Installation Manual
COLOR LCD SOUNDER
FCV-1200L/FCV-1200LM
i
Back

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FCV-1200L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Furuno FCV-1200L

Summary of Contents for Furuno FCV-1200L

  • Page 1: Table Of Contents

    2.3 Input/Output Sentences ..................2-10 3. INITIAL SETTINGS 3.1 Language Setting .....................3-1 3.2 Display Type......................3-2 3.3 Transducer Data (FCV-1200L only) ................3-3 3.4 Adjustment for Transceiver Unit, Video Sounder, Telesounder, Picture Recorder..3-7 3.5 Water Temperature Sensor Setting.................3-12 3.6 Net Sonde Setting ....................3-14 3.7 Nav Data, Heading Sensor Setting .................3-16...
  • Page 2 *00080900700* *00080900700* *00080900700* *00080900700* ( ( KAMI KAMI ) ) FCV-1200L/LM FCV-1200L/LM * 0 0 0 8 0 9 0 0 7 0 0 * * 0 0 0 8 0 9 0 0 7 0 0 * *IME23650R30* *IME23650R30*...

  • Page 3: Safety Instructions

    The installer of the equipment is solely responsible for the proper installation of the equipment. FURUNO will assume no responsibility for any damage associated with improper installation. Be sure that the power supply is compatible with the voltage rating of the equipment.
  • Page 4 CAUTION CAUTION The transducer cable must he handled Ground the equipment to carefully, following the guidelines prevent mutual interference. below. • Keep fuels and oils away from the Observe the following compass safe cable. • Locate the cable where it will not be distances to prevent interference to a magnetic compass: damaged.

  • Page 5: System Configuration

    *2: EXIF Assy. required for FCV-1200L. Same as above *3: For sister ship one unit only Sister ship: EXIF Assy. required for FCV-1200L Master ship: FCV-1200LM or FCV-1200L equipped with EXIF Assy. *4: Navigator may be connected to interface unit or monitor unit.
  • Page 6 *2: EXIF Assy. required for FCV-1200L. Same as above *3: For sister ship one unit only Sister ship: EXIF Assy. required for FCV-1200L Master ship: FCV-1200LM or FCV-1200L equipped with EXIF Assy. *4: When connecting optional monitor unit, connect it to control unit.

  • Page 7: Equipment Lists

    CV-1201/MU-101C Select one, with Portrait type Monitor Unit SP06-01101 (for − CV-1202/MU-101C Landscape type dislay unit) − CV-1203 For FCV-1200L Processor Unit − CV-1203M For FCV-1200LM Spare Parts SP02-04200 000-012-451 1 set SP02-04001 (Processor Unit) For landscape-type monitor unit, FP02-05100...
  • Page 8 1 set Landscape-type FP02-05111 001-413-710 Flush mount type Accessories Hard cover 06-021-2121 100-320-101 For Control Unit CP02-06520 06S4078 *5* m Installation 000-012-455 (FCV-1200L) CP02-06501 Materials CP02-06530 06S4078 *5* m 000-012-456 (FCV-1200LM) CP02-06511 1 set CP02-06680 06S4078 *10* m 000-012-468 (FCV-1200L) CP02-06501...
  • Page 9 For EXIF Board Assy. Connector FM14-8P 000-511-408 For FNZ-18 NCS-254-P 000-506-505 For connection of transducer EXIF Board OP02-81 000-012-463 1 set For FCV-1200L Assy. − Interface Unit IF-8000 1 set Unibody OP06-16 006-556-300 1 set For monitor unit and control unit monitor unit...
  • Page 10 Available transducers 1 kW transducer viii...
  • Page 11 1 kW transducer (con’t)
  • Page 12 2 kW transducer...
  • Page 13 3 kW transducer *: 5 kW transducer.
  • Page 14 3 kW transducer (con’t) *: 5 kW transducer.
  • Page 15 1 kW/2 kW transducer xiii...
  • Page 16 1 kW/2 kW transducer (con’t)
  • Page 17 1 kW/3 kW transducer *: 5 kW transducer.
  • Page 18 1 kW/3 kW transducer (con’t) *: 5 kW transducer.
  • Page 19 2 kW/3 kW transducer *: 5 kW transducer. xvii...
  • Page 20 2 kW/3 kW transducer (con’t) *: 5 kW transducer. xviii...
  • Page 21 3 kW/2 kW transducer *: 5 kW transducer.
  • Page 22 This page is intentionally left blank.

