SmartNode 1000 and 2000 Series Getting Started Guide
Note

Installing the interface card cables

The following interface cards are available for use with the SmartNode 2300:
• IC-4FXS—Gateway interface card for 4 analog FXS ports (see section
card cables")
• IC-4BRV-8V—8-channel gateway interface card for ISDN BRI (see section
interface card cables"
• IC-E1V—30-channel E1 gateway interface card for ISDN PRI (see section
card cables" on page 96)
• IC-T1V—23-channel T1 gateway interface card for ISDN PRI (see section
face card cables" on page 97)
Determine which cards are installed in your SmartNode 2300, then go to the appropriate section to install
the device.

Installing the IC-4FXS interface card cables

The IC-4FXS supports up to four analog connections (see
nated with RJ-12 plugs (see
Note
Note
Connecting cables
Some NTUs have non-standard or mirrored connections and require
special cables. Consult the NTU maker's product documentation.
on page 94)
figure 61 on page 94).
Table 29. RJ-12 socket
Pin
3
4
The IC-4FXS is actually equipped with RJ-11 sockets. An RJ-11
socket is similar to an RJ-12 socket but pins 1 and 6 are omitted.
Pins not listed are not used.
6 • SmartNode 2300 installation
"Installing the IC-4FXS interface
"Installing the IC-E1V interface
table 28 for port pin-out listing) via cables termi-
Signal
Ring (-)
Tip (+)
"Installing the IC-4BRV-8V
"Installing the IC-T1V inter-
93
