The can take the next forms:
Status
•
or when the module is working properly with no alarm.
when the module has at least one alarm (level Warning) active.
when the module has at least one alarm (level Critical) active.
when the module has a communication fault.
When the module is working properly with no alarms, the icon is not reactive, otherwise it is reactive and clicking
on it makes the page Alarm Table appear.
Output load level: Value of the percentage of load at module output
•
Battery load level: Percentage of charge available in the battery module
•
