5.7.5 Manage Log

Click the Logs > Manage Log tab to open this interface. Log files can be downloaded through this
interface.

Figure 5-24 Manage Log Interface

Table 5-22 Manage Log Parameters

Name
Log level
System log server
Local log port
Log server
Procedure for downloading the log:
Step1 Click Download; the gateway begins to assemble the logs.
Step2 After a few seconds, the interface of log saving will be displayed.
Step3 Click Save, and select the path to save.
Step4 The user may review the log from the server.
5-43
Description
Select the log file level of gateway. Default is 4. The higher the level, the more details the log
file will provide.
Note: Log level should be set to be 4 or lower when gateway is used in normal operation, so
as not to impact system performance.
Set the IP address of the system log server.
The port for sending system logs.
IP address of debugging the log server.
