Summary of Contents for Furuno FCV-1200L

Page 1: Table Of Contents
3. INITIAL SETTINGS 3.1 Language Setting ....................... 3-1 3.2 Display Type ......................3-2 3.3 Transducer Data (FCV-1200L only) ................3-3 3.4 Adjustment for Transceiver Unit, Video Sounder, Telesounder, Picture Recorder..3-7 3.5 Water Temperature Sensor Setting................. 3-12 3.6 Net Sonde Setting ....................3-14 3.7 Nav Data, Heading Sensor Setting.................
Page 2 ・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN A : APR 2000 Printed in Japan All rights reserved. U1 : SEP . 10, 2014 Pub. No. IME-23650-U1 ( YOTA ) FCV-1200L/LM 0 0 0 8 0 9 0 0 7 1 3...
Page 3: Safety Instructions
The installer of the equipment is solely responsible for the proper installation of the equipment. FURUNO will assume no responsibility for any damage associated with improper installation. Be sure that the power supply is compatible with the voltage rating of the equipment.
Page 4 CAUTION CAUTION The transducer cable must he handled Ground the equipment to carefully, following the guidelines prevent mutual interference. below. • Keep fuels and oils away from the Observe the following compass safe cable. • Locate the cable where it will not be distances to prevent interference to a magnetic compass: damaged.
Page 5: System Configuration
SYSTEM CONFIGURATION Standard type...
Page 6 Blackbox type...
Page 7: Equipment Lists
Select one, with − Portrait type Monitor Unit SP06-01101 (for CV-1202/MU-101C Landscape type − dislay unit) CV-1203 − For FCV-1200L Processor Unit CV-1203M For FCV-1200LM − Spare Parts SP02-04200 000-012-451 1 set SP02-04001 (Processor Unit) For landscape-type monitor unit, FP02-05100...
Page 8 FP02-05111 001-413-710 1 set Flush mount type Accessories Hard cover 06-021-2121 100-320-101 For Control Unit Installation CP02-06520 06S4078 *5* m 000-012-455 (FCV-1200L) CP02-06501 Materials CP02-06530 06S4078 *5* m 000-012-456 (FCV-1200LM) CP02-06511 1 set CP02-06680 06S4078 *10* m 000-012-468 (FCV-1200L) CP02-06501...
Page 9 For EXIF Board Assy. Connector FM14-8P 000-511-408 For FNZ-18 NCS-254-P 000-506-505 For connection of transducer EXIF Board OP02-81 000-012-463 1 set For FCV-1200L Assy. Interface Unit IF-8000 − 1 set Unibody OP06-16 006-556-300 1 set For monitor unit and control unit monitor unit...
Page 10 Available transducers 1 kW transducer viii...
Page 11 1 kW transducer (con’t)
Page 12 2 kW transducer...
Page 13 3 kW transducer *: 5 kW transducer.
Page 14 3 kW transducer (con’t) *: 5 kW transducer.
Page 15 1 kW/2 kW transducer xiii...
Page 16 1 kW/2 kW transducer (con’t)
Page 17 1 kW/3 kW transducer *: 5 kW transducer.
Page 18 1 kW/3 kW transducer (con’t) *: 5 kW transducer.
Page 19 2 kW/3 kW transducer *: 5 kW transducer. xvii...
Page 20 2 kW/3 kW transducer (con’t) *: 5 kW transducer. xviii...
Page 21 3 kW/2 kW transducer *: 5 kW transducer.
Page 22 This page is intentionally left blank.
Page 23: Mounting
1. MOUNTING NOTICE Do not apply paint, anti-corrosive sealant or contact spray to coating or plastic parts of the equipment. Those items contain organic solvents that can damage coating and plastic parts, especially plastic connectors. 1.1 Monitor Unit, Control Unit The monitor and control units can be installed as one unit (unibody) or two separate units.
Page 24 For portrait-type unibody monitor unit a) Pass the signal cable (connects between interface unit and display unit) through the slot in the hanger and then connect the cable to the display unit. HANGER Signal Cable Slot Figure 1-2 Hanger b) Fasten the hanger at the rear of the display unit with four binding screws (M4X10). Hanger (rear view) Figure 1-3 Hanger, rear view For landscape-type unibody monitor unit...