  • Page 23: Mounting

    1. MOUNTING 1.1 Monitor Unit, Control Unit The monitor and control units can be installed as one unit (unibody) or two separate units. The optional “separate monitor unit installation kit” is necessary when installing them as separate units. Further, these units can be mounted in a panel (requires optional flush mount kit), together or separately.
  • Page 24 For portrait-type unibody monitor unit a) Pass the signal cable (connects between interface unit and display unit) through the slot in the hanger and then connect the cable to the display unit. HANGER Signal Cable Slot Figure 1-2 Hanger b) Fasten the hanger at the rear of the display unit with four binding screws (M4X10). Hanger (rear view) Figure 1-3 Hanger, rear view For landscape-type unibody monitor unit...
  • Page 25 Display unit for separate type, blackbox type (vertical-type control unit) 1. Dismount the coupling place from the rear of the display unit to separate display unit from control unit. 2. Pass the signal cable (connects between interface unit and display unit) through the slot in the hanger and then connect the cable to the display unit.
  • Page 26 Hanger (rear view) Figure 1-7 Hanger, rear view 3. Coat threads of upset screws (M6X16, 2 pcs.) used to fasten hanger to mounting base. 4. Fasten the hanger (or display unit) to the mounting base with two upset screws. (Use the upper holes to tilt the display unit 20°;...
  • Page 27 Hex-head screws Mounting fixture location changes with monitor orientation. Mounting fixture Figure 1-9 How to flush mount unibody type monitor unit 3. Fasten the monitor unit to the mounting location with six tapping screws. Separate monitor unit flush mount kit Separate monitor unit flush mount kit: Type OP06-17, Code no.
  • Page 28 Separate control unit flush mount kit Control unit flush mount kit OP06-18 (Code no. 006-556-320) Separate installation kit OP02-83-1.5 (Code no. 001-413-600) Separate installation kit OP02-83-5 (Code no. 001-413-610) Name Type Code No. Remarks Mounting Fixture 06-021-2101 100-279-731 Tapping Screws 5X20 000-802-840 Hex-head Screws...
  • Page 29 Blackbox type Supply monitor and interconnection cable (D-sub connector, three rows of 15 pins, max. length 15 m) locally. The monitor connects to the interface unit, and should satisfy the specifications shown below. • VGA type • Analog RGB, 0.7 Vpp, positive polarity •...

  • Page 30: Processor Unit

    1.2 Processor Unit There are two types of Processor Units: CV-1203 (FCV-1200L) and CV-1203M (FCV-1203LM). With the EXIF Board Assy. (standard on FCV-1200LM, optional on FCV-1200L) external equipment such as an echosounder interface, switch box, etc. can be connected. The unit can be mounted on the deck, a desktop or on a bulkhead. Select a mounting location considering the points below.

  • Page 31: Interface Unit

    Interface Unit The Interface Unit IF-8000 is supplied with the blackbox-type system, and is optional with the standard type system. It can be mounted on the deck, a desktop or a bulkhead. Select a mounting location for it considering the following: •...

  • Page 32: Booster Box (Option)

    Thru-hull mount water temperature sensor T-02MSB, T-03MSB Select a suitable mounting location considering the following points: Select a mid-boat flat position. The sensor does not have to be installed perfectly perpendicular; however, the location should not be such that the transducer may be damaged when the boat is dry-docked.

  • Page 33: Wiring

    *4: Navigator may be connected to either monitor unit or interface unit. *5: Cable between monitor unit and control unit Unibody - MJ-A10SPF0002-0015 Separate - MJ-A10SPF0002-015, MJ-A10SPF0002-050 *6: A + B < 15 m A + C < 15 m Figure 2-1 Wiring diagram for standard-type FCV-1200L...
  • Page 34 Sister ship: Requires EXIF Assy. Master ship: Requires EXIF Assy. *4: When connecting optional monitor unit, connect it to control unit. *5: A + B < 15 m A + C < 15 m Figure 2-2 Wiring diagram for blackbox-type FCV-1200L...
  • Page 35 Standard-type FCV-1200LM CONTROL UNIT MONITOR UNIT CV-1201: Portrait type MU-101C CV-1202: Landscape type NMEA 0183 Navigator *2 06S4078 External Monitor *1.5m/5m/10m* Interface Unit 06S4078 (1.5m/5m/10m) IF-8000 Water Temp. Sensor 06S4078(1.5m/5m/10m) (T-02MSB, etc.) PROCESSOR UNIT CV-1203M Net Sonde Navigator *2 TEMP FNZ-18 DPYCYS-2.0 Ship's Mains...
  • Page 36 Blackbox-type FCV-1200LM CONTROL UNIT CV-1201: Portrait type CV-1202: Landscape type MONITOR UNIT External Monitor MU-101C MJ-A10SPF0002-015 MJ-A10SPF0002-050 06S4078(1.5m/ 5m/10m) NMEA 0183 Interface Unit Navigator External Monitor IF-8000 06S4078(1.5m/5m/10m) 06S4078(1.5m/5m/10m) Interface Unit IF-8000 Water Temp. Sensor (T-02MSB, etc.) PROCESSOR UNIT Interface Unit CV-1203M IF-8000 Net Sonde...

