4.5 Environment Sensor (option)

The environment sensor (66846) is an option that enables temperature and humidity to be measured, and
indication of the position of two external contacts. It is connected with a standard network cable to the Card
Settings port of the Network Management Card.
The card automatically detects sensor presence. The main menu then displays an additional section
"Environment" with the following elements:
Status
•
Configuration
•
Log
•
Important note: To switch the serial port to the configuration mode, just disconnect the cable and

4.5.1 Characteristics

Temperature measurement from 0 to 70 ° C with +/- 1° C accuracy
•
Measurement of humidity from 0 to 100% with +/- 6% accuracy
•
Min / max time-stamped function for temperature and humidity
•
Choice of temperature readings in Celsius or Fahrenheit
•
High and low thresholds, hysteresis and offset adjustable via Web interface
•
Possibility of notification of status changes by e-mail, SMS or SNMP trap
•
Note: SMS notification requires the use of a third-party application that converts emails to SMS
Position detection of 2 dry contacts (maximum sensor/contact distance: 20 m)
•
Name and status of each configurable contact
•
Recording of events and measurements in the card log
•
Possibility of shutting down the installation safely if one of the thresholds is exceeded or dry contact
•
status change
Connection to the Network Management Card by shielded CAT5 straight RJ45 network cables
•
(maximum card/sensor distance: 10m)
Network Management Card
– User Manual 34003991XT_EN/JC
Network
Management Card
(Network-MS)
User Manual
reset the card.