Page 25 Display unit for separate type, blackbox type (vertical-type control unit) 1. Dismount the coupling place from the rear of the display unit to separate display unit from control unit. 2. Pass the signal cable (connects between interface unit and display unit) through the slot in the hanger and then connect the cable to the display unit.
Page 26 Hanger (rear view) Figure 1-7 Hanger, rear view 3. Coat threads of upset screws (M6X16, 2 pcs.) used to fasten hanger to mounting base. 4. Fasten the hanger (or display unit) to the mounting base with two upset screws. (Use the upper holes to tilt the display unit 20°;...
Page 27 Hex-head screws Mounting fixture location changes with monitor orientation. Mounting fixture Figure 1-9 How to flush mount unibody type monitor unit 3. Fasten the monitor unit to the mounting location with six self-tapping screws. Separate monitor unit flush mount kit Separate monitor unit flush mount kit: Type OP06-17, Code no.
Page 28 Separate control unit flush mount kit Control unit flush mount kit OP06-18 (Code no. 006-556-320) Separate installation kit OP02-83-1.5 (Code no. 001-413-600) Separate installation kit OP02-83-5 (Code no. 001-413-610) Name Type Code No. Remarks Mounting Fixture 06-021-2101 100-279-731 Self-tapping Screw 5×20 000-162-609-10 Hex-head Screw...
Page 29 Blackbox type Supply monitor and interconnection cable (D-sub connector, three rows of 15 pins, max. length 15 m) locally. The monitor connects to the interface unit, and should satisfy the specifications shown below. • VGA type • Analog RGB, 0.7 Vpp, positive polarity •...
Page 30: Processor Unit
1.2 Processor Unit There are two types of Processor Units: CV-1203 (FCV-1200L) and CV-1203M (FCV-1203LM). With the EXIF Board Assy. (standard on FCV-1200LM, optional on FCV-1200L) external equipment such as an echosounder interface, switch box, etc. can be connected. The unit can be mounted on the deck, a desktop or on a bulkhead. Select a mounting location considering the points below.
Page 31: Interface Unit
Interface Unit The Interface Unit IF-8000 is supplied with the blackbox-type system, and is optional with the standard type system. It can be mounted on the deck, a desktop or a bulkhead. Select a mounting location for it considering the following: •...
Page 32 This page is intentionally left blank. 1-10...
Page 33: Wiring
Cover wiring with vinyl tape and pass cable through hole. This will permit passing of the cable through a hole of 30 mm diameter. Standard-type FCV-1200L Figure 2-1 Wiring diagram for standard-type FCV-1200L...
Page 34 Blackbox-type FCV-1200L Figure 2-2 Wiring diagram for blackbox-type FCV-1200L...
Page 35 Standard-type FCV-1200LM Figure 2-3 Wiring diagram for standard-type FCV-1200LM...
Page 36 Blackbox-type FCV-1200LM Figure 2-4 Wiring diagram for blackbox-type FCV-1200LM...
Page 37: Wiring Standard Equipment
Transceiver Unit (ETR-5D/ETR-10D), Switch Box EX-7, etc. Attach connector SRCN6A25-24P (supplied) to the signal cable assy. supplied with the Transceiver Unit. Note 1: For the FCV-1200L, the EXIF board assy. (option) enables connection of external equipment. Connector SRCN6A25-24P is optionally available.
Page 38: Power Cable
Ground the equipment to prevent electrical shock and mutual interference. Interface unit IF-8000 The Interface Unit IF-8000 is supplied standard with the FCV-1200LM and is optionally available with the FCV-1200L. CONT NMEA DATA/VIDEO IN DATA/VIDEO OUT RGB OUT Cable (06S4078)
Page 39 Use a monitor cable (max. length 15 m) to connect a commercial monitor. A D-sub 15P connector with three rows of pins is required for connection at the interface unit. The monitor must satisfy the following requirements: VGA type Analog RGB, 0.7Vpp, positive polarity TTL level H, V, negative polarity Note 1: Two interface units may be connected.
