Floor Mix on the Loudspeakers

Loudspeakers are included in most microphone units for localized sound-reinforcement of the meeting. When a participant
uses their microphone, their speech is heard at other unit loudspeakers. This improves speech clarity in large rooms and
reduces typical problems associated with sound reinforcement systems.
A Loudspeaker for Each Participant
Each participant can listen to the meeting on a personal loudspeaker attached to the microphone unit.
Note: To avoid feedback, the loudspeaker is turned off when that microphone is active.
Loudspeaker Adjustment
Loudspeaker volume is a system setting that applies to all connected units. Volume is adjustable from -0 dB (no
attenuation) to -40 dB, including off (mute). To adjust the volume:
From the Browser Interface
Go to the Loudspeaker Control page ( > )
Audio Loudspeaker Control
From the CU
Scroll to the Loudspeaker Menu ( > > )
loudspk. control loudspk. volume db

Headphone Channels

Microphone units include a headphone output for listening to interpreter channels or other participants on the floor
channel. Each participant chooses their channel from the microphone unit channel selectors.
Channels 1 - 31 are dedicated for language interpretation. Participants select one of the channels to listen to their
language during a multilingual event. The audio source comes from interpreter stations transmitting onto their selected
channel. See the Interpretation section of this guide for more details.
Channel 0 (the floor channel) is typically selected by interpreters to provide simultaneous interpretation of those
addressing the floor. This channel is also selectable by other participants to listen to the floor channel on headphones
(channel 0 = LEDs off).
1. Connect headphones to the headphone jack on the side of the microphone unit.
2. Select a channel by pressing the selector buttons on the front of the unit.
3. Adjust the volume of the headphones using the + or - buttons on the unit.
40
