TGWxE1-2G PRI (ISDN) Trunk
Gateways Series for Aeonix

Figure 5-30 Upgrade Interface

Step6 The following prompt is displayed during the upgrade.

Figure 5-31 Prompt of Upgrade Process

The gateway upgrade takes a few minutes. Do not operate the gateway during this period.
Step7 Clicke OK on the following dialog box that is displayed once the upgrade is completed.

Figure 5-32 Interface of Successful Upgrade

Step8 The gateway will reboot, and the login interface will be displayed (see 5.1 Login, on page 5-1).
Step9 Wait for about 2 minutes, and access the interface of gateway management system. Click Info
and check the software version to verify that the upgrade was completed successfully.
5-47