Page 40: Wiring Optional Equipment
Wiring Optional Equipment Navigator Use cable type MJ-A6SPF0011/0012 (option) to connect the navigator to the NMEA connector on the standard LCD monitor unit or Interface Unit in case of blackbox system. For detailed information see the interconnection diagram at the back of this manual. Water temperature sensor T42, T80 Connect the water temperature sensor cable to the TEMP connector on the processor unit.
Page 41 CV-1203, is necessary when connecting a telesounder (on sister ship and master ship), transceiver or other video sounder to the FCV-1200L. Below are the contents of the EXIF board assy. kit. For connection cable use type S-02-6-10 (24P, 10 m, Code No. 002-962-030).
Page 42: Input/Output Sentences
Input/Output Sentences Input sentences Sentence Data Remarks Time, position GRI, TD (Loran C) Latitude and longitude TD (Loran C) Water temperature Latitude and longitude, TD (Loran C), ground speed and course Recommended minimum navigation information Latitude and longitude (GPS), ground speed and course Speed through the ground and course Heaving data (satellite compass) P sentence Roll angle, Pitch angle (satellite compass) P sentence...
Page 43: Initial Settings
This section provides the information necessary for initial setup of the equipment. First turn on the power and set display language. For the FCV-1200L, enter transducer used, by model number (FURUNO transducer only) or by specifications. For either model, execute other procedures as applicable.
Page 44: Display Type
Display Type If your picture is turned 90° do the following: 1. Press any key to show the installation main menu. XDCR SETTING INSTALLATION DEMO XDCR SELECT : XDCR TYPE [HIGH] FREQ : --- kHz TRANSDUCER : ----- PWR REDUCTION : OFF OUTPUT POWER : -- kW SUPPLY VOLT : -- V...
Page 45: Transducer Data (Fcv-1200L Only)
3.3 Transducer Data (FCV-1200L only) This paragraph provides information necessary for entering transducer data. You enter transducer data by either transducer model number (for FURUNO transducer, page 3-4) or specification (page 3-5). The FCV-1200L is programmed for use with the following non-FURUNO transducers.
Page 46 Entering transducer data by transducer model number Note 1: If you are continuing from paragraph 3.1 go to step 2. Note 2: If you have already entered transducer settings and want to reconfirm them turn on the power while pressing any key. 1.
Page 47 Press any key to go to the transducer setting menu and reenter transducer data. Entering transducer data by transducer specifications For new transducer or other make of transducer see FURUNO Information for further information. Note 1: If you are continuing from paragraph 3.1 go to step 2.
Page 48 5. Do the following for both the high and low frequency transducers, or whichever transducer is installed. a) Press [ ] to select [HIGH] FREQ or [LOW] FREQ, and then press [+] to open the dialog box. --- kHz b) Press [+] or [-] to enter transducer frequency, and then press [ ] or [ ] to close the dialog box.
Page 49: Adjustment For Transceiver Unit, Video Sounder, Telesounder, Picture Recorder
ETR-10D, etc.), Color Video Sounder, Telesounder (TS-30/507000/8000) or the Picture Recorder MT-12. Note 1: For the FCV-1200L, first install the EXIF board assy. See page 2-7. Note 2: For the FCV-1200LM, only a master ship’s telesounder can be connected. Further, the Picture Recorder MT-12 can only play back the echosounder signal;...
Page 50 4. Press [ ] to select E/S DRAFT SETTING, and then press [+] to open that menu. DISP ALM TX/RX USER-1/2 SYSTEM E/S DRAFT SETTING <High Frequency> XDCR CONNECT INTERNAL TX POWER : MAX DRAFT : +0.0 ft (-15~+90) FREQ CHOICE : **kHz <Low Frequency>...
Page 51 For transceiver unit 1. Do the following for both high and low frequencies, or whichever is installed. a) Use [ ] or [ ] to select DRAFT and press [+] to open the dialog box. +0.0 b) Use [+] or [-] to enter ship’s draft, and then press [ ] or [ ] to close the dialog box. 2.
Page 52 Telesounder The FCV-1200LM can only be connected to a telesounder on board a master ship and the FCV-1200L to a telesounder on board a master ship or sister ship. 1. Turn on the power. 2. Turn the [FUNCTION] switch to the MENU position.
Page 53 2. Turn the [FUNCTION] switch to the EXIT position to quit. Picture recorder The FCV-1200L can only playback the echosounder signal; FCV-1200LM can record and play back the echosounder signal. 1. Turn on the power and turn the [FUNCTION] switch to the MENU position.
