Altronix HubWayLD8Di/16Di Active UTP Transceiver Hub w/Integral Isolated Camera Power transmits UTP video,
RS422/RS485 data and power over a single CAT-5 or higher structured cable. Unit provides 8 or 16 camera channels in
a space saving 1U EIA 19" rack mount chassis which may be rack, wall or shelf mounted. Video transmission range is
up to 3000 ft. max. per channel. Units are compatible with AC and/or DC fixed or PTZ cameras when utilizing Altronix
HubWayAv, HubWayAv2, HubWayDv or HubWayDvi Video Balun/Combiners. In addition, the unit features individu-
ally selectable 24VAC or 28VAC PTC protected outputs with surge suppression. An optional HubSat4D Passive UTP
Transceiver Hub with Integral Camera Power can be used as an accessory module to transmit video from up to 4 cameras
over a single CAT-5 or higher structured cable back to the HubWayLD8Di/16Di. In addition, the HubSat4D provides
power to these cameras locally to eliminate the possibility of voltage drop associated with long cable runs.
HubWayLD8Di/LD82Di/LD83Di
Input:
• 115VAC 60Hz, 2.5 amp or
230VAC 50/60Hz, 1.5 amp.
Video:
• Eight (8) channels of video over twisted pair up to
a distance of 3000 ft. per channel.
• Eight (8) 75 ohm video outputs.
Power:
• Unit provides up to 1 amp max. per channel not to
exceed a total of 8 amp (150VA) maximum current.
Agency Listings:
• UL Listed for Commercial CCTV Equipment (UL 2044).
CUL Listed - CSA Standard C22.2 No.1-04, Audio,
Video and Similar Equipment.
Data:
• RS422/RS485 data inputs.
Power:
• Individually selectable 24VAC or 28VAC power outputs
with OFF position.
• Individual electronically isolated PTC outputs.
• PTCs are rated @ 1 amp per channel.
• Surge suppression.
Visual Indicators:
• AC input power indicator.
• Video signal and power LED indicators.
HubWayLD82Di
• HubWayLD8Di with eight (8) UL Listed Accessory
HubWayAv Video Balun/Combiners for 24VAC Cameras.
HubWayLD83Di
• HubWayLD8Di with eight (8) UL Listed Accessory
HubWayDv Video Balun/Combiners for 12VDC Cameras.
WARNING: To reduce the risk of fire or electric shock do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to all local codes.
1. Set the input voltage selector switch located on the left side of the HubWayLD8Di/LD16Di unit (facing front panel)
for 115VAC or 230VAC operation (Fig. 1k, pg. 4).
2. Attach mounting brackets to HubWayLDi unit for rack or wall mount installation (Figs. 6-7, pg. 8). Affix rubber pads
to HubWayLD for shelf installation (Fig. 8, pg. 8).
- 2 -
Overview:
HubWayLD Specifica tions:
HubWayLD16Di/LD162Di/LD163Di
Input:
• 115VAC 60Hz, 5 amp or
230VAC 50/60Hz, 2.5 amp.
Video:
• Sixteen (16) channels of video over twisted pair up to
a distance of 3000 ft. per channel.
• Sixteen (16) 75 ohm video outputs.
Power:
• Unit provides up to 1 amp max. per channel not to
exceed a total of 16 amp (300VA) maximum current.
Common Specifica tions:
Features:
• Picture and Gain control.
• Illuminated master power disconnect circuit breaker
with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
• Unit can be rack, wall or shelf mounted.
• 1U rack mount chassis for use in standard EIA 19" rack.
Accessories:
• Video Balun/Combiners:
- HubWayAv - for use with 24VAC cameras.
- HubWayAv2 - for use with 24VAC cameras.
- HubWayDv - for use with 12VDC cameras.
- HubWayDvi - for use with non-isolated 12VDC cameras.
• Optional HubSat4D allows transmission of up to
four (4) video signals over a single CAT-5 or higher
structured cable.
Additional Models:
HubWayLD162Di
• HubWayLD16Di with sixteen (16) UL Listed Accessory
HubWayAv Video Balun/Combiners for 24VAC Cameras.
HubWayLD163Di
• HubWayLD16Di with sixteen (16) UL Listed Accessory
HubWayDv Video Balun/Combiners for 12VDC Cameras.

Installation Instructions:

HubWayLD Active Isolated Unit
