Voting Results

During voting sessions the CCU delivers interim voting
results, unless the session is secret.
At completion of a voting session, the CCU delivers final
voting results. Also at completion of an attendance check
the CCU delivers final attendance check result.
10.1.9.2 The DIS-CCU supports 3- and 5-button voting.
3-button voting sessions the following alternatives apply:
1 'Yes' 2 'Abstain' 3 'No' 5-button voting sessions the
following alternatives apply: 1 '+ +' 2 '+' 3 '0' 4 '-' 5 '- -'
10.1.9.2.1 Example: Voting Assume, that the DIS-CCU is
not controlled by SW 6000
SW 6000 controlled
With SW 6000 attached to the CCU, voting results are
defined in SW 6000. Up to 9 voting results can be defined.
Standalone
The DIS-CCU supports 3- and 5-button voting.
3-button voting sessions the following alternatives apply:
1. 'Yes'
2. 'Abstain'
3. 'No'
5-button voting sessions the following alternatives apply:
1. '++'
2. '+'
3. '0'
4. '-'
5. '--'

Microphone Control

Commands from External Control to
DIS-CCU
Turn on microphone
mic_on <seat no><CR>
Instruct the CCU to turn on the microphone at seat_no.
If the CCU turns on the microphone, it replies with the
'mic_on' command. If the microphone also appeared in the
request list, it is taken out of the request list and the CCU
issues the 'mic_request_off' command.
Turn off microphone
mic_off <seat no><CR>
Instruct the CCU to turn off the microphone at seat_no.
Example: Voting
Assume that the DIS-CCU is not controlled by the SW 6000
ExtCtrl
CU
---------------------------------->
voting_status
---------------------------------->
<----------------------------------
voting_configuration 1 3-button voting voting_configuration 2
3-button secret voting
voting_configuration 3 5-button voting voting_configuration 4
5-button secret voting
voting_status_done
<----------------------------------
---------------------------------->
start_voting 1
---------------------------------->
<---------------------------------- voting_started 1
<----------------------------------
<---------------------------------- interim_voting_result 1
0 Yes interim_voting_result 2 0 Abstain
interim_voting_result 3 0 No
<----------------------------------
<--------------------
vote (Yes)
<--------------------
<---------------------------------- interim_voting_result 1
1 Yes interim_voting_result 2 0 Abstain
interim_voting_result 3 0 No
<----------------------------------
---------------------------------->
stop_voting
---------------------------------->
<----------------------------------
voting_stopped
<----------------------------------
<---------------------------------- final_voting_result 1 1
Yes final_voting_result 2 0 Abstain
final_voting_result 3 0 No
<----------------------------------
If the CCU turns off the microphone, it issues a 'mic_off'
command.
Turn off all the delegate microphones
mic_all_delegates_off><CR>
Instruct the CCU to turn off all delegate microphones.
A Chairman is not turned off.
The CCU responds to the command by issuing the 'mic_
off' command for each microphone that is turned off.
Put a microphone in the reply list
mic_reply_on <seat no><CR>
Insert a microphone into the reply list.