  • Page 37: Wiring Standard Equipment

    Transceiver Unit (ETR-5D/ETR-10D), Switch Box EX-7, etc. Attach connector SRCN6A25-24P (supplied) to the signal cable assy. supplied with the Transceiver Unit. Note 1: For the FCV-1200L, the EXIF board assy. (option) enables connection of external equipment. Connector SRCN6A25-24P is optionally available.
  • Page 38 Ground the equipment to prevent electrical shock and mutual interference. Interface unit IF-8000 The Interface Unit IF-8000 is supplied standard with the FCV-1200LM and is optionally available with the FCV-1200L. CONT NMEA DATA/VIDEO IN DATA/VIDEO OUT RGB OUT Cable (06S4078)
  • Page 39 Use a monitor cable (max. length 15 m) to connect a commercial monitor. A D-sub 15P connector with three rows of pins is required for connection at the interface unit. The monitor must satisfy the following requirements: VGA type Analog RGB, 0.7Vpp, positive polarity TTL level H, V, negative polarity Note 1: Two interface units may be connected.

  • Page 40: Wiring Optional Equipment

    Wiring Optional Equipment Navigator Use cable type MJ-A6SPF0011/0012 (option) to connect the navigator to the NMEA connector on the standard LCD monitor unit or Interface Unit in case of blackbox system. For detailed information see the interconnection diagram at the back of this manual. Water temperature sensor T-02MSB, T-02MTB, T-03MSB Connect the water temperature sensor cable to the TEMP connector on the processor unit.
  • Page 41 CV-1203, is necessary when connecting a telesounder (on sister ship and master ship), transceiver or other video sounder to the FCV-1200L. Below are the contents of the EXIF board assy. kit. For connection cable use type S-02-6-10 (24P, 10 m, Code No. 002-962-030).

  • Page 42: Input/Output Sentences

    Input/Output Sentences Input sentences Sentence Data Remarks Time, position GRI, TD (Loran C) Latitude and longitude TD (Loran C) Water temperature Latitude and longitude, TD (Loran C), ground speed and course Recommended minimum navigation information Latitude and longitude (GPS), ground speed and course Speed through the ground and course Output sentences Sentence...

  • Page 43: Initial Settings

    This section provides the information necessary for initial setup of the equipment. First turn on the power and set display language. For the FCV-1200L, enter transducer used, by model number (FURUNO transducer only) or by specifications. For either model, execute other procedures as applicable.

  • Page 44: Display Type

    Display Type If your picture is turned 90° do the following: 1. Press any key to show the installation main menu. XDCR SETTING INSTALLATION DEMO XDCR SELECT : XDCR TYPE [HIGH] FREQ : --- kHz TRANSDUCER : ----- PWR REDUCTION : OFF OUTPUT POWER : -- kW SUPPLY VOLT : -- V...

  • Page 45: Transducer Data (Fcv-1200L Only)

    3.3 Transducer Data (FCV-1200L only) This paragraph provides information necessary for entering transducer data. You enter transducer data by either transducer model number (for FURUNO transducer, page 3-4) or specification (page 3-5). The FCV-1200L is programmed for use with the following non-FURUNO transducers.
  • Page 46 Entering transducer data by transducer model number Note 1: If you are continuing from paragraph 3.1 go to step 2. Note 2: If you have already entered transducer settings and want to reconfirm them turn on the power while pressing any key. 1.
  • Page 47 Press any key to go to the transducer setting menu and reenter transducer data. Entering transducer data by transducer specifications For new transducer or other make of transducer see FURUNO Information for further information. Note 1: If you are continuing from paragraph 3.1 go to step 2.
  • Page 48 5. Do the following for both the high and low frequency transducers, or whichever transducer is installed. a) Press [ ] to select [HIGH] FREQ or [LOW] FREQ, and then press [+] to open the dialog box. --- kHz b) Press [+] or [-] to enter transducer frequency, and then press [ ] or [ ] to close the dialog box.

