Menu Navigation

The DIS-CCU provides controls from the front panel for
system setup and configuration. Use the 5-button keypad to
navigate the menu and change settings.
The figure below gives an overview of the menu structure.
• Use arrow buttons to cycle through menu items
• Press enter (center) button to navigate to an editable
field.
• Use up/down buttons to cycle through the available
values
6000 tMode
Main Menu
Loudspk. Control
Loudspk. Volume
Mic -> Loudspk.
Audio In 1-> Loudspk.
Audio In 2-> Loudspk.
Audio Out A Volume
Participant Setup
Max. Speakers
Max. Total Speakers
Max. Deleg. Speakers
Max. Requests
Max. Replies
Operation
Operation Mode
Speak Interrupt
Voice Detection
Threshold
Release Time
Auto off
Auto Off Time
LAN Setup
IP address
Subnet Mask
Default Gateway
IP Address Mode
MAC Address
Local Hostname
System
License Info
Max. Conf. Units
Max. Intp. Channels
6000 Operation
Select 5900 System
FW Release ID
Serial Number
Restore Factory Defaults
Menu Overview - DCS 6000 Mode
13
0 to -40 dB, Off
On/Off
On/Off
On/Off
0 to -40 dB, Off
1 to 8
1 to 8
0 to 250
0 to 250
Auto, Manual, FIFO,
Vox, Auto Reply, Manual
Reply, Vox Reply
Lower, Same, None
-12 to 8 dB
1.0 to 10.0 sec
On/Off
5 to 60 sec
xxx.xxx.xxx.xxx
xxx.xxx.xxx.xxx
xxx.xxx.xxx.xxx
Dynamic/Static
xx:xx:xx:xx:xx:xx
dis-ccu
250/3800
Licensed 4 to 31
License Available
OK/Cancel
x.x.xxx
xxx.xxx.xxx
OK/Cancel
