SmartNode 1000 and 2000 Series Getting Started Guide
Front panel
The front view of the IC-T1V interface card is depicted in
interface. See chapter 11,
Interface
The card provides one PRI port, described in
Port
T1 0
RJ-45 connector providing T1 PRI (1.533 Mbps) interface, meeting all requirements of ITU-T recom-
mendations for G.703. Use a shielded T1 interface cable for 120W balanced connections to con-
nect the SmartNode with an NT or ET, e.g. a PBX or LE.
Description
The IC-T1V interface card provides an ISDN PRI interface allowing transfer of up to 23 ISDN voice channels
in parallel.
Interface cards descriptions
"Monitoring Status"
on page 132 for detailed information on the LED states.
Figure 27. IC-T1V
table
Table 17. IC-E1V port description
figure
26. The LINK LED indicates the status of the
15. The connector is terminated at 120 ohm.
Description
1 • General Information
48
