Altronix HubWay ld Installation Manual page 7

Rack Mount Chassis Mechanical Drawing & Dimensions (H x W x D approximate):
1.625"
41.28mm
16
PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE
8.5"
215.9mm
0.75"
19.05mm
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the
presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of sufficient
magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
HubWayLD Active Isolated Unit
1.625" x 19.125" x 8.5" (41.275mm x 486mm x 215.9mm)
15 14 13 12 11
GAIN PICTURE GAIN PICTURE GAIN PICTURE
1 2 3 4 CH 1-4 5
+ DATA --
1-8
(ON)
Fig. 5
Illuminated master power disconnect circuit breaker:
• OFF position Circuit breaker tripped – Switch not illuminated.
• RESET (ON) position – Switch illuminated.
CAUTION: To reduce the risk of electric shock do not open enclosure. There
are no user serviceable parts inside. Refer servicing to qualified service personnel.
REAR
10 9 8 7
GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE
TOP & BOTTOM
17.625"
447.67mm
FRONT
6 7 8 CH 5-8
28VAC
OFF
24VAC
19.125"
485.78mm
6 5 4 3 2
GAIN PICTURE GAIN PICTURE GAIN PICTURE
9 10 11 12 CH 9-12 13 14
+ DATA --
9-16
1
AC POWER
GAIN
15 16 CH 13-16
28VAC
OFF
24VAC
- 7 -