Page 54: Water Temperature Sensor Setting
5. Use [+] or [-] to select source of water temperature data, and then press [ ] or [ ] to close the dialog box. SONDE: FURUNO Net Sonde FNZ-18 inputs water temperature data. SENSOR: Water temperature sensor T42 or T80 inputs water temperature data. This is the default setting.
Page 55 Use [+] or [-] to enter the difference found in b) above. For example, if the indication of the ° enter –5 (degrees). FCV-1200L is +5 higher than the actual value d) Press [ ] or [ ] to close the dialog box.
Page 56: Net Sonde Setting
Net Sonde Setting Follow the procedure below when a Net Sonde is connected to the video sounder. 1. Turn on the power and turn the [FUNCTION] switch to the MENU position. 2. Press [ ] and [+] to select SYSTEM at the top of the screen. 3.
Page 57 9. Press [ ] to select SONDE GRAPH, and then press [+] to open the dialog box. 10. Use [-] or [+] to turn the graph display OFF (default setting) or ON as appropriate, and then press [ ] or [ ] to close the dialog box. 11.
Page 58: Nav Data, Heading Sensor Setting
Nav Data, Heading Sensor Setting Select navigator and heading sensor used as below. 1. Turn on the power and turn the [FUNCTION] switch to the MENU position. 2. Press [ ] and [+] to select SYSTEM at the top of the screen. 3.
Page 59 8. Press [ ] to select NAV DATA, and then press [+] to open the dialog box. LC LA DECCA GPS DR AUTO 9. Use [-] or [+] to select type of navigator connected, and then press [ ] or [ ] to close the dialog box.
Page 60: Stabilization (Heaving Compensation)
Stabilization (heaving compensation) The stabilization feature is available with connection of a satellite compass (SC-50/SC-110) to the NMEA port and functions to compensate for ship's heaving. Set NMEA output from the satellite compass as below and follow the accompanying procedure to compensate for heaving. SC-50/SC-110 SC-30 Version: IEC ED1...
Page 61: Propagation Velocity
Propagation Velocity This section provides the information for adjustment of propagation velocity. Normally, no adjustment is necessary, however if the depth indication is wrong, lower or raise propagation velocity as appropriate. 1. Turn on the power while pressing any key to show the installation main menu. 2.
Page 62: Demonstration Mode
3.10 Demonstration Mode The demonstration mode provides a simulated video sounder picture. Connection of the transducer is not necessary. All controls are operational. 1. Turn on the power while pressing any key to display the installation main menu. 2. Press [+] to select DEMO. XDCR SETTING INSTALLATION DEMO DEMO MODE...
Page 63: Restoring Default Settings
3.11 Restoring Default Settings The procedure below restores most default settings. The following settings are not affected: target setting, language, demo mode, monitor type (portrait, landscape), transducer settings, user color settings and user clutter settings. 1. Turn on the power and turn the [FUNCTION] switch to the MENU position. 2.
Page 64: Dip Switch Setting
No change is necessary when connecting a video sounder which uses a linear amplifier (FCV-271/382/782, etc.). For video sounder with log amplifier (FCV-1500, etc.) change the DIP switch settings as below. Early model FURUNO video sounders which have a log amplifier cannot be connected.
Page 65 Default setting (for linear amp) 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 Setting for log amp DIP SWITCH S1 DIP SWITCH S2 DIP SWITCH S3 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8...
Page 66 This page is intentionally left blank. 3-24...
Page 67: Appendix 1 Transducer 50Bl-12/50Bl-24H
APPENDIX 1 TRANSDUCER 50BL-12/50BL-24H When using the transducer 50BL-12/50BL-24H, see this appendix. Transducer, thru-hull pipe and tank list Frequency Hull Tank Fasten inside Fasten outside Transducer (kHz) Material (Code No.) hull (Code No.) hull (Code No.) T-693 TWB-6000 TFB-7000 Steel (000-015-044) (000-015-207) (000-015-209)
Page 68: Appendix 2 Blt Transducers
APPENDIX 2 BLT TRANSDUCERS The BLT transducer (Bolt-clamp Langevin Transducer) has large bandwidth, good sound efficiency, compact structure and is reinforced for protection against slamming. Transducer, thru-hull pipe and tank list Frequency Hull Tank Fasten inside Fasten outside Transducer (kHz) Material (Code No.) hull (Code No.)
