality under certain circumstances. Bosch Security Systems Configuration via the browser | en 91 Operating Instructions V 2.5 | 2007.6...
  • Page 92: Encryption

    Click an entry to select it (select multiple entries by hold- ing the control key while clicking). Click Clear keys to delete the keys for the marked streams. These streams are no longer encrypted. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 93: Version Information

    Keep this information at hand when seeking technical support. For example, you can copy the hardware and firmware version numbers to paste them into an e-mail. Bosch Security Systems Configuration via the browser | en 93 Operating Instructions V 2.5 | 2007.6...
  • Page 94: Livepage Configuration

    Mark the check boxes for the information to be displayed on the Livepage. The selected elements are checked. Check on the Livepage whether and how the desired items are displayed. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 95 VCA are displayed in the live video stream. Show event log The event messages are displayed with the date and time in a field next to the video image. Bosch Security Systems Configuration via the browser | en 95 Operating Instructions V 2.5 | 2007.6...
  • Page 96: Licenses

    Livepage. – If necessary, click Search to find a suitable folder. 7.15.6 Licenses You can enter the activation key to release additional functions or software modules. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 97: Maintenance

    The latest firmware can be obtained from your customer service center or from the Bosch Security Systems download area. Bosch Security Systems Configuration via the browser | en 97 Operating Instructions V 2.5 | 2007.6...
  • Page 98 You can save configuration data for the camera to a computer and load saved configuration data from a computer to the unit. Click Download; a dialog box appears. Follow the instructions to save the current settings. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 99: Function Test

    Does the camera transmit all the data required? – Does the camera respond as desired to alarm events? – Is it possible to control peripheral devices if necessary? Bosch Security Systems Configuration via the browser | en 99 Operating Instructions V 2.5 | 2007.6...
  • Page 100: Connections Between Video Servers

    This connection option can also be used to connect a transmit- ter and a compatible receiver using a switch connected to the alarm input. In this case, no computer is needed to establish the connection. V 2.5 | 2007.6 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 101: Connecting With A Web Browser

    In the title bar of the Monitor window on the page Connec- tions, click the X icon to end the display of the video images on the connected monitor. Bosch Security Systems Connections between video servers | en 101 Operating Instructions...
  • Page 102: Operation With Decoder Software

    IP video security solution that provides seamless management of digital video, audio and data across any IP net- work. It is designed to work with Bosch CCTV products as part of a total video security management system. Now you can inte- grate your existing components into one easy-to-manage sys- tem, or use Bosch’s full-line capabilities and benefit from a...
  • Page 103: Maintenance

    Defective or superfluous devices and parts should be disposed of profes- sionally or taken to your local collection point for hazardous materials. Bosch Security Systems Operating Instructions Maintenance | en 103 V 2.5 | 2007.6...
  • Page 104: Troubleshooting

    104 en | Troubleshooting Troubleshooting If you cannot resolve a fault, please contact your supplier or system integrator or go direct to Bosch Security Systems Cus- tomer Service. The version numbers of the internal processors can be viewed on a special page. Please note this information before contact- ing Customer Service.
  • Page 105 LUN mapping not The iSCSI system does not possible. support the use of initiator identification. Bosch Security Systems Possible causes Select possible alarm sources on page. Specify the desired alarm response on the tions sary change the IP address.
  • Page 106: Specifications

    LAN interface 1 × Ethernet 10/100 Base-T, automatic adaptation, half/full duplex, RJ-45 Video encoding proto- MPEG-4, JPEG cols Video data rate 9,600 KBit/s ... 10 MBit/s V 2.5 | 2007.6 NWC-0495-20P NTSC 768x492 Operating Instructions Dinion IP Bosch Security Systems...
  • Page 107 120 ms (PAL/NTSC, MPEG-4, no network delay) Image refresh rate 1 ... 50/60 fields/s adjustable (PAL/NTSC) Field/image-based coding Network protocols TCP, UDP, IP, HTTP, IGMP V2, ICMP, ARP Bosch Security Systems Operating Instructions Specifications | en 107 V 2.5 | 2007.6...
  • Page 108: Dimensions (Mm/Inch)

    108 en | Specifications 12.1 Dimensions (mm/inch) V 2.5 | 2007.6 (4.646") (3.346") (1.339") 1/4"-20 UNC 1/4"-20 UNC (1.889") (4.843") (2.638") Dimensions in mm (inches). Operating Instructions Dinion IP Bosch Security Systems...
  • Page 109: Accessories

    Power transformers TC 120PS Power Supply Unit – 110-120 VAC/15 VDC, 50/60 Hz, 300mA TC 220PS Power Supply Unit – 230 VAC/15 VDC, 50 Hz, 10 VA Bosch Security Systems Operating Instructions Specifications | en 109 V 2.5 | 2007.6...
  • Page 110: Glossary

    Identification: a machine-readable character sequence Institute of Electrical and Electronics Engineers Internet Group Management Protocol The main protocol used on the Internet, normally in con- junction with the Transfer Control Protocol (TCP): TCP/IP Operating Instructions Dinion IP Bosch Security Systems...
  • Page 111 Parameters QCIF RADIUS server RFC 868 Bosch Security Systems See Internet Protocol A 4-byte number uniquely defining each device on the Inter- net. It is usually written in dotted decimal notation with full stops separating the bytes, for example "209.130.2.193".
  • Page 112 Time-To-Live; life cycle of a data packet in station transfers User Datagram Protocol Uniform Resource Locator Unshielded Twisted Pair See wide area network A long distance link used to extend or connect remotely located local area networks Operating Instructions Dinion IP Bosch Security Systems...
  • Page 113 Dinion IP Glossary | en 113 Bosch Security Systems Operating Instructions V 2.5 | 2007.6...
  • Page 115 Bosch Security Systems Robert-Koch-Straße 100 D-85521 Ottobrunn Germany Telefon 089 6290-0 089 6290-1020 www.boschsecuritysystems.com © Bosch Security Systems, 2007...
