GB

4.5 PROGRAMS

The PROGRAMS control is used for already stored programs
(or recipes), storing new ones and managing them inside a list.
program search
Programs
Search...
Apple Crumble
Apple Strudel
BBQ Chicken
Boiled Eggs
Chicken Breast
Chicken Legs
Croissants
list of programs (example)
program cancel button (basket)
4.5.2 PROGRAM SEARCH
To fi nd a program, enter the name using the keypad and press
OK. The program with name closest to the one required will be
highlighted on the list.
Program Search Name
|
ABC
abc
abc
123!?
ABC
abc
123!?
A
B
C
a
b
c
G
g
H
h
i
I
ABC
= Upper case letters
abc
= Lower case letters
123
= Numbers
. / =
= Symbols
àèé
= Other characters
4.5.3 START PROGRAM
Press the button of the Program Name on the Program List to
access the Start screen and set the cooking parameters or start
the program.
4.5.4 SAVE PROGRAM
Press this button to access the screen to save
the program (or recipe); this is similar to the search by
entering a name and confi rming with OK.
X
./=
àèé
D
E
F
d
e
f
J
j
k
K
L
l
4.5.5
LOAD / SAVE PROGRAMS
LOAD recipes / programs in Oven from USB:
1) Insert the USB key.
2) Access the Programs menu
3) Open the drawer and select the symbol
(upload from USB)
4) Select the required fi le (e.g. UI40_01.prg)
Wait for completion of the loading process.
Attention: Recipes / programs with the same name will be
overwritten.
5) Press OK and remove the key.
SAVE recipes / programs from Oven on USB:
1) Insert the USB key.
2) Access the Programs menu
3) Open the drawer and select the symbol
(save on USB)
Wait for completion of the save procedure.
4) Press OK and remove the key.

4.6 CLEANING

CLEANING SYSTEM
This cleaning system carries out automatic compartment washing
with suitable detergents according to the amount of grime detected;
therefore the following 4 cycles have been provided for:
CLEAN Soft
For still fresh grime from not very greasy cooking
CLEAN Medium
For normal grime from greasy cooking.
CLEAN Strong
For heavy grime from very greasy cooking (e.g. roast
chicken, sausages).
CLEAN Extra Strong
For heavy grime from very greasy cooking (e.g. roast chi-
cken, sausages) even with dried residuals (encrustations).
To use these stored programs, proceed as follows:
Note 1:
Before cleaning the compartment with the CLEANING SYSTEM,
remove the grease fi lter (if present).
The CLEANING SYSTEM cycle starts when the temperature has
automatically reached 70°C in the compartment.
Before carrying out a CLEANING SYSTEM cycle, make sure there
is detergent in the containers (located under the control panel on
models 6-10GN1/1 or independent in models 20GN1/1-2/1) and
that it is of the required type, therefore see par. 6. CLEANING
AND MAINTENANCE.
48