  • Page 49: Adjustment For Transceiver Unit, Video Sounder, Telesounder, Picture Recorder

    ETR-10D, etc.), Color Video Sounder, Telesounder (TS-30/507000/8000) or the Picture Recorder MT-12. Note 1: For the FCV-1200L, first install the EXIF board assy. See page 2-7. Note 2: For the FCV-1200LM, only a master ship’s telesounder can be connected. Further, the Picture Recorder MT-12 can only play back the echosounder signal;...
  • Page 50 4. Press [ ] to select E/S DRAFT SETTING, and then press [+] to open that menu. DISP ALM TX/RX USER-1/2 SYSTEM E/S DRAFT SETTING <High Frequency> XDCR CONNECT INTERNAL TX POWER : MAX DRAFT : +0.0 ft (-15~+90) FREQ CHOICE : **kHz <Low Frequency>...
  • Page 51 For transceiver unit 1. Do the following for both high and low frequencies, or whichever is installed. a) Use [ ] or [ ] to select DRAFT and press [+] to open the dialog box. +0.0 b) Use [+] or [-] to enter ship’s draft, and then press [ ] or [ ] to close the dialog box. 2.
  • Page 52 Telesounder The FCV-1200LM can only be connected to a telesounder on board a master ship and the FCV-1200L to a telesounder on board a master ship or sister ship. 1. Turn on the power. 2. Turn the [FUNCTION] switch to the MENU position.
  • Page 53 2. Turn the [FUNCTION] switch to the EXIT position to quit. Picture recorder The FCV-1200L can only playback the echosounder signal; FCV-1200LM can record and play back the echosounder signal. 1. Turn on the power and turn the [FUNCTION] switch to the MENU position.

  • Page 54: Water Temperature Sensor Setting

    CIF: Water temperature data input from CIF of Net Sonde. 6. For FURUNO make water temperature sensor or Net Sonde, you may offset water temperature data to further refine its accuracy. This must be done with the boat in water.
  • Page 55 Use [+] or [-] to enter the difference found in b) above. For example, if the indication of the ° enter –5 (degrees). FCV-1200L is +5 higher than the actual value d) Press [ ] or [ ] to close the dialog box.

  • Page 56: Net Sonde Setting

    Net Sonde Setting Follow the procedure below when a Net Sonde is connected to the video sounder. 1. Turn on the power and turn the [FUNCTION] switch to the MENU position. 2. Press [ ] and [+] to select SYSTEM at the top of the screen. 3.
  • Page 57 9. Press [ ] to select SONDE GRAPH, and then press [+] to open the dialog box. 10. Use [-] or [+] to turn the graph display OFF (default setting) or ON as appropriate, and then press [ ] or [ ] to close the dialog box. 11.

  • Page 58: Nav Data, Heading Sensor Setting

    Nav Data, Heading Sensor Setting Select navigator and heading sensor used as below. 1. Turn on the power and turn the [FUNCTION] switch to the MENU position. 2. Press [ ] and [+] to select SYSTEM at the top of the screen. 3.
  • Page 59 8. Press [ ] to select NAV DATA, and then press [+] to open the dialog box. LC LA DECCA GPS DR AUTO 9. Use [-] or [+] to select type of navigator connected, and then press [ ] or [ ] to close the dialog box.

  • Page 60: Propagation Velocity

    Propagation Velocity This section provides the information for adjustment of propagation velocity. Normally, no adjustment is necessary, however if the depth indication is wrong, lower or raise propagation velocity as appropriate. 1. Turn on the power while pressing any key to show the installation main menu. 2.

  • Page 61: Demonstration Mode

    Demonstration Mode The demonstration mode provides a simulated video sounder picture. Connection of the transducer is not necessary. All controls are operational. 1. Turn on the power while pressing any key to display the installation main menu. 2. Press [+] to select DEMO. XDCR SETTING INSTALLATION DEMO DEMO MODE...

  • Page 62: Restoring Default Settings

    3.10 Restoring Default Settings The procedure below restores most default settings. The following settings are not affected: target setting, language, demo mode, monitor type (portrait, landscape), transducer settings, user color settings and user clutter settings. 1. Turn on the power and turn the [FUNCTION] switch to the MENU position. 2.

  • Page 63: Dip Switch Setting

    No change is necessary when connecting a video sounder which uses a linear amplifier (FCV-271/382/782, etc.). For video sounder with log amplifier (FCV-1500, etc.) change the DIP switch settings as below. Early model FURUNO video sounders which have a log amplifier cannot be connected.
  • Page 64 Default setting (for linear amp) 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 Setting for log amp DIP SWITCH S1 DIP SWITCH S2 DIP SWITCH S3 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8...

