Case Of Power Restoration Before The End Of The "Shutdown Duration" Counter - Eaton Network-MS User Manual

www.eaton.com
Utility failure
Utility
Main output
NSM 1 on main
output
Output 1
NSM 2 on output 1

5.2.3 Case of power restoration before the end of the "shutdown duration" counter

If power is restored before the end of the Shutdown Duration, the UPS is shut off after the Shutdown Duration for
a time equal to the forced reboot delay (10 seconds)
Utility failure
Utility
Main output
NSM 1 on main
output
Output 1
NSM 2 on output 1
Network Management Card
Start shutdown main
Start shutdown
output
output 1
Battery capacity
under:
Shutdown
duration output 1
Battery capacity
under: (output 1)
Start shutdown main
Start shutdown
output
output 1
Battery capacity under
Shutdown
duration output 1
Battery capacity
under: (output 1)
– User Manual 34003991XT_EN/JC
Network
Management Card
(Network-MS)
User Manual
Utility restore
Shutdown duration
Utility restore
Shutdown
Forced Reboot
duration
:
Page
82/143