Page 69 APPENDIX 2 BLT TRANSDUCERS 50/88 50BL-24HR/88-126H T-682 TWB-6000 (2) TFB-7000 (2) Steel (000-015-851) (000-015-207) (000-015-209) T-682F TRB-1100 (2) (000-015-852) (000-015-219) 28/200 28BL-12HR/200B-12H T-683 TWB-6000 (2) TFB-7000 (2) Steel (000-015-853) (000-015-207) (000-015-209) T-683F TRB-1100 (2) (000-015-854) (000-015-219) 38/200 38BL-15HR/200B-12H T-683 TWB-6000 (2) TFB-7000 (2) Steel (000-015-853)
Page 70: Appendix 3 Transducer 82B-35R
APPENDIX 3 TRANSDUCER 82B-35R The 82B-35R is a transducer with wide bandwidth of 65 kHz-110 kHz. It is constructed to provide protection against slamming. Transducer, thru-hull pipe and tank list Frequency Hull Tank Fasten inside Fasten outside Transducer (kHz) Material (Code No.) hull (Code No.) hull (Code No.)
Page 71: Appendix 4 T42 And T80 Temperature Sensors
APPENDIX 4 T42 AND T80 TEMPERATURE SENSORS The following pages of this appendix provide a copy of the installation instructions for AIRMAR temperature sensors T42 and T80. AP-5...
Page 72 OWNER’S GUIDE & INSTALLATION INSTRUCTIONS Thru-Hull, Analog Record the information found on the cable tag for future reference. Part No._________________Date___________ High-Precision Temperature Sensor Model T42 Follow the precautions below for optimal product performance and to reduce the risk of property damage, personal injury, and/or death. WARNING: Always wear safety goggles and a dust mask when installing.
Page 73 9-12 mm (3/8-1/2") pour in larger than the casting hole through the epoxy hull’s outer skin inner skin core hull thickness hull nut hull solid or hollow cylinder outer skin bedding Figure 1. Bedding and installing Figure 2. Preparing a cored fiberglass hull Copyright ©...
Page 74 Maintenance & Replacement Aquatic growth can accumulate rapidly on the sensor’s surface reducing its performance within weeks. Clean the surface with a Scotch-Brite® scour pad and mild household detergent taking care to avoid making scratches. If the fouling is severe, lightly wet sand with fine grade wet/dry paper.
Page 76: Mounting Location
OWNER’S GUIDE & INSTALLATION INSTRUCTIONS Surface Mount, Analog Record the information found on the cable tag for future reference. Part No._________________Date___________ Temperature Sensor Model T80 Follow the precautions below for optimal product performance and to reduce the risk of property damage, personal injury, and/or death. Tools &...
Page 77 Mount the sensor near the centerline and close to the bottom of Cable Routing & Connecting the transom. 1. Route the cable to the instrument, being careful not to tear the cable jacket when passing it through the bulkhead(s) and other Route the sensor cable over the transom, through a drain hole, or parts of the boat.
Page 85 D-2A...
Page 86 D-2B...
Page 90 D-5A...
Page 91 D-5B...
Page 97 D - 9 Nov. 14, '02...
Page 100 D-12...
Page 101: Interconnection Diagrams
1φ,50/60Hz 整流器（＋）（－） W=50mm RECTIFIER COPPER STRAP RU-1746B-2 アース銅板 IV-8sq. 50/200-1T 50/200-1ST 送受波器 TRANSDUCER 送受波器 FCV-1200Lのみ注記 TRANSDUCER FCV-1200L ONLY ＊１）造船所手配。＊２）オプション。＊３）工場にて取付済み。＊４）コネクタクランプでアースに落とす。＊５）表示部がある場合は表示部に接続すること。 DRAWN TITLE FCV-1200L/1200LM T.YAMASAKI 14/Jul/2014 NOTE CHECKED 名称カラー魚群探知機 *1. SHIPYARD SUPPLY. H.MAKI 14/Jul/2014 *2.