  • Page 65: Appendix 1 Transducer 50Bl-12/50Bl-24H

    APPENDIX 1 TRANSDUCER 50BL-12/50BL-24H When using the transducer 50BL-12/50BL-24H, see this appendix. Transducer, thru-hull pipe and tank list Frequency Hull Tank Fasten inside Fasten outside Transducer (kHz) Material (Code No.) hull (Code No.) hull (Code No.) T-693 TWB-6000 TFB-7000 Steel (000-015-044) (000-015-207) (000-015-209)

  • Page 66: Appendix 2 New Blt Transducers

    APPENDIX 2 NEW BLT TRANSDUCERS A new type BLT transducer (Bolt-clamp Langevin Transducer) has been developed for this echo sounder. The BLT transducer has large bandwidth, good sound efficiency, compact structure and is reinforced for protection against slamming. Transducer, thru-hull pipe and tank list Frequency Hull Tank...
  • Page 67 APPENDIX 2 NEW BLT TRANSDUCERS 50/88 50BL-24HR/88-126H T-682 TWB-6000 (2) TFB-7000 (2) Steel (000-015-851) (000-015-207) (000-015-209) T-682F TRB-1100 (2) (000-015-852) (000-015-219) 28/200 28BL-12HR/200B-12H T-683 TWB-6000 (2) TFB-7000 (2) Steel (000-015-853) (000-015-207) (000-015-209) T-683F TRB-1100 (2) (000-015-854) (000-015-219) 38/200 38BL-15HR/200B-12H T-683 TWB-6000 (2) TFB-7000 (2) Steel...
  • Page 70 ＰＡＣＫＩＮＧ ＬＩＳＴ 02FJ-X-9853 -2 FCV-1200L/LM（和 ﾌﾞﾗｯｸﾎﾞｯｸｽ横型） N A M E DESCRIPTION/CODE № O U T L I N E Q'TY ユニット UNIT CV-1202 操作部 CONTROL UNIT 000-012-497 付属品 ACCESSORIES FP06-01120 06-021-2111-0 操作取付台 CONTROL UNIT MOUNTING PLATE 100-279-740 ｿｳｻﾌﾞﾗｹｯﾄ 06-021-2112-0 BRACKET 100-281-880 5X20 SUS304 +ﾄﾗｽﾀｯﾋﾟﾝﾈｼﾞ 1種...
  • Page 71 A-3A ＰＡＣＫＩＮＧ ＬＩＳＴ 02FJ-X-9856 -1 FCV-1200L/LM（和 ﾌﾞﾗｯｸﾎﾞｯｸｽ縦型） N A M E DESCRIPTION/CODE № O U T L I N E Q'TY ユニット UNIT CV-1201 操作部 CONTROL UNIT 000-012-495 付属品 ACCESSORIES FP02-05111 06-021-2101-1 操作取付金具 FLUSH MOUNTING PLATE FOR CONTROL UNIT 100-279-731 +ﾄﾗｽﾀｯﾋﾟﾝﾈｼﾞ...
  • Page 75 006-556-240 06AS-X-9503 CODE NO. CODE NO. CODE NO. CODE NO. TYPE TYPE FP06-01102 TYPE TYPE 付属品表 付属品表 付属品表 付属品表 ACCESSORIES 番 号 名  称 型名／規格 数量 略  図 用途／備考 Q'TY OUTLINE NAME DESCRIPTIONS REMARKS ﾌｰﾄﾞｸﾐﾋﾝ FP06-01102 HOOD ASSY. CODE NO. 006-556-240 06AS-X-9503 ＦＵＲＵＮＯ ＥＬＥＣＴＲＩＣ ＣＯ ．，ＬＴＤ.
  • Page 77 006-556-260 06AS-X-9501 CODE NO. CODE NO. CODE NO. CODE NO. TYPE TYPE FP06-01120 TYPE TYPE 付属品表 付属品表 付属品表 付属品表 ACCESSORIES 番 号 名  称 型名／規格 数量 略  図 用途／備考 Q'TY OUTLINE NAME DESCRIPTIONS REMARKS 操作取付台 06-021-2111-0 CONTROL UNIT MOUNTING PLATE CODE NO. 100-279-740 ｿｳｻﾌﾞﾗｹｯﾄ...
  • Page 78 TYPE NO. TYPE NO. SPARE SPARE SPARE SPARE ﾋｭｰｽﾞ FGMB 0.2A 125V FUSE 000-121-723 MFR'S NAME MFR'S NAME MFR'S NAME MFR'S NAME FURUNO FURUNO ELECTRIC ELECTRIC CO.,LTD. CO.,LTD. DWG NO. DWG NO. DWG NO. DWG NO. FURUNO FURUNO ELECTRIC ELECTRIC CO.,LTD.
  • Page 93 D - 9 Nov. 14, '02...
  • Page 96 D-12...
