Adding an External Audio Source

Two inputs are available on the DIS-CCU for adding an external audio source to the system, often useful for
teleconferencing or internet calling.
1. Connect a line-level audio source, such as the audio output of a computer, teleconferencing unit, or wireless
microphone system to the audio input on the DIS-CCU back panel.
2. Open the web interface to
3. Select the input gain according to the output of the external device. If necessary, select 10 dB for a slight gain boost.
4. Select the routing for the audio channel:
• Loudspeaker: to all microphone unit loudspeakers
• Ch. 0: to the headphone output on the microphone unit
5. If desired, route the channel to Output A (Group) to output a blend of the external source with the microphone units:
• Deselect for teleconferencing or signal processing to avoid a feedback loop
• Select for a wireless microphone to be blended with other microphone unit audio
6. Adjust the volume of the audio input to mix naturally with speech levels of the microphone units.
> .
Audio Input Control
Input Control Page
Audio
Set gain and fine-tune volume
Route the input channels
>
Input Control
43
